SCIENTIFIC AMERICAN SUPPLEMENT NO. 275

NEW YORK, APRIL 9, 1881

Scientific American Supplement. Vol. XI, No. 275.

Scientific American established 1845

Scientific American Supplement, $5 a year.

Scientific American and Supplement, $7 a year.

* * * * *

TABLE OF CONTENTS.

I. ENGINEERING AND MECHANICS.--The Various Modes of

Transmitting Power to a Distance. (Continued from No. 274.)

By ARTHUR ARCHARD. of Geneva.--II. Compressed Air.--III.

Transmission by Pressure Water.--IV. Transmission by

Electricity.--General Results

The Hotchkiss Revolving Gun

Floating Pontoon Dock. 2 figures.--Improved floating pontoon dock

II. TECHNOLOGY AND CHEMISTRY.--Wheat and Wheat Bread. By H. MEGE

MOURIES.--Color in bread.--Anatomical structure and chemical

composition of wheat.--Embryo and coating of the embryo.--

Cerealine--Phosphate of calcium.--1 figure, section of a grain

of wheat, magnified.

Origin of New Process Milling.--Special report to the Census

Bureau. By ALBERT HOPPIN.--Present status of milling structures

and machinery in Minneapolis by Special Census Agent C. W.

JOHNSON.--Communication from GEORGE T. SMITH.

Tap for Effervescing Liquids. 1 figure.

London Chemical Society.--Notes.--Pentathionic acid, Mr.

VIVIAN LEWES.--Hydrocarbons from Rosin Spirit. Dr.

ARMSTRONG.--On the Determination of the Relative Weight of Single

Molecules. E. VOGEL.--On the Synthetical Production of Ammonia

by the Combination of Hydrogen and Nitrogen in the Presence of

Heated Spongy Platinum, G. S. JOHNSON.--On the Oxidation of

Organic Matter in Water, A. DOWNS.

Rose Oil, or Otto of Roses. By CHAS. G. WARNFORD LOCK.--Sources

of rose oil.--History--Where rose gardens are now cultivated

for oil.--Methods of cultivation.--Processes of

distillation.--Adulterations

ads:

A New Method of Preparing Metatoluidine. By OSCAR WIDMAN.

III. AGRICULTURE, HORTICULTURE, ETC.--The Guenon Milk Mirror. 1 figure.

Escutcheon of the Jersey Bull Calf, Grand Mirror.

Two Good Lawn Trees

Cutting Sods for Lawns

Horticultural Notes: New apples, pears, grapes, etc.--Discussion

on Grapes. Western New York Society.--New peaches.--Insects

affecting horticulture.--Insect destroyers.

Observations on the Salmon of the Pacific. By DAVID S. JORDAN

and CHARLES B. GILBERT. Valuable census report.

IV. LIGHT, ELECTRICITY ETC.--Relation between Electricity

and Light. Dr. O. T. Lodge's lecture before the London Institute.

Interesting Electrical Researches by Dr. Warren de La Rue and

Dr. Hugo Miller.

Telephony by Thermic Currents

The Telectroscope. By Moxs. SENLECQ. 5 figures. A successful

apparatus for transmitting and reproducing camera pictures by

electricity.

V. HYGIENE, MEDICINE, ETC.--Rapid Breathing as a Pain Obtunde in

Minor Surgery, Obstetrics, the General Practice of Medicine, and

of Dentistry. Dr. W. G. A. Bonwill's paper before the

Philadelphia County Medical Society. 8 figures. Sphygmographic

tracings.

VI. ARCHITECTURE, ART, ETC.--Artist's Homes. No. 11. "Weirleigh."

Residence of Harrison Weir. Perspective and plans.

* * * * *

WHEAT AND WHEAT BREAD.

By H. MEGE-MOURIES.

In consequence of the interest that has been recently excited on the

subject of bread reform, we have, says the London _Miller_, translated the

interesting contribution of H. Mege-Mouries to the Imperial and Central

Society of Agriculture of France, and subsequently published in a separate

form in 1860, on "Wheat and Wheat Bread," with the illustration prepared

by the author for the contribution. The author says: "I repeat in this

pamphlet the principal facts put forth in the notes issued by me, and in

the reports furnished by Mr. Chevreul to the Academy of Science, from 1853

up to 1860."

The study of the structure of the wheat berry, its chemical composition,

its alimentary value, its preservation, etc., is not alone of interest to

science, agriculture, and industry, but it is worthy of attracting the

attention of governments, for this study, in its connection to political

economy, is bound up with the fate and the prosperity of nations. Wheat has

been cultivated from time immemorial. At first it was roughly crushed and

consumed in the form of a thick soup, or in cakes baked on an ordinary

hearth. Many centuries before the Christian era the Egyptians were

acquainted with the means of making fermented or leavened bread; afterwards

this practice spread into Greece, and it is found in esteem at Rome two

centuries B.C.; from Rome the new method was introduced among the Gauls,

and it is found to-day to exist almost the same as it was practiced at that

period, with the exception, of course, of the considerable improvements

introduced in the baking and grinding.

Since the fortunate idea was formed of transforming the wheat into bread,

this grain has always produced white bread, and dark or brown bread, from

which the conclusion was drawn that it must necessarily make white bread

and brown bread; on the other hand, the flours, mixed with bran, made a

brownish, doughy, and badly risen bread, and it was therefore concluded

that the bran, by its color, produced this inferior bread. From this error,

accepted as a truth, the most contradictory opinions of the most opposite

processes have arisen, which are repeated at the present day in the art of

separating as completely as possible all the tissues of the wheat, and of

extracting from the grain only 70 per cent of flour fit for making white

bread. It is, however, difficult for the observer to admit that a small

quantity of the thin yellow envelope can, by a simple mingling with the

crumb of the loaf, color it brown, and it is still more difficult to admit

that the actual presence of these envelopes can without decomposition

render bread doughy, badly raised, sticky, and incapable of swelling in

water. On the other hand, although some distinguished chemists deny or

exalt the nutritive properties of bran, agriculturists, taking practical

observation as proof, attribute to that portion of the grain a

physiological action which has nothing in common with plastic alimentation,

and prove that animals weakened by a too long usage of dry fodder, are

restored to health by the use of bran, which only seems to act by its

presence, since the greater portion of it, as already demonstrated by Mr.

Poggiale, is passed through with the excrement.

With these opinions, apparently so opposed, it evidently results that there

is an unknown factor at the bottom of the question; it is the nature of

this factor I wish to find out, and it was after the discovery that I

was able to explain the nature of brown bread, and its _role_ in the

alimentation of animals. We have then to examine the causes of the

production of brown bread, to state why white bread kills animals fed

exclusively on it, while bread mixed with bran makes them live. We have to

explain the phenomena of panification, the operations of grinding, and to

explain the means of preparing a bread more economical and more favorable

to health. To explain this question clearly and briefly we must first be

acquainted with the various substances forming the berry, their nature,

their position, and their properties. This we shall do with the aid of the

illustration given.

[Illustration: SECTION OF A GRAIN OF WHEAT MAGNIFIED.]

EXPLANATION OF DIAGRAM.

1.--Superficial Coating of the Epidermis, severed at the Crease of

the Kernel.

2.--Section of Epidermis, Averages of the Weight of the Whole Grain, 1/2 %.

3.--Epicarp, do. do. do. 1 %.

4.--Endocarp, do. do. do. 1 1/2 %.

5.--Testa or Episperm, do. do. do. 2 %.

6.--Embryo Membrane (with imaginary spaces in white on both sides

to make it distinct).

7.\ / Glutonous Cells \

8. > Endosperm < containing > do. do. 90 %.

9./ \ Farinaccous Matter /

ANATOMICAL STRUCTURE AND CHEMICAL COMPOSITION OF WHEAT.

The figure represents the longitudinal cut of a grain of wheat; it was made

by taking, with the aid of the microscope and of photography, the drawing

of a large quantity of fragments, which, joined together at last, produced

the figure of the entire cut. These multiplied results were necessary to

appreciate the insertion of the teguments and their nature in every part

of the berry; in this long and difficult work I have been aided by the

co-operation of Mr. Bertsch, who, as is known, has discovered a means of

fixing rapidly by photography any image from the microscope. I must state,

in the first place, that even in 1837 Mr. Payen studied and published the

structure and the composition of a fragment of a grain of wheat; that

this learned chemist, whose authority in such matters is known, perfectly

described the envelopes or coverings, and indicated the presence of various

immediate principles (especially of azote, fatty and mineral substances

which fill up the range of contiguous cells between them and the periphery

of the perisperm, to the exclusion of the gluten and the starchy granules),

as well as to the mode of insertion of the granules of starch in the gluten

contained in the cells, with narrow divisions from the perisperm, and in

such a manner that up to the point of working indicated by the figure 1

this study was complete. However, I have been obliged to recommence it, to

study the special facts bearing on the alimentary question, and I must say

that all the results obtained by Mr. Bertsch, Mr. Trecul, and myself agree

with those given by Mr. Payen.

ENVELOPES OF THE BERRY.

No. 1 represents a superficial side of the crease.

No. 2 indicates the epidermis or cuticle. This covering is extremely light,

and offers nothing remarkable; 100 lb. of wheat contain 1/2 lb. of it.

No. 3 indicates the epicarp. This envelope is distinguished by a double

row of long and pointed vessels; it is, like the first one, very light and

without action; 100 lb. of wheat contain 1 lb. of it.

No. 4 represents the endocarp, or last tegument of the berry; the

sarcocarp, which should be found between the numbers 2 and 3, no longer

exists, having been absorbed. The endocarp is remarkable by its row of

round and regular cells, which appear in the cut like a continuous string

of beads; 100 lb. of wheat contain 11/2 lb. of it.

These three envelopes are colorless, light, and spongy; their elementary

composition is that of straw; they are easily removed besides with the aid

of damp and friction. This property has given rise to an operation called

decortication, the results of which we shall examine later on from an

industrial point of view. The whole of the envelopes of the berry of wheat

amount to 3 lb. in 100 lb. of wheat.

ENVELOPES AND TISSUES OF THE BERRY PROPER.

No. 5 indicates the testa or episperm. This external tegument of the berry

is closer than the preceding ones; it contains in the very small cells

two coloring matters, the one of a palish yellow, the other of an orange

yellow, and according as the one or the other matter predominates, the

wheat is of a more or less intense yellow color; hence come all the

varieties of wheat known in commerce as white, reddish, or red wheats.

Under this tegument is found a very thin, colorless membrane, which, with

the testa or episperm, forms two per cent. of the weight of the wheat.

No. 6 indicates the embryous membrane, which is only an expansion of the

germ or embryo No. 10. This membrane is seen purposely removed from its

contiguous parts, so as to render more visible its form and insertions.

Under this tissue is found with the Nos. 7, 8, and 9, the endosperm or

perisperm, containing the gluten and the starch; soluble and insoluble

albuminoids, that is to say, the flour.

The endosperm and the embryous membrane are the most interesting parts of

the berry; the first is one of the depots of the plastic aliments, the

second contains agents capable of dissolving these aliments during the

germination, of determining their absorption in the digestive organs of

animals, and of producing in the dough a decomposition strong enough to

make dark bread. We shall proceed to examine separately these two parts of

the berry.

ENDOSPERM OR FLOURY PORTION, NOS. 7, 8, 9.

This portion is composed of large glutinous cells, in which the granules

of starch are found. The composition of these different layers offers a

particular interest; the center, No. 9, is the softest part; it contains

the least gluten and the most starch; it is the part which first pulverizes

under the stone, and gives, after the first bolting, the fine flour. As

this flour is poorest in gluten, it makes a dough with little consistency,

and incapable of making an open bread, well raised. The first layer, No.

8, which surrounds the center, produces small white middlings, harder and

richer in gluten than the center; it bakes very well, and weighs 20 lb. in

100, and it is these 20 parts in 100 which, when mixed with the 50 parts in

the center, form the finest quality flour, used for making white bread.

The layer No. 7, which surrounds the preceding one, is still harder and

richer in gluten; unfortunately in the reduction it becomes mixed with some

hundredth parts of the bran, which render it unsuitable for making bread

of the finest quality; it produces in the regrinding lower grade and

dark flours, together weighing 7 per cent. The external layer, naturally

adhering to the membrane, No. 6, becomes mixed in the grinding with bran,

to the extent of about 20 per cent., which renders it unsuitable even

for making brown bread; it serves to form the regrindings and the offals

destined for the nourishment of animals; this layer is, however, the

hardest, and contains the largest quantity of gluten, and it is by

consequence the most nutritive. We now see the endosperm increasing from

the center, formed of floury layers, which augment in richness in gluten,

in proportion as they are removed from the center. Now, as the flours make

more bread in proportion to the quantity of gluten they contain, and the

gluten gives more bread in proportion to its being more developed, or

having more consistence, it follows that the flour belonging to the parts

of the berry nearest the envelopes or coverings should produce the greatest

portion of bread, and this is what takes place in effect. The product of

the different layers of the endosperm is given below, and it will be seen

that the quantity of bread increases in a proportion relatively greater

than that of the gluten, which proves once more that the gluten of the

center or last formation has less consistence than that of the other layers

of older formation.

The following are the results obtained from the same wheat:

Gluten. Bread.

100 parts of flour in center contain.. 8 and produce 128

" " first layer " .. 9,2 " 136

" " second " " .. 11 " 140

" " external " " .. 13 " 145

On the whole, it is seen, according to the composition of the floury part

of the grain, that the berry contains on an average 90 parts in 100 of

flour fit for making bread of the first quality, and that the inevitable

mixing in of a small quantity of bran reduces these 90 to 70 parts with

the ordinary processes; but the loss is not alone there, for the foregoing

table shows that the best portion of the grain is rejected from the food

of man that brown or dark bread is made of flour of very good quality, and

that the first quality bread is made from the portion of the endosperm

containing the gluten in the smallest quantity and in the least developed

form.

This is a consideration not to be passed over lightly; assuredly the gluten

of the center contains as much azote as the gluten of the circumference,

but it must not be admitted in a general way that the alimentary power of

a body is in connection with the amount of azote it contains, and without

entering into considerations which would carry us too wide of the subject,

we shall simply state that if the flesh of young animals, as, for instance,

the calf, has a debilitating action, while the developed flesh of

full-grown animals--of a heifer, for example--has really nourishing

properties, although the flesh of each animal contains the same quantity of

azote, we must conclude that the proportion of elements is not everything,

and that the azotic or nitrogenous elements are more nourishing in

proportion as they are more developed. This is why the gluten of the layers

nearest the bran is of quite a special interest from the point of view of

alimentation and in the preparation of bread.

THE EMBRYO AND THE COATING OF THE EMBRYO.

To be intelligible, I must commence by some very brief remarks on the

tissues of vegetables. There are two sorts distinguished among plants;

some seem of no importance in the phenomena of nutrition; others, on the

contrary, tend to the assimilation of the organic or inorganic components

which should nourish and develop all the parts of the plant. The latter

have a striking analogy with ferments; their composition is almost similar,

and their action is increased or diminished by the same causes.

These tissues, formed in a state of repose in vegetables as in grain, have

special properties; thus the berry possesses a pericarp whose tissues

should remain foreign to the phenomena of germination, and these tissues

show no particularity worthy of remark, but the coating of the embryo,

which should play an active part, possesses, on the contrary, properties

that may be compared to those of ferments. With regard to these ferments,

I must further remark that I have not been able, nor am I yet able, to

express in formula my opinion of the nature of these bodies, but little

known as yet; I have only made use of the language mostly employed, without

wishing to touch on questions raised by the effects of the presence, and

by the more complex effects of living bodies, which exercise analogous

actions.

With these reservations I shall proceed to examine the tissues in the berry

which help toward the germination.

THE EMBRYO (10, see woodcut) is composed of the root of the plant, with

which we have nothing to do here. This root of the plant which is to grow

is embedded in a mass of cells full of fatty bodies. These bodies present

this remarkable particularity, that they contain among their elements

sulphur and phosphorus. When you dehydrate by alcohol 100 grammes of the

embryo of wheat, obtained by the same means as the membrane (a process

indicated later on), this embryo, treated with ether, produces 20 grammes

of oils composed elementarily of hydrogen, oxygen, carbon, azote, sulphur,

and phosphorus. This analysis, made according to the means indicated by M.

Fremy, shows that the fatty bodies of the embryo are composed like those of

the germ of an egg, like those of the brain and of the nervous system of

animals. It is necessary for us to stop an instant at this fact: in the

first place, because it proves that vegetables are designed to form the

phosphoric as well as the nitrogenous and ternary aliments, and finally,

because it indicates how important it is to mix the embryo and its

dependents with the bread in the most complete manner possible, seeing that

a large portion of these phosphoric bodies always become decomposed during

the baking.

COATING OF THE EMBRYO.--This membrane (6), which is only an expansion of

the embryo, surrounds the endosperm; it is composed of beautiful irregular

cubic cells, diminishing according as they come nearer to the embryo. These

cells are composed, first, of the insoluble cellular tissue; second,

of phosphate of chalk and fatty phosphoric bodies; third, of soluble

cerealine. In order to study the composition and the nature of this

tissue, it must be completely isolated, and this result is obtained in the

following manner.

The wheat should be damped with water containing 10 parts in 100 of

alcoholized caustic soda; at the expiration of one hour the envelopes of

the pericarp, and of the testa Nos. 2, 3, 4, 5, should be separated by

friction in a coarse cloth, having been reduced by the action of the alkali

to a pulpy state; each berry should then be opened separately to remove the

portion of the envelope held in the fold of the crease, and then all the

berries divided in two are put into three parts of water charged with

one-hundredth of caustic potash. This liquid dissolves the gluten, divides

the starch, and at the expiration of twenty-four hours the parts of the

berries are kneaded between the fingers, collected in pure water, and

washed until the water issues clear; these membranes with their embryos,

which are often detached by this operation, are cast into water acidulated

with one-hundredth of hydrochloric acid, and at the end of several hours

they should be completely washed. The product obtained consists of

beautiful white membranes, insoluble in alkalies and diluted acids, which

show under the microscope beautiful cells joined in a tissue following the

embryo, with which it has indeed a striking analogy in its properties and

composition. This membrane, exhausted by the alcohol and ether, gives, by

an elementary analysis, hydrogen, oxygen, carbon, and azote. Unfortunately,

under the action of the tests this membrane has been killed, and it no

longer possesses the special properties of active tissues. Among these

properties three may be especially mentioned:

1st. Its resistance to water charged with a mineral salt, such as sea salt

for instance

2d. Its action through its presence.

3d. Its action as a ferment.

The action of saltwater is explained as follows: When the berry is plunged

into pure water it will be observed that the water penetrates in the course

of a few hours to the very center of the endosperm, but if water charged

or saturated with sea salt be used, it will be seen that the liquid

immediately passes through the teguments Nos. 2, 3, 4, and 5, and stops

abruptly before the embryo membrane No. 6, which will remain quite dry and

brittle for several days, the berry remaining all the time in the

water. Should the water penetrate further after several days, it can be

ascertained that the entrance was gained through the part No 10 free of

this tissue, and this notwithstanding the cells are full of fatty bodies.

This membrane alone produces this action, for if the coatings Nos. 2, 3, 4,

and 5 be removed, the resistance to the liquid remains the same, while if

the whole, or a portion of it, be divided, either by friction between two

millstones or by simple incisions, the liquid penetrates the berry within

a few hours. This property is analogous to that of the radicules of roots,

which take up the bodies most suitable for the nourishment of the plant. It

proves, besides, that this membrane, like all those endowed with life, does

not obey more the ordinary laws of permeability than those of chemical

affinity, and this property can be turned to advantage in the preservation

of grain in decortication and grinding.

To determine the action of this tissue through its presence, take 100

grammes of wheat, wash it and remove the first coating by decortication;

then immerse it for several hours in lukewarm water, and dry afterwards in

an ordinary temperature. It should then be reduced in a small coffee mill,

the flour and middlings separated by sifting and the bran repassed through

a machine that will crush it without breaking it; then dress it again, and

repeat the operation six times at least. The bran now obtained is composed

of the embryous membrane, a little flour adhering to it, and some traces

of the teguments Nos. 2, 3, 4, and 5. This coarse tissue-weighs about 14

grammes, and to determine its action through its presence, place it in 200

grammes of water at a temperature of 86 deg.; afterwards press it. The liquid

that escapes contains chiefly the flour and cerealine. Filter this liquid,

and put it in a test glass marked No. 1, which will serve to determine the

action of the cerealine.

The bran should now be washed until the water issues pure, and until it

shows no bluish color when iodized water and sulphuric acid are added; when

the washing is finished the bran swollen by the water is placed under a

press, and the liquid extracted is placed, after being filtered, in a test

tube. This test tube serves to show that all cerealine has been removed

from the blades of the tissue. Finally, these small blades of bran, washed

and pressed, are cast, with 50 grammes of lukewarm water, into a test tube,

marked No. 3; 100 grammes of diluted starch to one-tenth of dry starch

are then added in each test tube, and they are put into a water bath at

a temperature of 104 deg. Fahrenheit, being stirred lightly every fifteen

minutes. At the expiration of an hour, or at the most an hour and a half,

No. 1 glass no longer contains any starch, as it has been converted into

dextrine and glucose by the cerealine, and the iodized water only produces

a purple color. No. 2 glass, with the same addition, produces a bluish

color, and preserves the starch intact, which proves that the bran was well

freed from the cerealine contained. No. 3 glass, like No. 1, shows a purple

coloring, and the liquid only contains, in place of the starch, dextrine

and glucose, _i. e_, the tissue has had the same action as the cerealine

deprived of the tissue, and the cerealine as the tissue freed from

cerealine. The same membrane rewashed can again transform the diluted

starch several times. This action is due to the presence of the embryous

membrane, for after four consecutive operations it still preserves its

original weight. As regards the remains of the other segments, they have

no influence on this phenomenon, for the coating Nos. 2, 3, 4, and 5,

separated by the water and friction, have no action whatever on the diluted

starch. Besides its action through its presence, which is immediate,

the embryous membrane may also act as a ferment, active only after a

development, varying in duration according to the conditions of temperature

and the presence or absence of ferments in acting.

I make a distinction here as is seen, between the action through being

present, and the action of real ferments, but it is not my intention to

approve or disapprove of the different opinions expressed on this subject.

I make use of these expressions only to explain more clearly the phenomena

I have to speak of, for it is our duty to bear in mind that the real

ferments only act after a longer or shorter period of development, while,

on the other hand, the effects through presence are immediate.

I now return to the embryous membrane. Various causes increase or decrease

the action of this tissue, but it may be said in general that all the

agents that kill the embryous membrane will also kill the cerealine. This

was the reason why I at first attributed the production of dark bread

exclusively to the latter ferment, but it was easy to observe that during

the baking, decompositions resulted at over 158 deg. Fah., while the cerealine

was still coagulated, and that bread containing bran, submitted to 212 deg. of

heat, became liquefied in water at 104 deg.. It was now easy to determine

that dark flours, from which the cerealine had been removed by repeated

washings, still produced dark bread. It was at this time, in remembering

my experiences with organic bodies, I determined the properties of the

insoluble tissue, deprived of the soluble cerealine, with analogous

properties, but distinguished not alone by its solid organization and state

of insolubility, but also by its resistance to heat, which acts as on

yeast. There exists, in reality, I repeat, a resemblance between the

embryous membrane and the yeast; they have the same immediate composition;

they are destroyed by the same poisons, deadened by the same temperatures,

annihilated by the same agents, propagated in an analogous manner, and

it might be said that the organic tissues endowed with life are only an

agglomeration of fixed cells of ferments. At all events, when the blades of

the embryous membrane, prepared as already stated, are exposed to a water

bath at 212 deg., this tissue, in contact with the diluted starch, produces

the same decomposition; the contact, however, should continue two or three

hours in place of one. If, instead of placing these membranes in the water

bath, they are enveloped in two pounds of dough, and this dough put in the

oven, after the baking the washed membranes produce the same results, which

especially proves that this membrane can support a temperature of 212 deg. Fah.

without disorganization. We shall refer to this property in speaking of the

phenomena of panification.

CEREALINE.--The cells composing the embryous membrane contain, as already

stated, the cerealine, but after the germination they contain cerealine and

diastase, that is to say, a portion of the cerealine changed into diastase,

with which it has the greatest analogy. It is known how difficult it is to

isolate and study albuminous substances. The following is the method of

obtaining and studying cerealine. Take the raw embryous membrane, prepared

as stated, steep it for an hour in spirits of wine diluted with twice its

volume of water, and renew this liquid several times until the dextrine,

glucose, coloring matters, etc., have been completely removed. The

membranes should now be pressed and cast into a quantity of water

sufficient to make a fluid paste of them, squeeze out the mixture,

filter the liquid obtained, and this liquid will contain the cerealine

sufficiently pure to be studied in its effects. Its principal properties

are: The liquid evaporated at a low temperature produces an amorphous,

rough mass nearly colorless, and almost entirely soluble in distilled

water; this solution coagulates between 158 deg. and 167 deg. Fah., and the

coagulum is insoluble in acids and weak alkalies; the solution is

precipitated by all diluted acids, by phosphoric acid at all the degrees of

hydration, and even by a current of carbonic acid. All these precipitates

redissolve with an excess of acid, sulphuric acid excepted. Concentrated

sulphuric acid forms an insoluble downy white precipitate, and the

concentrated vegetable acids, with the exception of tannic acid, do not

determine any precipitate. Cerealine coagulated by an acid redissolves in

an excess of the same acid, but it has become dead and has no more action

on the starch. The alkalies do not form any precipitate, but they kill the

cerealine as if it had been precipitated The neutral rennet does not make

any precipitate in a solution of cerealine--5 centigrammes of dry cerealine

transform in twenty-five minutes 10 grammes of starch, reduced to a paste

by 100 grammes of water at 113 deg. Fah. It will be seen that cerealine has a

grand analogy with albumen and legumine, but it is distinguished from them

by the action of the rennet, of the heat of acids, alcohol, and above all

by its property of transforming the starch into glucose and dextrine.

It may be said that some albuminous substances have this property, but it

must be borne in mind that these bodies, like gluten, for example, only

possess it after the commencement of the decomposition. The albuminous

matter approaching nearest to cerealine is the diastase, for it is only a

transformation of the cerealine during the germination, the proof of which

may be had in analyzing the embryous membrane, which shows more diastase

and less cerealine in proportion to the advancement of the germination: it

differs, however, from the diastase by the action of heat, alcohol, etc.

It is seen that in every case the cerealine and the embryous membrane

act together, and in an analogous manner; we shall shortly examine their

effects on the digestion and in the phenomena of panification.

PHOSPHATE OF CALCIUM.--Mr. Payen was the first to make the observation

that the greatest amount of phosphate of chalk is found in the teguments

adjoining the farinaceous or floury mass. This observation is important

from two points of view; in the first place, it shows us that this mineral

aliment, necessary to the life of animals, is rejected from ordinary bread;

and in the next place, it brings a new proof that phosphate of chalk is

found, and ought to be found, in everyplace where there are membranes

susceptible of exercising vital functions among animals as well as

vegetables.

Phosphate of chalk is not in reality (as I wished to prove in another work)

a plastic matter suitable for forming bones, for the bones of infants are

three times more solid than those of old men, which contain three times

as much of it. The quantity of phosphate of chalk necessary to the

constitution of animals is in proportion to the temperature of those

animals, and often in the inverse ratio of the weight of their bones, for

vegetables, although they have no bones, require phosphate of chalk. This

is because this salt is the natural stimulant of living membranes, and the

bony tissue is only a depot of phosphate of chalk, analogous to the adipose

tissue, the fat of which is absorbed when the alimentation coming from the

exterior becomes insufficient. Now, as we know all the parts constituting

the berry of wheat, it will be easy to explain the phenomena of

panification, and to conclude from the present moment that it is not

indifferent to reject from the bread this embryous membrane where the

agents of digestion are found, viz., the phosphoric bodies and the

phosphate of chalk.

* * * * *

THE ORIGIN OF NEW PROCESS MILLING.

The following article was written by Albert Hoppin, editor of the

_Northwestern Miller_, at the request of Special Agent Chas. W. Johnson,

and forms a part of his report to the census bureau on the manufacturing

industries of Minneapolis.

"The development of the milling industry in this city has been so

intimately connected with the growth and prosperity of the city itself,

that the steps by which the art of milling has reached its present high

state of perfection are worthy of note, especially as Minneapolis may

rightly claim the honor of having brought the improvements, which have

within the last decade so thoroughly revolutionized the art of making

flour, first into public notice, and of having contributed the largest

share of capital and inventive skill to their full development. So much is

this the case that the cluster of mills around the Falls of St. Anthony is

to-day looked upon as the head-center of the milling industry not only of

this country, but of the world. An exception to this broad statement may

possibly be made in favor of the city of Buda Pest, in Austro-Hungary, from

the leading mills in which the millers in this country have obtained many

valuable ideas. To the credit of American millers and millwrights it must,

however, be said that they have in all cases improved upon the information

they have thus obtained.

"To rightly understand the change that has taken place in milling methods

during the last ten years, it is necessary to compare the old way with the

new, and to observe wherein they differ. From the days of Oliver Evans, the

first American mechanic to make any improvement in milling machinery, until

1870, there was, if we may except some grain cleaning or smut machines,

no very strongly marked advance in milling machinery or in the methods of

manufacturing flour. It is true that the reel covered with finely-woven

silk bolting cloth had taken the place of the muslin or woolen covered hand

sieve, and that the old granite millstones have given place to the French

burr; but these did not affect the essential parts of the _modus operandi_,

although the quality of the product was, no doubt, materially improved. The

processes employed in all the mills in the United States ten years ago were

identical, or very nearly so, with those in use in the Brandywine Mills in

Evans's day. They were very simple, and may be divided into two distinct

operations.

"First. Grinding (literally) the wheat.

"Second. Bolting or separating the flour or interior portion of the berry

from the outer husk, or bran. It may seem to some a rash assertion, but

this primitive way of making flour is still in vogue in over one-half of

the mills of the United States. This does not, however, affect the truth of

the statement that the greater part of the flour now made in this country

is made on an entirely different and vastly-improved system, which has come

to be known to the trade as the new process.

"In looking for a reason for the sudden activity and spirit of progress

which had its culmination in the new process, the character of the

wheat raised in the different sections of the Union must be taken into

consideration. Wheat may be divided into two classes, spring and winter,

the latter generally being more starchy and easily pulverized, and at the

same time having a very tough bran or husk, which does not readily crumble

or cut to pieces in the process of grinding. It was with this wheat that

the mills of the country had chiefly to do, and the defects of the old

system of milling were not then so apparent. With the settlement of

Minnesota, and the development of its capacities as a wheat-growing State,

a new factor in the milling problem was introduced, which for a time bid

fair to ruin every miller who undertook to solve it. The wheat raised in

this State was, from the climatic conditions, a spring wheat, hard in

structure and having a thin, tender, and friable bran. In milling this

wheat, if an attempt was made to grind it as fine as was then customary to

grind winter wheat, the bran was ground almost as fine as the flour, and

passed as readily through the meshes of the bolting reels or sieves,

rendering the flour dark, specky, and altogether unfit to enter the Eastern

markets in competition with flour from the winter wheat sections. On the

other hand, if the grinding was not so fine as to break up the bran,

the interior of the berry being harder to pulverize, was not rendered

sufficiently fine, and there remained after the flour was bolted out a

large percentage of shorts or middlings, which, while containing the

strongest and best flour in the berry, were so full of dirt and impurities

as to render them unfit for any further grinding except for the very lowest

grade of flour, technically known as 'red dog.' The flour produced from

the first grinding was also more or less specky and discolored, and, in

everything but strength, inferior to that made from winter wheat, while the

'yield' was so small, or, in other words, the amount of wheat which it took

to make a barrel of flour was so large, that milling in Minnesota and other

spring wheat sections was anything but profitable.

"The problem which ten years since confronted the millers of this city was

how to obtain from the wheat which they had to grind a white, clear flour,

and to so increase the yield as to leave some margin for profit. The first

step in the solution of this problem was the invention by E. N. La Croix

of the machine which has since been called the purifier, which removed the

dirt and light impurities from the refuse middlings in the same manner that

dust and chaff are removed from wheat by a fanning mill. The middlings thus

purified were then reground, and the result was a much whiter and cleaner

flour than it had been possible to obtain under the old process of low

close grinding. This flour was called 'patent' or 'fancy,' and at once took

a high position in the market. The first machine built by La Croix was

immediately improved by George T. Smith, and has since then been the

subject of numberless variations, changes, and improvements; and over the

principles embodied in its construction there has been fought one of the

longest and most bitter battles recorded in the annals of patent litigation

in this country. The purifier is to-day the most important machine in use

in the manufacture of flour in this country, and may with propriety be

called the corner-stone of new process milling. The earliest experiments in

its use in this country were made in what was then known as the 'big mill'

in this city, owned by Washburn, Stephens & Co., and now known as the

Washburn Mill B.

"The next step in the development of the new process, also originating

in Minneapolis, was the abandonment of the old system of cracking the

millstone, and substituting in its stead the use of smooth surfaces on the

millstones, thus in a large measure doing away with the abrasion of the

bran, and raising the quality of the flour produced at the first grinding.

So far as we know, Mr. E. R. Stephens, a Minneapolis miller, then employed

in the mill owned by Messrs. Pillsbury, Crocker & Fish, and now a member of

the prominent milling firm of Freeman & Stephens, River Falls, Wisconsin,

was the first to venture on this innovation. He also first practiced the

widening of the furrows in the millstones and increasing their number, thus

adding largely to the amount of middlings made at the first grinding, and

raising the percentage of patent flour. He was warmly supported by Amasa K.

Ostrander, since deceased, the founder and for a number of years the editor

of the _North-Western Miller_, a trade newspaper. The new ideas were for a

time vigorously combated by the millers, but their worth was so plain that

they were soon adopted, not only in Minneapolis, but by progressive millers

throughout the country. The truth was the 'new process' in its entirety,

which may be summarized in four steps--first, grinding or, more properly,

granulating the berry; second, bolting or separating the 'chop' or meal

into first flour, middlings, and bran; third, purifying the middlings,

fourth, regrinding and rebolting the middlings to produce the higher grade,

or 'patent' flour. This higher grade flour drove the best winter wheat

flours out of the Eastern markets, and placed milling in Minnesota upon a

firm basis. The development of the 'new process' cannot be claimed by any

one man. Hundreds of millers all over the country have contributed to its

advance, but the millers of Minneapolis have always taken the lead.

"Within the past two or three years what may be distinctively called the

'new process' has, in the mills of Minneapolis and some few other leading

mills in the country, been giving place to a new system, or rather, a

refinement of the processes above described. This latest system is known to

the trade as the 'gradual reduction' or high-grinding system, as the 'new

process' is the medium high-grinding system, and the old way is the low or

close grinding system. In using the gradual reduction in making flour the

millstones are abandoned, except for finishing some of the inferior grades

of flour, and the work is done by means of grooved and plain rollers, made

of chilled iron or porcelain. In some cases disks of chilled iron, suitably

furrowed, are used, and in others concave mills, consisting of a cylinder

running against a concave plate. In Minneapolis the chilled iron rolls take

the precedence of all other means.

"The system of gradual reduction is much more complicated than either of

those which preceded it; but the results obtained are a marked advance over

the 'new process.' The percentage of high-grade flour is increased, several

grades of different degrees of excellence being produced, and the yield

is also greater from a given quantity of wheat. The system consists in

reducing the wheat to flour, not at one operation, as in the old system,

nor in two grindings, as in the 'new process,' but in several successive

reductions, four, five, or six, as the case may be. The wheat is first

passed through a pair of corrugated chilled iron rollers, which merely

split it open along the crease of the berry, liberating the dirt which lies

in the crease so that it can be removed by bolting. A very small percentage

of low-grade flour is also made in this reduction. After passing through

what is technically called a 'scalping reel' to remove the dirt and flour,

the broken wheat is passed through a second set of corrugated rollers, by

which it is further broken up, and then passes through a second separating

reel, which removes the flour and middlings. This operation is repeated

successively until the flour portion of the berry is entirely removed from

the bran, the necessary separation being made after each reduction. The

middlings from the several reductions are passed through the purifiers,

and, after being purified, are reduced to flour by successive reductions

on smooth iron or porcelain rollers. In some cases, as stated above, iron

disks and concave mills are substituted for the roller mill, but the

operation is substantially the same. One of the principal objects sought to

be attained by this high-grinding system is to avoid all abrasion of the

bran, another is to take out the dirt in the crease of the berry at the

beginning of the process, and still another to thoroughly free the bran

from flour, so as to obtain as large a yield as possible. Incidental to the

improved methods of milling, as now practiced in this country, is a marked

improvement in the cleaning of the grain and preparing it for flouring. The

earliest grain-cleaning machine was the 'smutter,' the office of which was

to break the smut balls, and scour the outside of the bran to remove any

adhering dust, the scouring machine being too harsh in its action, breaking

the kernels of wheat, and so scratching and weakening the bran that it

broke up readily in the grinding. The scouring process was therefore

lessened, and was followed by brush machines, which brushed the dirt,

loosened up and left by the scourer, from the berry. Other machines for

removing the fuzzy and germ ends of the berry have also been introduced,

and everything possible is done to free the grain from extraneous

impurities before the process of reduction is commenced. In all the minor

details of the mill there has been the same marked change, until the modern

merchant mill of to-day no more resembles that of twenty-five years ago

than does the modern cotton mill the old-fashioned distaff. The change has

extended into the winter wheat sections, and no mill in the United States

can hope to hold its place in the markets unless it is provided with the

many improvements in machinery and processes which have resulted from the

experiments begun in this city only ten years since, and which have

made the name of Minneapolis and the products of her many mills famous

throughout the world. The relative merits of the flour made by the new

process and the old have been warmly discussed, but the general verdict

of the great body of consumers is that the patent or new process flour is

better in every way for bread making purposes, being clearer, whiter, more

evenly granulated, and possessing more strength. Careful chemical analysis

has confirmed this. As between winter and spring wheat flours made by the

new process and gradual reduction systems, it maybe remarked that the

former contain more starch and are whiter in color, while the latter,

having more gluten, excel in strength. In milling all varieties of wheat,

whether winter or spring, the new processes are in every way superior to

the old, and, in aiding their inception and development, the millers of

Minneapolis have conferred a lasting benefit on the country.

"Minneapolis, Minn., December 1, 1880."

THE MILLING STRUCTURES AND MACHINERY.

Mr. Johnson added the following, showing the present status of the milling

industry in Minneapolis:

"The description of the process of the manufacture of flour so well

given above, conveys no idea of the extent and magnitude of the milling

structures, machinery, and buildings employed in the business. Many of the

leading millers and millwrights have personally visited and studied the

best mills in England, France, Hungary, and Germany, and are as familiar

with their theory, methods, and construction as of their own, and no

expense or labor has been spared in introducing the most approved features

of the improvements in the foreign mills. Experimenting is constantly going

on, and the path behind the successful millers is strewn with the wrecks of

failures. A very large proportion of the machinery is imported, though the

American machinists are fast outstripping their European rivals in the

quality and efficiency of the machinery needed for the new mills constantly

going up.

"There are twenty-eight of these mills now constructed and at work,

operating an equivalent of 412 runs of stone, consuming over sixteen

million bushels of wheat, and manufacturing over three million barrels of

flour annually. Their capacities range from 250 to 1,500 barrels of flour

per day. Great as these capacities are, there is now one in process of

construction, the Pillsbury A Mill, which at the beginning of the harvest

of 1881 will have a capacity of 4,000 barrels daily. The Washburn A Mill,

whose capacity is now 1,500 barrels, is being enlarged to make 8,500

barrels a day, and the Crown Roller Mill, owned by Christian Bros. & Co.,

is also being enlarged to produce 3,000 barrels a day. The largest mill in

Europe has a daily capacity of but 2,800 barrels, and no European mill is

fitted with the exquisite perfection of machinery and apparatus to be found

in the mills of this city.

"The buildings are mainly built of blue limestone, found so abundant in the

quarries of this city, range and line work, and rest on the solid ledge.

The earlier built mills are severely plain, but the newer ones are greatly

improved by the taste of the architect, and are imposing and beautiful in

appearance."

DIRECT FOREIGN TRADE.

The flour of Minneapolis, holding so high a rank in the markets of the

world, is always in active demand, especially the best grades, and brings

from $1.00 to $1.60 per barrel more than flour of the best qualities of

southern, eastern, or foreign wheat. During the year nearly a million

barrels were shipped direct to European and other foreign ports, on through

bills of lading, and drawn for by banks here having special foreign

exchange arrangements, at sight, on the day of shipment. This trade

is constantly increasing, and the amount of flour handled by eastern

commission men is decreasing in proportion.

* * * * *

Referring to the foregoing, the following letter from Mr. Geo. T. Smith to

the editor of the _London Miller_ is of interest:

SIR: I find published in the _North-western Miller_ of December 24, 1880,

extracts from an article on the origin of new process milling, prepared by

Albert Hoppin, Esq., editor of the above-named journal, for the use of one

of the statistical divisions of the United States census, which is so at

variance, in at least one important particular, with the facts set forth in

the paper read by me before the British and Irish millers, at their meeting

in May last, that I think I ought to take notice of its statements, more

especially as the _North-Western Miller_ has quite a circulation on this

side of the water.

As stated in the paper read by me above-mentioned, I was engaged in

February, 1871, by Mr. Christian, who was then operating the "big," or

Washburn Mill at Minneapolis, to take charge of the stones in that mill. At

this time Mr. Christian was very much interested in the improvement of the

quality of his flour, which in common with the flour of Minneapolis mills,

without exception, was very poor indeed. For some time previous to this I

had insisted to him most strenuously that the beginning of any improvement

must be found in smooth, true, and well balanced stones, and it was because

he was at last convinced that my ideas were at least worthy of a practical

test I was placed in charge of his mill. Nearly two months were consumed in

truing and smoothing the stone, as all millers in the mill had struck

at once when they became acquainted with the character of the changes I

proposed to make.

I remained with Mr. Christian until the latter part of 1871, in all about

eight months. During this time the flour from the Washburn Mill attained a

celebrity that made it known and sought after all over the United States.

It commanded attention as an event of the very greatest importance, from

the fact that it was justly felt that if a mill grinding spring wheat

exclusively was capable of producing a flour infinitely superior in every

way to the best that could be made from the finest varieties of winter

wheats, the new North Western territory, with its peculiar adaptation to

the growing of spring grain, and its boundless capacity for production,

must at once become one of the most important sections of the country.

Mr. Christian's appreciation of the improvements I had made in his mill

was attested by doubly-locked and guarded entrances, and by the stringent

regulations which were adopted to prevent any of his employes carrying

information with regard to the process to his competitors.

All this time other Minneapolis mills were doing such work and only such as

they had done previously. Ought not the writer of an article on the origin

of new process milling--which article is intended to become historical, and

to have its authenticity indorsed by the government--to have known whether

Mr. Christian, in the Washburn Mill, did or did not make a grade of

flour which has hardly been excelled since for months before any other

Minneapolis mill approached his product in any degree? And should he not

be well enough acquainted with the milling of that period--1871-2--to know

that such results as were obtained in the Washburn Mill could only be

secured by the use of _smooth_ and _true_ stones? Mr. Stephens--whom I

shall mention again presently--did _not_ work in the Washburn Mill while I

was in charge of it.

In the fall of 1871 I entered into a contract with Mr. C. A. Pillsbury,

owner of the Taylor Mill and senior partner in the firm by whom the

Minneapolis Mill was operated, to put both those mills into condition to

make the same grade of flour as Mr. Christian was making. The consideration

in the contract was 5,000 dols. At the above mills I met to some extent the

same obstruction in regard to millers striking as had greeted me at Mr.

Christian's mill earlier in the year; but among those who did not strike at

the Minneapolis Mill I saw, for the first time, Mr. Stephens--then still

in his apprenticeship--whom Mr. Hoppin declares to have been, "so far as I

know," the first miller to use smooth stones. If Mr. Hoppin is right in his

assertion, perhaps he will explain why, during the eight months I was at

the Washburn Mill, Mr. Stephens did not make a corresponding improvement

in the product of the Minneapolis Mill. That he did not do this is amply

proved by the fact of Mr. Pillsbury giving me 5,000 dols. to introduce

improvements into his mills, when, supposing Mr. Hoppin's statement to

be correct, he might have had the same alterations carried out under Mr.

Stephens' direction at a mere nominal cost. As a matter of fact, the stones

in both the Taylor and Minneapolis Mills were as rough as any in the

Washburn Mill when I took charge of them.

Thus it appears (1) that the flour made by the mill in which Stephens was

employed was not improved in quality, while that of the Washburn Mill,

where he was not employed, became the finest that had ever been made in the

United States at that time. That (2) the owner of the mill in which Mr.

Stephens was employed, as he was not making good flour, engaged me at a

large cost to introduce into his mills the alterations by which only, both

Mr. Hoppin and myself agree, could any material improvement in the milling

of that period be effected, .viz., smooth, true, and well-balanced

stones.--GEO. T. SMITH.

* * * * *

For breachy animals do not use barbed fences. To see the lacerations that

these fences have produced upon the innocent animals should be sufficient

testimony against them. Many use pokes and blinders on cattle and goats,

but as a rule such things fail. The better way is to separate breachy

animals from the lot, as others will imitate their habits sooner or later,

and then, if not curable, _sell them_.

* * * * *

THE GUENON MILK-MIRROR.

The name of the simple Bordeaux peasant is, and should be, permanently

associated with his discovery that the milking qualities of cows were, to a

considerable extent, indicated by certain external marks easily observed.

We had long known that capacious udders and large milk veins, combined with

good digestive capacity and a general preponderance of the alimentary over

the locomotive system, were indications that rarely misled in regard to the

ability of a cow to give much milk; but to judge of the amount of milk a

cow would yield, and the length of time she would hold out in her flow, two

or three years before she could be called a cow--this was Guenon's great

accomplishment, and the one for which he was awarded a gold medal by the

Agricultural Society of his native district. This was the first of many

honors with which he was rewarded, and it is much to say that no committee

of agriculturists who have ever investigated the merits of the system

have ever spoken disparagingly of it. Those who most closely study it,

especially following Guenon's original system, which has never been

essentially improved upon, are most positive in regard to its truth,

enthusiastic in regard to its value.

The fine, soft hair upon the hinder part of a cow's udder for the most part

turns upward. This upward-growing hair extends in most cases all over that

part of the udder visible between the hind legs, but is occasionally marked

by spots or mere lines, usually slender ovals, in which the hair grows

down. This tendency of the hair to grow upward is not confined to the udder

proper; but extends out upon the thighs and upward to the tail. The edges

of this space over which the hair turns up are usually distinctly marked,

and, as a rule, the larger the area of this space, which is called the

"mirror" or "escutcheon," the more milk the cow will give, and the longer

she will continue in milk.

[Illustration: ESCUTCHEON OF THE JERSEY BULL-CALF, GRAND MIRROR, 4,904.]

That portion of the escutcheon which covers the udder and extends out on

the inside of each thigh, has been designated as the udder or mammary

mirror; that which runs upward towards the setting on of the tail, the

rising or placental mirror. The mammary mirror is of the greater value,

yet the rising mirror is not to be disregarded. It is regarded of especial

moment that the mirror, taken as a whole, be symmetrical, and especially

that the mammary mirror be so; yet it often occurs that it is far

otherwise, its outline being often very fantastical--exhibiting deep

_bays_, so to speak, and islands of downward growing hair. There are also

certain "ovals," never very large, yet distinct, which do not detract from

the estimated value of an escutcheon; notably those occurring on the lobes

of the udder just above the hind teats. These are supposed to be points of

value, though for what reason it would be hard to tell, yet they do occur

upon some of the very best milch cows, and those whose mirrors correspond

most closely to their performances.

Mr. Guenon's discovery enables breeders to determine which of their calves

are most promising, and in purchasing young stock it affords indications

which rarely fail as to their comparative milk yield. These indications

occasionally prove utterly fallacious, and Mr. Guenon gives rules for

determining this class, which he calls "bastards," without waiting for them

to fail in their milk. The signs are, however, rarely so distinct that one

would be willing to sell a twenty-quart cow, whose yield confirmed the

prediction of her mirror at first calving, because of the possibility of

the going dry in two months, or so, as indicated by her bastardy marks.

It is an interesting fact that the mirrors of bulls (which are much like

those of cows, but less extensive in every direction) are reflected in

their daughters. This gives rise to the dangerous custom of breeding for

mirrors, rather than for milk. What the results may be after a few years it

is easy to see. The mirror, being valued for its own sake--that is, because

it sells the heifers--will be likely to lose its practical significance and

value as a _milk_ mirror.

We have a striking photograph of a young Jersey bull, the property of Mr.

John L. Hopkins, of Atlanta, Ga., and called "Grand Mirror." This we have

caused to be engraved and the mirror is clearly shown. A larger mirror is

rarely seen upon a bull. We hope in a future number to exhibit some cows'

mirrors of different forms and degrees of excellence.--_Rural New Yorker_.

* * * * *

TWO GOOD LAWN TREES.

The negundo, or ash-leaved maple, as it is called in the Eastern States,

better known at the West as a box elder, is a tree that is not known as

extensively as it deserves. It is a hard maple, that grows as rapidly as

the soft maple; is hardy, possesses a beautiful foliage of black green

leaves, and is symmetrical in shape. Through eastern Iowa I found it

growing wild, and a favorite tree with the early settlers, who wanted

something that gave shade and protection to their homes quickly on their

prairie farms. Brought east, its growth is rapid, and it loses none of the

characteristics it possessed in its western home. Those who have planted it

are well pleased with it. It is a tree that transplants easily, and I know

of no reason why it should not be more popular.

For ornamental lawn planting, I give pre-eminence to the cut-leaf weeping

birch. Possessing all the good qualities of the white birch, it combines

with them a beauty and delicate grace yielded by no other tree. It is an

upright grower, with slender, drooping branches, adorned with leaves of

deep rich green, each leaf being delicately cut, as with a knife, into

semi-skeletons. It holds its foliage and color till quite late in the fall.

The bark, with age, becomes white, resembling the white birch, and the

beauty of the tree increases with its age. It is a free grower, and

requires no trimming. Nature has given it a symmetry which art cannot

improve.

H.T.J.

* * * * *

CUTTING SODS FOR LAWNS.

I am a very good sod layer, and used to lay very large lawns--half to

three-quarters of an acre. I cut the sods as follows: Take a board eight to

nine inches wide, four, five, or six feet long, and cut downward all around

the board, then turn the board over and cut again alongside the edge of the

board, and so on as many sods as needed. Then cut the turf with a sharp

spade, all the same lengths. Begin on one end, and roll together. Eight

inches by five feet is about as much as a man can handle conveniently. It

is very easy to load them on a wagon, cart, or barrow, and they can be

quickly laid. After laying a good piece, sprinkle a little with a watering

pot, if the sods are dry; then use the back of the spade to smooth them a

little. If a very fine effect is wanted, throw a shovelful or two of good

earth over each square yard, and smooth it with the back of a steel rake.

F.H.

* * * * *

[COUNTRY GENTLEMAN.]

HORTICULTURAL NOTES.

The Western New York Society met at Rochester, January 26.

_New Apples, Pears, Grapes, etc._--Wm. C Barry, secretary of the committee

on native fruits, read a full report. Among the older varieties of the

apple, he strongly recommended Button Beauty, which had proved so excellent

in Massachusetts, and which had been equally successful at the Mount

Hope Nurseries at Rochester; the fine growth of the tree and its great

productiveness being strongly in its favor. The Wagener and Northern Spy

are among the finer sorts. The Melon is one of the best among the older

sorts; the fruit being quite tender will not bear long shipment, but it

possesses great value for home use, and being a poor grower, it had been

thrown aside by nurserymen and orchardists. It should be top-grafted on

more vigorous sorts. The Jonathan is another fine sort of slender growth,

which should be top-grafted.

Among new pears, Hoosic and Frederic Clapp were highly commended for their

excellence. Some of the older peaches of fine quality had of late been

neglected, and among them Druid Hill and Brevoort.

Among the many new peaches highly recommended for their early ripening,

there was great resemblance to each other, and some had proved earlier than

Alexander.

Of the new grapes, Lady Washington was the most promising. The Secretary

was a failure. The Jefferson was a fine sort, of high promise.

Among the new white grapes, Niagara, Prentiss, and Duchess stood

pre-eminent, and were worthy of the attention of cultivators. The

Vergennes, from Vermont, a light amber colored sort, was also highly

commended. The Elvira, so highly valued in Missouri, does not succeed well

here. Several facts were stated in relation to the Delaware grape, showing

its reliability and excellence.

Several new varieties of the raspberry were named, but few of them were

found equal to the best old sorts. If Brinckle's Orange were taken as a

standard for quality, it would show that none had proved its equal in fine

quality. The Caroline was like it in color, but inferior in flavor. The New

Rochelle was of second quality. Turner was a good berry, but too soft for

distant carriage.

Of the many new strawberries named, each seemed to have some special

drawback. The Bidwell, however, was a new sort of particular excellence,

and Charles Downing thinks it the most promising of the new berries.

_Discussion on Grapes._--C. W. Beadle, of Ontario, in allusion to Moore's

Early grape, finds it much earlier than the Concord, and equal to it in

quality, ripening even before the Hartford. S. D. Willard, of Geneva,

thought it inferior to the Concord, and not nearly so good as the Worden.

The last named was both earlier and better than the Concord, and sold for

seven cents per pound when the Concord brought only four cents. C. A.

Green, of Monroe County, said the Lady Washington proved to be a very fine

grape, slightly later than Concord. P. L. Perry, of Canandaigua, said

that the Vergennes ripens with Hartford, and possesses remarkable keeping

qualities, and is of excellent quality and free from pulp. He presented

specimens which had been kept in good condition. He added, in relation to

the Worden grape, that some years ago it brought 18 cents per pound in New

York when the Concord sold three days later for only 8 cents. [In such

comparisons, however, it should be borne in mind that new varieties usually

receive more attention and better culture, giving them an additional

advantage.]

The Niagara grape received special attention from members. A. C. Younglove,

of Yates County, thought it superior to any other white grape for its many

good qualities. It was a vigorous and healthy grower, and the clusters were

full and handsome. W. J. Fowler, of Monroe County, saw the vine in October,

with the leaves still hanging well, a great bearer and the grape of fine

quality. C. L. Hoag, of Lockport, said he began to pick the Niagara on the

26th of August, but its quality improved by hanging on the vine. J. Harris,

of Niagara County, was well acquainted with the Niagara, and indorsed all

the commendation which had been uttered in its favor. T. C. Maxwell said

there was one fault--we could not get it, as it was not in market. W. C.

Barry, of Rochester, spoke highly of the Niagara, and its slight foxiness

would be no objection to those who like that peculiarity. C. L. Hoag

thought this was the same quality that Col. Wilder described as "a little

aromatic." A. C. Younglove found the Niagara to ripen with the Delaware.

Inquiry being made relative to the Pockington grape, H. E. Hooker said it

ripened as early as the Concord. C. A. Green was surprised that it had not

attracted more attention, as he regarded it as a very promising grape. J.

Charlton, of Rochester, said that the fruit had been cut for market on the

29th of August, and on the 6th of September it was fully ripe; but he has

known it to hang as late as November. J. S. Stone had found that when it

hung as late as November it became sweet and very rich in flavor.

_New Peaches._--A. C. Younglove had found such very early sorts as

Alexander and Amsden excellent for home use, but not profitable for market.

The insects and birds made heavy depredations on them. While nearly all

very early and high-colored sorts suffer largely from the birds, the

Rivers, a white peach, does not attract them, and hence it may be

profitable for market if skillfully packed; rough and careless handling

will spoil the fruit. He added that the Wheatland peach sustains its high

reputation, and he thought it the best of all sorts for market, ripening

with Late Crawford. It is a great bearer, but carries a crop of remarkably

uniform size, so that it is not often necessary to throw out a bad

specimen. This is the result of experience with it by Mr. Rogers at

Wheatland, in Monroe County, and at his own residence in Vine Valley. S. D.

Willard confirmed all that Mr. Younglove had said of the excellence of the

Rivers peach. He had ripened the Amsden for several years, and found it

about two weeks earlier than the Rivers, and he thought if the Amsden were

properly thinned, it would prevent the common trouble of its rotting; such

had been his experience. E. A. Bronson, of Geneva, objected to making very

early peaches prominent for marketing, as purchasers would prefer waiting

a few days to paying high prices for the earliest, and he would caution

people against planting the Amsden too largely, and its free recommendation

might mislead. May's Choice was named by H. E. Hooker as a beautiful yellow

peach, having no superior in quality, but perhaps it may not be found

to have more general value than Early and Late Crawford. It is scarcely

distinguishable in appearance from fine specimens of Early Crawford. W. C.

Barry was called on for the most recent experience with the Waterloo,

but said he was not at home when it ripened, but he learned that it had

sustained its reputation. A. C. Younglove said that the Salway is the best

late peach, ripening eight or ten days after the Smock. S. D. Willard

mentioned an orchard near Geneva, consisting of 25 Salway trees, which for

four years had ripened their crop and had sold for $4 per bushel in the

Philadelphia market, or for $3 at Geneva--a higher price than for any other

sort--and the owner intends to plant 200 more trees. W. C. Barry said the

Salway will not ripen at Rochester. Hill's Chili was named by some members

as a good peach for canning and drying, some stating that it ripens before

and others after Late Crawford. It requires thinning on the tree, or

the fruit will be poor. The Allen was pronounced by Mr. Younglove as an

excellent, intensely high-colored late peach.

_Insects Affecting Horticulture_.--Mr. Zimmerman spoke of the importance

of all cultivators knowing so much of insects and their habits as to

distinguish their friends from their enemies. When unchecked they increase

in an immense ratio, and he mentioned as an instance that the green fly

(_Aphis_) in five generations may become the parent of six thousand million

descendants. It is necessary, then, to know what other insects are employed

in holding them in check, by feeding on them. Some of our most formidable

insects have been accidentally imported from Europe, such as the codling

moth, asparagus beetle, cabbage butterfly, currant worm and borer, elm-tree

beetle, hessian fly, etc.; but in nearly every instance these have come

over without bringing their insect enemies with them, and in consequence

they have spread more extensively here than in Europe. It was therefore

urged that the Agricultural Department at Washington be requested to

import, as far as practicable, such parasites as are positively known to

prey on noxious insects. The cabbage fly eluded our keen custom-house

officials in 1866, and has enjoyed free citizenship ever since. By

accident, one of its insect enemies (a small black fly) was brought over

with it, and is now doing excellent work by keeping the cabbage fly in

check.

The codling moth, one of the most formidable fruit destroyers, may be

reduced in number by the well-known paper bands; but a more efficient

remedy is to shower them early in the season with Paris green, mixed in

water at the rate of only one pound to one hundred gallons of water, with

a forcing pump, soon after blossoming. After all the experiments made and

repellents used for the plum curculio, the jarring method is found the most

efficient and reliable, if properly performed. Various remedies for insects

sometimes have the credit of doing the work, if used in those seasons

when the insects happen to be few. With some insects, the use of oil is

advantageous, as it always closes up their breathing holes and suffocates

them. The oil should be mixed with milk, and then diluted as required, as

the oil alone cannot be mixed with the water. As a general remedy,

Paris green is the strongest that can be applied. A teaspoonful to a

tablespoonful, in a barrel of water, is enough. Hot water is the best

remedy for house plants. Place one hand over the soil, invert the pot, and

plunge the foliage for a second only at a time in water heated to from 150 deg.

to 200 deg.F, according to the plants; or apply with a fine rose. The yeast

remedy has not proved successful in all cases.

Among beneficial insects, there are about one hundred species of lady bugs,

and, so far as known, all are beneficial. Cultivators should know them.

They destroy vast quantities of plant lice. The ground beetles are mostly

cannibals, and should not be destroyed. The large black beetle, with

coppery dots, makes short work with the Colorado potato beetles; and

a bright green beetle will climb trees to get a meal of canker worms.

Ichneumon flies are among our most useful insects. The much-abused dragon

flies are perfectly harmless to us, but destroy many mosquitoes and flies.

Among insects that attack large fruits is the codling moth, to be destroyed

by paper bands, or with Paris green showered in water. The round-headed

apple-tree borer is to be cut out, and the eggs excluded with a sheet of

tarred paper around the stem, and slightly sunk in the earth. For the

oyster-shell bark louse, apply linseed oil. Paris green, in water,

will kill the canker worm. Tobacco water does the work for plant lice.

Peach-tree borers are excluded with tarred or felt paper, and cut out with

a knife. Jar the grape flea beetle on an inverted umbrella early in the

morning. Among small-fruit insects, the strawberry worms are readily

destroyed with hellebore, an ounce to a gallon of warm water. The same

remedy destroys the imported currant worm.

_Insect Destroyers_.--Prof. W. Saunders, of the Province of Ontario,

followed Mr. Zimmerman with a paper on other departments of the same

general subject, which contained much information and many suggestions of

great value to cultivators. He had found Paris green an efficient remedy

for the bud-moth on pear and other trees. He also recommends Paris green

for the grapevine flea beetle. Hellebore is much better for the pear slug

than dusting with sand, as these slugs, as soon as their skin is spoiled

by being sanded, cast it off and go on with their work of destruction as

freely as ever, and this they repeat. He remarked that it is a common error

that all insects are pests to the cultivator. There are many parasites,

or useful ones, which prey on our insect enemies. Out of 7,000 described

insects in this country, only about 50 have proved destructive to our

crops. Parasites are much more numerous. Among lepidopterous insects

(butterflies, etc.), there are very few noxious species; many active

friends are found among the Hymenoptera (wasps, etc.), the ichneumon flies

pre-eminently so; and in the order Hemiptera (bugs proper) are several that

destroy our enemies. Hence the very common error that birds which destroy

insects are beneficial to us, as they are more likely to destroy our insect

friends than the fewer enemies. Those known as _flycatchers_ may do neither

harm nor good; so far as they eat the wheat-midge and Hessian fly they

confer a positive benefit; in other instances they destroy both friends and

enemies. Birds that are only partly insectivorous, and which eat grain and

fruit, may need further inquiry. Prof. S. had examined the stomachs of many

such birds, and particularly of the American robin, and the only curculio

he ever found in any of these was a single one in a whole cherry which the

bird had bolted entire. Robins had proved very destructive to his grapes,

but had not assisted at all in protecting his cabbages growing alongside

his fruit garden. These vegetables were nearly destroyed by the larvae of

the cabbage fly, which would have afforded the birds many fine, rich meals.

This comparatively feeble insect has been allowed by the throngs of birds

to spread over the whole continent. A naturalist in one of the Western

States had examined several species of the thrush, and found they had eaten

mostly that class of insects known as our friends.

Prof. S. spoke of the remedies for root lice, among which were hot water

and bisulphide of carbon. Hot water will get cold before it can reach the

smaller roots, however efficient it may be showered on leaves. Bisulphide

of carbon is very volatile, inflammable, and sometimes explosive, and must

be handled with great care. It permeates the soil, and if in sufficient

quantity may be effective in destroying the phylloxera; but its cost and

dangerous character prevent it from being generally recommended.

Paris green is most generally useful for destroying insects. As sold to

purchasers, it is of various grades of purity. The highest in price is

commonly the purest, and really the cheapest. A difficulty with this

variable quality is that it cannot be properly diluted with water, and

those who buy and use a poor article and try its efficacy, will burn or

kill their plants when they happen to use a stronger, purer, and more

efficient one. Or, if the reverse is done, they may pronounce it a humbug

from the resulting failure. One teaspoonful, if pure, is enough for a large

pail of water; or if mixed with flour, there should be forty or fifty times

as much. Water is best, as the operator will not inhale the dust. London

purple is another form of the arsenic, and has very variable qualities

of the poison, being merely refuse matter from manufactories. It is more

soluble than Paris green, and hence more likely to scorch plants. On the

whole, Paris green is much the best and most reliable for common use.

At the close of Prof. Saunders' remarks some objections were made by

members present to the use of Paris green on fruit soon after blossoming,

and Prof. S. sustained the objection, in that the knowledge that the fruit

had been showered with it would deter purchasers from receiving it, even if

no poison could remain on it from spring to autumn. A man had brought to

him potatoes to analyze for arsenic, on which Paris green had been used,

and although it was shown to him that the poison did not reach the roots

beneath the soil, and if it did it was insoluble and could not enter them,

he was not satisfied until a careful analysis was made and no arsenic at

all found in them. A member said that in mixing with plaster there should

be 100 or 150 pounds of plaster to one of the Paris green, and that a

smaller quantity, by weight, of flour would answer, as that is a more bulky

article for the same weight.

* * * * *

OBSERVATIONS ON THE SALMON OF THE PACIFIC.

By DAVID S. JORDAN and CHAS. H. GILBERT.

During the most of the present year, the writers have been engaged in the

study of the fishes of the Pacific coast of the United States, in the

interest of the U.S. Fish Commission and the U.S. Census Bureau. The

following pages contain the principal facts ascertained concerning the

salmon of the Pacific coast. It is condensed from our report to the U.S.

Census Bureau, by permission of Professor Goode, assistant in charge of

fishery investigations.

There are five species of salmon (Oncorhynchus) in the waters of the North

Pacific. We have at present no evidence of the existence of any more on

either the American or the Asiatic side.

These species may be called the quinnat or king salmon, the blue-back

salmon or red-fish, the silver salmon, the dog salmon, and the hump-back

salmon, or _Oncorhynchus chouicha, nerka, kisutch, keta_, and _gorbuscha_.

All these species are now known to occur in the waters of Kamtschatka as

well as in those of Alaska and Oregon.

As vernacular names of definite application, the following are on record:

a. Quinnat--Chouicha, king salmon, e'quinna, saw-kwey, Chinnook salmon,

Columbia River salmon, Sacramento salmon, tyee salmon, Monterey salmon,

deep-water salmon, spring salmon, ek-ul-ba ("ekewan") (fall run).

b. Blue-bock--krasnaya ryba, Alaska red-fish, Idaho red fish, sukkegh,

Frazer's River salmon, rascal, oo-chooy-ha.

c. Silver salmon--kisutch, winter salmon, hoopid, skowitz, coho, bielaya

ryba, o-o-wun.

d. Dog salmon--kayko, lekai, ktlawhy, qualoch, fall salmon, o-le-a-rah. The

males of _all_ the species in the fall are usually known as dog salmon, or

fall salmon.

e. Hump-back--gorbuscha, haddo, hone, holia, lost salmon, Puget Sound

salmon, dog salmon (of Alaska).

Of these species, the blue-back predominates in Frazer's River, the silver

salmon in Puget Sound, the quinnat in the Columbia and the Sacramento, and

the silver salmon in most of the small streams along the coast. All the

species have been seen by us in the Columbia and in Frazer's River; all

but the blue-back in the Sacramento, and all but the blue-back in waters

tributary to Puget Sound. Only the quinnat has been noticed south of San

Francisco, and its range has been traced as far as Ventura River, which is

the southernmost stream in California which is not muddy and alkaline at

its mouth.

Of these species, the quinnat and blue-back salmon habitually "run" in the

spring, the others in the fall. The usual order of running in the rivers is

as follows: _nerka, chouicha, kisutch, gorbuscha, keta_.

The economic value of the spring running salmon is far greater than that of

the other species, because they can be captured in numbers when at their

best, while the others are usually taken only after deterioration.

The habits of the salmon in the ocean are not easily studied. Quinnat and

silver salmon of every size are taken with the seine at almost any season

in Puget Sound. The quinnat takes the hook freely in Monterey bay, both

near the shore and at a distance of six or eight miles out. We have reason

to believe that these two species do not necessarily seek great depths, but

probably remain not very far from the mouth of the rivers in which they

were spawned.

The blue-back and the dog salmon probably seek deeper water, as the former

is seldom or never taken with the seine in the ocean, and the latter is

known to enter the Straits of Fuca at the spawning season.

The great majority of the quinnat salmon and nearly all blue-back salmon

enter the rivers in the spring. The run of both begins generally the last

of March; it lasts, with various modifications and interruptions, until

the actual spawning season in November; the time of running and the

proportionate amount of each of the subordinate runs, varying with each

different river. In general, the runs are slack in the summer and increase

with the first high water of autumn. By the last of August only straggling

blue-backs can be found in the lower course of any stream, but both in the

Columbia and the Sacramento the quinnat runs in considerable numbers till

October at least. In the Sacramento the run is greatest in the fall, and

more run in the summer than in spring. In the Sacramento and the smaller

rivers southward, there is a winter run, beginning in December.

The spring salmon ascend only those rivers which are fed by the melting

snows from the mountains, and which have sufficient volume to send their

waters well out to sea. Such rivers are the Sacramento, Rogue, Klamath,

Columbia, and Frazer's rivers.

Those salmon which run in the spring are chiefly adults (supposed to be at

least three years old). Their milt and spawn are no more developed than at

the same time in others of the same species which will not enter the rivers

until fall. It would appear that the contact with cold fresh water, when in

the ocean, in some way caused them to turn toward it and to "run," before

there is any special influence to that end exerted by the development of

the organs of generation.

High water on any of these rivers in the spring is always followed by an

increased run of salmon. The canners think, and this is probably true, that

salmon which would not have run till later are brought up by the contact

with the cold water. The cause of this effect of cold fresh water is not

understood. We may call it an instinct of the salmon, which is another way

of expressing our ignorance. In general, it seems to be true that in those

rivers and during those years when the spring run is greatest, the fall run

is least to be depended on.

As the season advances, smaller and younger salmon of these two species

(quinnat and blue-back) enter the rivers to spawn, and in the fall these

young specimens are very numerous. We have thus far failed to notice any

gradations in size or appearance of these young fish by which their ages

could be ascertained. It is, however, probable that some of both sexes

reproduce at the age of one year. In Frazer's River, in the fall, quinnat

male grilse of every size, from eight inches upward, were running, the milt

fully developed, but usually not showing the hooked jaws and dark colors

of the older males. Females less than eighteen inches in length were rare.

All, large and small, then in the river, of either sex, had the ovaries or

milt well developed.

Little blue-backs of every size down to six inches are also found in

the Upper Columbia in the fall, with their organs of generation fully

developed. Nineteen twentieths of these young fish are males, and some of

them have the hooked jaws and red color of the old males.

The average weight of the quinnat in the Columbia in the spring is

twenty-two pounds; in the Sacramento about sixteen. Individuals weighing

from forty to sixty pounds are frequently found in both rivers, and some as

high as eighty pounds are reported. It is questioned whether these large

fishes are:

(_a_.) Those which, of the same age, have grown more rapidly;

(_b_.) Those which are older but have, for some reason, failed to spawn;

or,

(_c_.) Those which have survived one or more spawning seasons.

All of these origins may be possible in individual cases; we are, however,

of the opinion that the majority of these large fish are those which have

hitherto run in the fall and so may have survived the spawning season

previous.

Those fish which enter the rivers in the spring continue their ascent until

death or the spawning season overtakes them. Probably none of them ever

return to the ocean, and a large proportion fail to spawn. They are known

to ascend the Sacramento as far as the base of Mount Shasta, or to its

extreme head-waters, about four hundred miles. In the Columbia they are

known to ascend as far as the Bitter Root Mountains, and as far as the

Spokan Falls, and their extreme limit is not known. This is a distance of

six to eight hundred miles.

At these great distances, when the fish have reached the spawning grounds,

besides the usual changes of the breeding season, their bodies are covered

with bruises on which patches of white fungus develop. The fins become

mutilated, their eyes are often injured or destroyed; parasitic worms

gather in their gills, they become extremely emaciated, their flesh

becomes white from the loss of the oil, and as soon as the spawning act

is accomplished, and sometimes before, all of them die. The ascent of the

Cascades and the Dalles probably causes the injury or death of a great many

salmon.

When the salmon enter the river they refuse bait, and their stomachs are

always found empty and contracted. In the rivers they do not feed, and when

they reach the spawning grounds their stomachs, pyloric coeca and all, are

said to be no larger than one's finger. They will sometimes take the

fly, or a hook baited with salmon roe, in the clear waters of the upper

tributaries, but there is no other evidence known to us that they feed when

there. Only the quinnat and blue-back (then called red-fish) have been

found in the fall at any great distance from the sea.

The spawning season is probably about the same for all the species. It

varies for all in different rivers and in different parts of the same

river, and doubtless extends from July to December.

The manner of spawning is probably similar for all the species, but we have

no data for any except the quinnat. In this species the fish pair off, the

male, with tail and snout, excavates a broad shallow "nest" in the gravelly

bed of the stream, in rapid water, at a depth of one to four feet; the

female deposits her eggs in it, and after the exclusion of the milt, they

cover them with stones and gravel. They then float down the stream tail

foremost. A great majority of them die. In the head-waters of the large

streams all die, unquestionably. In the small streams, and near the sea, an

unknown percentage probably survive. The young hatch in about sixty days,

and most of them return to the ocean during the high water of the spring.

The salmon of all kinds in the spring are silvery, spotted or not according

to the species, and with the mouth about equally symmetrical in both sexes.

As the spawning season approaches the female loses her silvery color,

becomes more slimy, the scales on the back partly sink into the skin, and

the flesh changes from salmon red and becomes variously paler, from the

loss of the oil, the degree of paleness varying much with individuals and

with inhabitants of different rivers.

In the lower Sacramento the flesh of the quinnat in either spring or fall

is rarely pale. In the Columbia, a few with pale flesh are sometimes taken

in spring, and a good many in the fall. In Frazer's River the fall run of

the quinnat is nearly worthless for canning purposes, because so many are

white meated. In the spring very few are white meated, but the number

increases towards fall, when there is every variation, some having red

streaks running through them, others being red toward the head and pale

toward the tail. The red and pale ones cannot be distinguished externally,

and the color is dependent neither on age nor sex. There is said to be no

difference in the taste, but there is no market for canned salmon not of

the conventional orange color.

As the season advances, the differences between the males and the females

become more and more marked, and keep pace with the development of the

milt, as is shown by dissection.

The males have: (_a_.) The premaxillaries and the tip of the lower jaw

more and more prolonged; both of them becoming finally strongly and often

extravagantly hooked, so that either they shut by the side of each other

like shears, or else the mouth cannot be closed. (_b_.) The front teeth

become very long and canine-like, their growth proceeding very rapidly,

until they are often half an inch long. (_c_.) The teeth on the vomer and

tongue often disappear. (_d_.) The body grows more compressed and deeper

at the shoulders, so that a very distinct hump is formed; this is more

developed in _0. gorbuscha_, but is found in all. (_e_.) The scales

disappear, especially on the back, by the growth of spongy skin. (_f_.) The

color changes from silvery to various shades of black and red or blotchy,

according to the species. The blue-back turns rosy red, the dog salmon a

dull, blotchy red, and the quiunat generally blackish.

These distorted males are commonly considered worthless, rejected by the

canners and salmon-salters, but preserved by the Indians. These changes are

due solely to influences connected with the growth of the testes. They are

not in any way due to the action of fresh water. They take place at about

the same time in the adult males of all species, whether in the ocean or

in the rivers. At the time of the spring runs all are symmetrical. In the

fall, all males of whatever species are more or less distorted. Among the

dog salmon, which run only in the fall, the males are hooked-jawed and

red-blotched when they first enter the Straits of Fuca from the outside.

The hump-back, taken in salt water about Seattle, shows the same

peculiarities. The male is slab-sided, hook-billed, and distorted, and is

rejected by the canners. No hook-jawed _females_ of any species have been

seen.

It is not positively known that any hook-jawed male survives the

reproductive act. If any do, their jaws must resume the normal form.

On first entering a stream the salmon swim about as if playing: they always

head toward the current, and this "playing" may be simply due to facing the

flood tide. Afterwards they enter the deepest parts of the stream and swim

straight up, with few interruptions. Their rate of travel on the Sacramento

is estimated by Stone at about two miles per day; on the Columbia at about

three miles per day.

As already stated, the economic value of any species depends in great part

on its being a "spring salmon." It is not generally possible to capture

salmon of any species in large numbers until they have entered the rivers,

and the spring salmon enter the rivers long before the growth of the organs

of reproduction has reduced the richness of the flesh. The fall salmon

cannot be taken in quantity until their flesh has deteriorated: hence the

"dog salmon" is practically almost worthless, except to the Indians, and

the hump-back salmon is little better. The silver salmon, with the same

breeding habits as the dog salmon, is more valuable, as it is found in

Puget Sound for a considerable time before the fall rains cause the fall

runs, and it may be taken in large numbers with seines before the season

for entering the rivers. The quinnat salmon, from its great size and

abundance, is more valuable than all other fishes on our Pacific coast

together. The blue back, similar in flesh but much smaller and less

abundant, is worth much more than the combined value of the three remaining

species.

The fall salmon of all species, but especially the dog salmon, ascend

streams but a short distance before spawning. They seem to be in great

anxiety to find fresh water, and many of them work their way up little

brooks only a few inches deep, where they soon perish miserably,

floundering about on the stones. Every stream, of whatever kind, has more

or less of these fall salmon.

It is the prevailing impression that the salmon have some special instinct

which leads them to return to spawn in the same spawning grounds where they

were originally hatched. We fail to find any evidence of this in the case

of the Pacific coast salmon, and we do not believe it to be true. It seems

more probable that the young salmon, hatched in any river, mostly remain in

the ocean within a radius of twenty, thirty, or forty miles of its mouth.

These, in their movements about in the ocean, may come into contact with

the cold waters of their parent rivers, or perhaps of any other river, at

a considerable distance from the shore. In the case of the quinnat and the

blue-back, their "instinct" leads them to ascend these fresh waters, and

in a majority of cases these waters will be those in which the fishes in

question were originally spawned. Later in the season the growth of the

reproductive organs leads them to approach the shore and to search for

fresh waters, and still the chances are that they may find the original

stream. But undoubtedly many fall salmon ascend, or try to ascend, streams

in which no salmon was ever hatched.

It is said of the Russian River and other California rivers, that their

mouths in the time of low water in summer generally become entirely closed

by sand bars, and that the salmon, in their eagerness to ascend them,

frequently fling themselves entirely out of water on the beach. But this

does not prove that the salmon are guided by a marvelous geographical

instinct which leads them to their parent river. The waters of Russian

River soak through these sand bars, and the salmon "instinct," we think,

leads them merely to search for fresh waters.

This matter is much in need of further investigation; at present, however,

we find no reason to believe that the salmon enter the Rogue River simply

because they were spawned there, or that a salmon hatched in the Clackamas

River is any the more likely on that account to return to the Clackamas

than to go up the Cowlitz or the Deschutes.

"At the hatchery on Rogue River, the fish are stripped, marked and set

free, and every year since the hatchery has been in operation some of the

marked fish have been re-caught. The young fry are also marked, but none of

them have been recaught."

This year the run of silver salmon in Frazer's River was very light, while

on Puget Sound the run was said by the Indians to be greater than ever

known before. Both these cases may be due to the same cause, the dry

summer, low water, and consequent failure of the salmon to find the rivers.

The run in the Sound is much more irregular than in the large rivers. One

year they will abound in one bay and its tributary stream and hardly be

seen in another, while the next year the condition will be reversed. At

Cape Flattery the run of silver salmon for the present year was very small,

which fact was generally attributed by the Indians to the birth of twins at

Neah Bay.

In regard to the diminution of the number of salmon on the coast. In

Puget's Sound, Frazer's River, and the smaller streams, there appears to be

little or no evidence of this. In the Columbia River the evidence appears

somewhat conflicting; the catch during the present year (1880) has been

considerably greater than ever before (nearly 540,000 cases of 48 lb. each

having been packed), although the fishing for three or four years has been

very extensive. On the other hand, the high water of the present spring has

undoubtedly caused many fish to become spring salmon which would otherwise

have run in the fall. Moreover, it is urged that a few years ago, when the

number caught was about half as great as now, the amount of netting used

was perhaps one-eighth as much. With a comparatively small outfit the

canners caught half the fish, now with nets much larger and more numerous,

they catch them all, scarcely any escaping during the fishing season (April

1 to August 1). Whether an actual reduction in the number of fish running

can be proven or not, there can be no question that the present rate of

destruction of the salmon will deplete the river before many years. A

considerable number of quinnat salmon run in August and September, and some

stragglers even later; these now are all which keep up the supply of

fish in the river. The non-molestation of this fall run, therefore, does

something to atone for the almost total destruction of the spring run.

This, however, is insufficient. A well-ordered salmon hatchery is the only

means by which the destruction of the salmon in the river can be prevented.

This hatchery should be under the control of Oregon and Washington, and

should be supported by a tax levied on the canned fish. It should be placed

on a stream where the quinnat salmon actually come to spawn.

It has been questioned whether the present hatchery on the Clackamas River

actually receives the quinnat salmon in any numbers. It is asserted, in

fact, that the eggs of the silver salmon and dog salmon, with scattering

quinnat, are hatched there. We have no exact information as to the truth of

these reports, but the matter should be taken into serious consideration.

On the Sacramento there is no doubt of the reduction of the number of

salmon; this is doubtless mainly attributable to over-fishing, but in part

it may be due to the destruction of spawning beds by mining operations and

other causes.

As to the superiority of the Columbia River salmon, there is no doubt that

the quinnat salmon average larger and fatter in the Columbia than in the

Sacramento and in Puget Sound. The difference in the canned fish is,

however, probably hardly appreciable. The canned salmon from the Columbia,

however, bring a better price in the market than those from elsewhere. The

canners there generally have had a high regard for the reputation of

the river, and have avoided canning fall fish or species other than the

quinnat. In the Frazer's River the blue-back is largely canned, and its

flesh being a little more watery and perhaps paler, is graded below the

quinnat. On Puget Sound various species are canned; in fact, everything

with red flesh. The best canners on the Sacramento apparently take equal

care with their product with those of the Columbia, but they depend largely

on the somewhat inferior fall run. There are, however, sometimes salmon

canned in San Francisco, which have been in the city markets, and for some

reason remaining unsold, have been sent to the canners; such salmon are

unfit for food, and canning them should be prohibited.

The fact that the hump-back salmon runs only on alternate years in Puget

Sound (1875, 1877, 1879, etc.) is well attested and at present unexplained.

Stray individuals only are taken in other years. This species has a

distinct "run," in the United States, only in Puget Sound, although

individuals (called "lost salmon") are occasionally taken in the Columbia

and in the Sacramento.--_American Naturalist._

* * * * *

THE RELATION BETWEEN ELECTRICITY AND LIGHT.

[Footnote: A lecture by Dr. O. J. Lodge, delivered at the London

Institution on December 16, 1880.]

Ever since the subject on which I have the honor to speak to you to-night

was arranged, I have been astonished at my own audacity in proposing to

deal in the course of sixty minutes with a subject so gigantic and so

profound that a course of sixty lectures would be quite inadequate for its

thorough and exhaustive treatment.

I must indeed confine myself carefully to some few of the typical and most

salient points in the relation between electricity and light, and I must

economize time by plunging at once into the middle of the matter without

further preliminaries.

Now, when a person is setting off to discuss the relation between

electricity and light, it is very natural and very proper to pull him up

short with the two questions: What do you mean by electricity? and What do

you mean by light? These two questions I intend to try briefly to answer.

And here let me observe that in answering these fundamental questions, I do

not necessarily assume a fundamental ignorance on your part of these two

agents, but rather the contrary; and must beg you to remember that if I

repeat well-known and simple experiments before you, it is for the purpose

of directing attention to their real meaning and significance, not to their

obvious and superficial characteristics; in the same way that I might

repeat the exceedingly familiar experiment of dropping a stone to the earth

if we were going to define what we meant by gravitation.

Now, then, we will ask first, What is electricity? and the simple answer

must be, We don't know. Well, but this need not necessarily be depressing.

If the same question were asked about matter, or about energy, we should

have likewise to reply, No one knows.

But then the term Matter is a very general one, and so is the term Energy.

They are heads, in fact, under which we classify more special phenomena.

Thus, if we were asked, What is sulphur? or what is selenium? we should at

least be able to reply, A form of matter; and then proceed to describe its

properties, _i. e._, how it affected our bodies and other bodies.

Again, to the question, What is heat? we can reply, A form of energy; and

proceed to describe the peculiarities which distinguish it from other forms

of energy.

But to the question. What is electricity? we have no answer pat like this.

We can not assert that it is a form of matter, neither can we deny it; on

the other hand, we certainly can not assert that it is a form of energy,

and I should be disposed to deny it. It may be that electricity is an

entity _per se_, just as matter is an entity _per se_.

Nevertheless, I can tell you what I mean by electricity by appealing to its

known behavior.

Here is a battery, that is, an electricity pump; it will drive electricity

along. Prof. Ayrtou is going, I am afraid, to tell you, on the 20th of

January next, that it _produces_ electricity; but if he does, I hope you

will remember that that is exactly what neither it nor anything else can

do. It is as impossible to generate electricity in the sense I am trying to

give the word, as it is to produce matter. Of course I need hardly say that

Prof. Ayrton knows this perfectly well; it is merely a question of words,

_i. e._, of what you understand by the word electricity.

I want you, then, to regard this battery and all electrical machines and

batteries as kinds of electricity pumps, which drive the electricity along

through the wire very much as a water-pump can drive water along pipes.

While this is going on the wire manifests a whole series of properties,

which are called the properties of the current.

[Here were shown an ignited platinum wire, the electric arc between two

carbons, an electric machine spark, an induction coil spark, and a vacuum

tube glow. Also a large nail was magnetized by being wrapped in the

current, and two helices were suspended and seen to direct and attract each

other.]

To make a magnet, then, we only need a current of electricity flowing round

and round in a whirl. A vortex or whirlpool of electricity is in fact a

magnet; and _vice versa_. And these whirls have the power of directing and

attracting other previously existing whirls according to certain laws,

called the laws of magnetism. And, moreover, they have the power of

exciting fresh whirls in neighboring conductors, and of repelling them

according to the laws of diamagnetism. The theory of the actions is known,

though the nature of the whirls, as of the simple stream of electricity, is

at present unknown.

[Here was shown a large electro-magnet and an induction-coil vacuum

discharge spinning round and round when placed in its field.]

So much for what happens when electricity is made to travel along

conductors, _i. e._, when it travels along like a stream of water in a

pipe, or spins round and round like a whirlpool.

But there is another set of phenomena, usually regarded as distinct and of

another order, but which are not so distinct as they appear, which

manifest themselves when you join the pump to a piece of glass, or any

non-conductor, and try to force the electricity through that. You succeed

in driving some through, but the flow is no longer like that of water in an

open pipe; it is as if the pipe were completely obstructed by a number of

elastic partitions or diaphragms. The water can not move without straining

and bending these diaphragms, and if you allow it, these strained

partitions will recover themselves, and drive the water back again. [Here

was explained the process of charging a Leyden jar.] The essential thing to

remember is that we may have electrical energy in two forms, the static

and the kinetic; and it is, therefore, also possible to have the rapid

alternation from one of these forms to the other, called vibration.

Now we will pass to the second question: What do you mean by light? And the

first and obvious answer is, Everybody knows. And everybody that is not

blind does know to a certain extent. We have a special sense organ for

appreciating light, whereas we have none for electricity. Nevertheless, we

must admit that we really know very little about the intimate nature of

light--very little more than about electricity. But we do know this,

that light is a form of energy, and, moreover, that it is energy rapidly

alternating between the static and the kinetic forms--that it is, in fact,

a special kind of energy of vibration. We are absolutely certain that light

is a periodic disturbance in some medium, periodic both in space and time;

that is to say, the same appearances regularly recur at certain equal

intervals of distance at the same time, and also present themselves at

equal intervals of time at the same place; that in fact it belongs to the

class of motions called by mathematicians undulatory or wave motions. The

wave motion in this model (Powell's wave apparatus) results from the simple

up and down motion popularly associated with the term wave. But when

a mathematician calls a thing a wave he means that the disturbance is

represented by a certain general type of formula, not that it is an

up-and-down motion, or that it looks at all like those things on the top of

the sea. The motion of the surface of the sea falls within that formula,

and hence is a special variety of wave motion, and the term wave has

acquired in popular use this signification and nothing else. So that when

one speaks ordinarily of a wave or undulatory motion, one immediately

thinks of something heaving up and down, or even perhaps of something

breaking on the shore. But when we assert that the form of energy called

light is undulatory, we by no means intend to assert that anything whatever

is moving up and down, or that the motion, if we could see it, would be

anything at all like what we are accustomed to in the ocean. The kind of

motion is unknown; we are not even sure that there is anything like motion

in the ordinary sense of the word at all.

Now, how much connection between electricity and light have we perceived in

this glance into their natures? Not much, truly. It amounts to about

this: That on the one hand electrical energy may exist in either of two

forms--the static form, when insulators are electrically strained by having

had electricity driven partially through them (as in the Leyden jar), which

strain is a form of energy because of the tendency to discharge and do

work; and the kinetic form, where electricity is moving bodily along

through conductors or whirling round and round inside them, which motion

of electricity is a form of energy, because the conductors and whirls can

attract or repel each other and thereby do work.

And, on the other hand, that light is the rapid alternation of energy

from one of these forms to the other--the static form where the medium is

strained, to the kinetic form when it moves. It is just conceivable, then,

that the static form of the energy of light is _electro_ static, that is,

that the medium is _electrically_ strained, and that the kinetic form of

the energy of light is _electro_-kinetic, that is, that the motion is

not ordinary motion, but electrical motion--in fact, that light is an

electrical vibration, not a material one.

On November 5, last year, there died at Cambridge a man in the full

vigor of his faculties--such faculties as do not appear many times in a

century--whose chief work has been the establishment of this very fact, the

discovery of the link connecting light and electricity; and the proof--for

I believe it amounts to a proof--that they are different manifestations

of one and the same class of phenomena--that light is, in fact, an

electro-magnetic disturbance. The premature death of James Clerk-Maxwell is

a loss to science which appears at present utterly irreparable, for he was

engaged in researches that no other man can hope as yet adequately to grasp

and follow out; but fortunately it did not occur till he had published his

book on "Electricity and Magnetism," one of those immortal productions

which exalt one's idea of the mind of man, and which has been mentioned by

competent critics in the same breath as the "Principia" itself.

But it is not perfect like the "Principia;" much of it is rough-hewn, and

requires to be thoroughly worked out. It contains numerous misprints and

errata, and part of the second volume is so difficult as to be almost

unintelligible. Some, in fact, consists of notes written for private use

and not intended for publication. It seems next to impossible now to mature

a work silently for twenty or thirty years, as was done by Newton two and a

half centuries ago. But a second edition was preparing, and much might have

been improved in form if life had been spared to the illustrious author.

The main proof of the electro-magnetic theory of light is this: The rate at

which light travels has been measured many times, and is pretty well known.

The rate at which an electro-magnetic wave disturbance would travel if such

could be generated (and Mr. Fitzgerald, of Dublin, thinks he has proved

that it can not be generated directly by any known electrical means) can

be also determined by calculation from electrical measurements. The two

velocities agree exactly. This is the great physical constant known as the

ratio V, which so many physicists have been measuring, and are likely to be

measuring for some time to come.

Many and brilliant as were Maxwell's discoveries, not only in electricity,

but also in the theory of the nature of gases, and in molecular science

generally, I can not help thinking that if one of them is more striking and

more full of future significance than the rest, it is the one I have just

mentioned--the theory that light is an electrical phenomenon.

The first glimpse of this splendid generalization was caught in 1845, five

and thirty years ago, by that prince of pure experimentalists, Michael

Faraday. His reasons for suspecting some connection between electricity and

light are not clear to us--in fact, they could not have been clear to him;

but he seems to have felt a conviction that if he only tried long enough

and sent all kinds of rays of light in all possible directions across

electric and magnetic fields in all sorts of media, he must ultimately

hit upon something. Well, this is very nearly what he did. With a sublime

patience and perseverance which remind one of the way Kepler hunted down

guess after guess in a different field of research, Faraday combined

electricity, or magnetism, and light in all manner of ways, and at last he

was rewarded with a result. And a most out-of-the-way result it seemed.

First, you have to get a most powerful magnet and very strongly excite it;

then you have to pierce its two poles with holes, in order that a beam of

light may travel from one to the other along the lines of force; then, as

ordinary light is no good, you must get a beam of plane polarized light,

and send it between the poles. But still no result is obtained until,

finally, you interpose a piece of a rare and out-of-the-way material, which

Faraday had himself discovered and made--a kind of glass which contains

borate of lead, and which is very heavy, or dense, and which must be

perfectly annealed.

And now, when all these arrangements are completed, what is seen is simply

this, that if an analyzer is arranged to stop the light and make the field

quite dark before the magnet is excited, then directly the battery is

connected and the magnet called into action, a faint and barely perceptible

brightening of the field occurs, which will disappear if the analyzer be

slightly rotated. [The experiment was then shown.] Now, no wonder that no

one understood this result. Faraday himself did not understand it at all.

He seems to have thought that the magnetic lines of force were rendered

luminous, or that the light was magnetized; in fact, he was in a fog,

and had no idea of its real significance. Nor had any one. Continental

philosophers experienced some difficulty and several failures before they

were able to repeat the experiment. It was, in fact, discovered too soon,

and before the scientific world was ready to receive it, and it was

reserved for Sir William Thomson briefly, but very clearly, to point

out, and for Clerk-Maxwell more fully to develop, its most important

consequences. [The principle of the experiment was then illustrated by the

aid of a mechanical model.]

This is the fundamental experiment on which Clerk-Maxwell's theory of

light is based; but of late years many fresh facts and relations between

electricity and light have been discovered, and at the present time they

are tumbling in in great numbers.

It was found by Faraday that many other transparent media besides heavy

glass would show the phenomenon if placed between the poles, only in a less

degree; and the very important observation that air itself exhibits the

same phenomenon, though to an exceedingly small extent, has just been made

by Kundt and Rontgen in Germany.

Dr. Kerr, of Glasgow, has extended the result to opaque bodies, and has

shown that if light be passed through magnetized _iron_ its plane is

rotated. The film of iron must be exceedingly thin, because of its opacity,

and hence, though the intrinsic rotating power of iron is undoubtedly very

great, the observed rotation is exceedingly small and difficult to observe;

and it is only by a very remarkable patience and care and ingenuity that

Dr. Kerr has obtained his result. Mr. Fitzgerald, of Dublin, has examined

the question mathematically, and has shown that Maxwell's theory would have

enabled Dr. Kerr's result to be predicted.

Another requirement of the theory is that bodies which are transparent

to light must be insulators or non-conductors of electricity, and that

conductors of electricity are necessarily opaque to light. Simple

observation amply confirms this; metals are the best conductors, and are

the most opaque bodies known. Insulators such as glass and crystals are

transparent whenever they are sufficiently homogeneous, and the very

remarkable researches of Prof. Graham Bell in the last few months have

shown that even _ebonite_, one of the most opaque insulators to ordinary

vision, is certainly transparent to some kinds of radiation, and

transparent to no small degree.

[The reason why transparent bodies must insulate, and why conductors must

be opaque, was here illustrated by mechanical models.]

A further consequence of the theory is that the velocity of light in a

transparent medium will be affected by its electrical strain constant; in

other words, that its refractive index will bear some close but not yet

quite ascertained relation to its specific inductive capacity. Experiment

has partially confirmed this, but the confirmation is as yet very

incomplete. But there are a number of results not predicted by theory, and

whose connection with the theory is not clearly made out. We have the fact

that light falling on the platinum electrode of a voltameter generates a

current, first observed, I think, by Sir W. R. Grove--at any rate, it is

mentioned in his "Correlation of Forces"--extended by Becquerel and Robert

Sabine to other substances, and now being extended to fluorescent and other

bodies by Prof. Minchin. And finally--for I must be brief--we have

the remarkable action of light on selenium. This fact was discovered

accidentally by an assistant in the laboratory of Mr. Willoughby Smith, who

noticed that a piece of selenium conducted electricity very much better

when light was falling upon it than when it was in the dark. The light of

a candle is sufficient, and instantaneously brings down the resistance to

something like one-fifth of its original value.

I could show you these effects, but there is not much to see; it is an

intensely interesting phenomenon, but its external manifestation is not

striking--any more than Faraday's heavy glass experiment was.

This is the phenomenon which, as you know, has been utilized by Prof.

Graham Bell in that most ingenious and striking invention, the photophone.

By the kindness of Prof. Silvanus Thompson, I have a few slides to show the

principle of the invention, and Mr. Shelford Bidwell has been kind enough

to lend me his home-made photophone, which answers exceedingly well for

short distances.

I have now trespassed long enough upon your patience, but I must just

allude to what may very likely be the next striking popular discovery; and

that is the transmission of light by electricity; I mean the transmission

of such things as views and pictures by means of the electric wire. It has

not yet been done, but it seems already theoretically possible, and it may

very soon be practically accomplished.

* * * * *

INTERESTING ELECTRICAL RESEARCHES.

During the last six years Dr. Warren de la Rue has been investigating,

in conjunction with Dr. Hugo Muller, the various and highly interesting

phenomena which accompany the electric discharge. From time to time the

results of their researches were communicated to the Royal Society, and

appeared in its Proceedings. Early last year Dr. De la Rue being requested

to bring the subject before the members of the Royal Institution, acceded

to the pressing invitation of his colleagues and scientific friends.

The discourse, which was necessarily long postponed on account of the

preparations that had to be made, was finally given on Friday, the 21st of

January, and was one of the most remarkable, from the elaborate nature of

the experiments, ever delivered in the theater of that deservedly famous

institution.

Owing to the great inconvenience of removing the battery from his

laboratory, Dr. de la Rue, despite the great expenditure, directed Mr. S.

Tisley to prepare, expressly for the lecture, a second series of 14,400

cells, and fit it up in the basement of the Royal Institution. The

construction of this new battery occupied Mr. Tisley a whole year, while

the charging of it extended over a fortnight.

The "de la Rue cell," if we may so call one of these elements, consists of

a zinc rod, the lower portion of which is embedded in a solid electrolyte,

viz., chloride of silver, with which are connected two flattened silver

wires to serve as electrodes. When these are united and the silver chloride

moistened, chemical action begins, and a weak but constant current is

generated.

The electromotive force of such a cell is 1.03 volts, and a current

equivalent to one volt passing through a resistance of one ohm was found to

decompose 0.00146 grain of water in one second. The battery is divided

into "cabinets," which hold from 1,200 to 2,160 small elements each. This

facilitates removal, and also the detection of any fault that may occur.

It will be remembered that in 1808 Sir Humphry Davy constructed his battery

of 2,000 cells, and thus succeeded in exalting the tiny spark obtained in

closing the circuit into the luminous sheaf of the voltaic arc. He also

observed that the spark passed even when the poles were separated by a

distance varying from 1/40 to 1/30 of an inch. This appears to have been

subsequently forgotten, as we find later physicists questioning the

possibility of the spark leaping over any interpolar distance. Mr. J.

P. Gassiot, of Clapham, demonstrated the inaccuracy of this opinion by

constructing a battery of 3,000 Leclanche cells, which gave a spark of

0.025 inch; a similar number of "de la Rue" cells gives an 0.0564 inch

spark. This considerable increase in potential is chiefly due to better

insulation.

The great energy of this battery was illustrated by a variety of

experiments. Thus, a large condenser, specially constructed by Messrs.

Varley, and having a capacity equal to that of 6,485 large Leyden jars,

was almost immediately charged by the current from 10,000 cells. Wires of

various kinds, and from 9 inches to 29 inches in length, were instantly

volatilized by the passage of the electricity thus stored up. The current

induced in the secondary wire of a coil by the discharge of the condenser

through the primary, was also sufficiently intense to deflagrate wires of

considerable length and thickness.

It was with such power at his command that Dr. De la Rue proceeded to

investigate several important electrical laws. He has found, for example,

that the positive discharge is more intermittent than the negative,

that the arc is always preceded by a streamer-like discharge, that its

temperature is about 16,000 deg., and its length at the ordinary pressure

of the atmosphere, when taken between two points, varies as the square

of the number of cells. Thus, with a battery of 1,000 cells, the arc was

0.0051 inch, with 11,000 cells it increased to 0.62 inch. The same law was

found to hold when the discharge took place between a point and a disk; it

failed entirely, however, when the terminals were two disks.

It was also shown that the voltaic arc is not a phenomenon of conduction,

but is essentially a disruptive discharge, the intervals between the

passage of two successive static sparks being the time required for the

battery to collect sufficient power to leap over the interposed resistance.

This was further confirmed by the introduction of a condenser, when the

intervals were perceptibly larger.

Faraday proved that the quantity of electricity necessary to produce a

strong flash of lightning would result from the decomposition of a single

grain of water, and Dr. de la Rue's experiments confirm this extraordinary

statement. He has calculated that this quantity of electricity would be

5,000 times as great as the charge of his large condenser, and that a

lightning flash a mile long would require the potential of 3,500,000 cells,

that is to say, of 243 of his powerful batteries.

In experimenting with "vacuum" tubes, he has found that the discharge is

also invariably disruptive. This is an important point, as many physicists

speak and write of the phenomenon as one of conduction. Air, in every

degree of tenuity, refuses to act as a conductor of electricity. These

experiments show that the resistance of gaseous media diminishes with the

pressure only up to a certain point, beyond which it rapidly increases.

Thus, in the case of hydrogen, it diminishes up to 0.642 mm., 845

millionths; it then rises as the exhaustion proceeds, and at 0.00065 mm.,

8.6 millionths, it requires as high a potential as at 21.7 mm., 28.553

millionths. At 0.00137 mm., 1.8 millionth, the current from 11,000 cells

would not pass through a tube for which 430 cells sufficed at the pressure

of minimum resistance. At a pressure of 0.0055 mm., 0.066 millionth, the

highest exhaust obtained in any of the experiments, even a one-inch spark

from an induction coil refused to pass. It was also ascertained that there

is neither condensacian nor dilatation of the gas in contact with the

terminals prior to the passage of the discharge.

These researches naturally led to some speculation about the conditions

under which auroral phenomena may occur. Observers have variously stated

the height at which the aurora borealis attains its greatest brilliancy

as ranging between 124 and 281 miles. Dr. de la Rue's conclusions fix

the upper limit at 124 miles, and that of maximum display at 37 miles,

admitting also that the aurora may sometimes occur at an altitude of a few

thousand feet.

The aurora was beautifully illustrated by a very large tube, in which the

theoretical pressure was carefully maintained, the characteristic roseate

tinge being readily produced and maintained.

In studying the stratifications observed in vacuum tubes, Dr. de la Rue

finds that they originate at the positive pole, and that their steadiness

may be regulated by the resistance in circuit, and that even when the least

tremor cannot be detected by the eye, they are still produced by rapid

pulsations which may be as frequent as ten millions per second.

Dr. de la Rue concluded his interesting discourse by exhibiting some of the

finest tubes of his numerous and unsurpassed collection.--_Engineering_

* * * * *

MEASURING ELECTROMOTIVE FORCE.

Coulomb's torsion balance has been adapted by M. Baille to the measurement

of low electromotive forces in a very successful manner, and has been found

preferable by him to the delicate electrometers of Sir W. Thomson. It

is necessary to guard it from disturbances due to extraneous electric

influences and the trembling of the ground. These can be eliminated

completely by encircling the instrument in a metal case connected to

earth, and mounting it on solid pillars in a still place. Heat also has a

disturbing effect, and makes itself felt in the torsion of the fiber and

the cage surrounding the lever. These effects are warded off by inclosing

the instrument in a non-conducting jacket of wood shavings.

The apparatus of M. Baille consists of an annealed silver torsion wire of

2.70 meters long, and a lever 0.50 meter long, carrying at each extremity

a ball of copper, gilded, and three centimeters in diameter. Similar balls

are fixed at the corners of a square 20.5 meters in the side, and connected

in diagonal pairs by fine wire. The lever placed at equal distances from

the fixed balls communicates, by the medium of the torsion wire, with the

positive pole of a battery, P, the other pole being to earth.

Owing to some unaccountable variations in the change of the lever or

needle, M. Baille was obliged to measure the change at each observation.

This was done by joining the + pole of the battery to the needle, and one

pair of the fixed balls, and observing the deflection; then the deflection

produced by the other balls was observed. This operation was repeated

several times.

The battery, X, to be measured consisted of ten similar elements, and one

pole of it was connected to the fixed balls, while the other pole was

connected to the earth. The needle, of course, remained in contact with the

+ pole of the charging battery, P.

The deflections were read from a clear glass scale, placed at a distance

of 3.30 meters from the needle, and the results worked out from Coulomb's

static formula,

C a = (4 m m')/d squared, with

______________

/ sum((p/g) r squared)

O = / -------------

\/ C

[TEX: O = \sqrt{\frac{\sum \frac{p}{g} r^2}{C}}]

In M. Baillie's experiments, O = 437 cubed, and sum(pr squared)= 32171.6 (centimeter

grammes), the needle having been constructed of a geometrical form.

The following numbers represent the potential of an element of the

battery--that is to say, the quantity of electricity that the pole of that

battery spreads upon a sphere of one centimeter radius. They are expressed

in units of electricity, the unit being the quantity of electricity which,

acting upon a similar unit at a distance of one centimeter, produces a

repulsion equal to one gramme:

Volta pile 0.03415 open circuit.

Zinc, sulphate of copper, copper 0.02997 "

Zinc, acidulated water, copper, sulphate of copper 0.03709 "

Zinc, salt water, carbon peroxide of manganese 0.05282 "

Zinc, salt water, platinum, chloride of platinum 0.05027 "

Zinc, acidulated water, carbon nitric acid 0.06285 "

These results were obtained just upon charging the batteries, and are,

therefore, slightly higher than the potentials given after the batteries

became older. The sulphate of copper cells kept about their maximum value

longest, but they showed variations of about 10 per cent.

* * * * *

TELEPHONY BY THERMIC CURRENTS.

While in telephonic arrangements, based upon the principle of magnetic

induction, a relatively considerable expenditure of force is required in

order to set the tightly stretched membrane in vibration, in the so-called

carbon telephones only a very feeble impulse is required to produce the

differences in the current necessary for the transmission of sounds. In

order to produce relatively strong currents, even in case of sound-action

of a minimum strength, Franz Kroettlinger, of Vienna, has made an

interesting experiment to use thermo electric currents for the transmission

of sound to a distance. The apparatus which he has constructed is

exceedingly simple. A current of hot air flowing from below upward is

deflected more or less from its direction by the human voice. By its action

an adjacent thermo-battery is excited, whose current passes through the

spiral of an ordinary telephone, which serves as the receiving instrument.

As a source of heat the inventor uses a common stearine candle, the flame

of which is kept at one and the same level by means of a spring similar to

those used in carriage lamps. On one side of the candle is a sheet metal

voice funnel fixed upon a support, its mouth being covered with a movable

sliding disk, fitted with a suitable number of small apertures. On the

other side a similar support holds a funnel-shaped thermo-battery. The

single bars of metal forming this battery are very thin, and of such a

shape that they may cool as quickly as possible. Both the speaking-funnel

and the battery can be made to approach, at will, to the stream of warm air

rising up from the flame. The entire apparatus is inclosed in a tin case

in such a manner that only the aperture of the voice-funnel and the polar

clamps for securing the conducting wires appear on the outside. The inside

of the case is suitably stayed to prevent vibration. On speaking into the

mouth-piece of the funnel, the sound-waves occasion undulations in the

column of hot air which are communicated to the thermo-battery, and in this

manner corresponding differences are produced in the currents in the wires

leading to the receiving instrument.--_Oesterreichische-Ungarische Post._

* * * * *

THE TELECTROSCOPE.

By MONS. SENLECQ, of Ardres.

This apparatus, which is intended to transmit to a distance through a

telegraphic wire pictures taken on the plate of a camera, was invented in

the early part of 1877 by M. Senlecq, of Ardres. A description of the first

specification submitted by M. Senlecq to M. du Moncel, member of the

Paris Academy of Sciences, appeared in all the continental and American

scientific journals. Since then the apparatus has everywhere occupied the

attention of prominent electricians, who have striven to improve on it.

Among these we may mention MM. Ayrton, Perry, Sawyer (of New York),

Sargent (of Philadelphia), Brown (of London), Carey (of Boston), Tighe (of

Pittsburg), and Graham Bell himself. Some experimenters have used many

wires, bound together cable-wise, others one wire only. The result has

been, on the one hand, confusion of conductors beyond a certain distance,

with the absolute impossibility of obtaining perfect insulation; and,

on the other hand, an utter want of synchronism. The unequal and slow

sensitiveness of the selenium likewise obstructed the proper working of the

apparatus. Now, without a relative simplicity in the arrangement of the

conducting wires intended to convey to a distance the electric current with

its variations of intensity, without a perfect and rapid synchronism

acting concurrently with the luminous impressions, so as to insure the

simultaneous action of transmitter and receiver, without, in fine, an

increased sensitiveness in the selenium, the idea of the telectroscope

could not be realized. M. Senlecq has fortunately surmounted most of these

main obstacles, and we give to-day a description of the latest apparatus he

has contrived.

TRANSMITTER.

A brass plate, A, whereon the rays of light impinge inside a camera, in

their various forms and colors, from the external objects placed before the

lens, the said plate being coated with selenium on the side intended to

face the dark portion of the camera This brass plate has its entire surface

perforated with small holes as near to one another as practicable. These

holes are filled with selenium, heated, and then cooled very slowly, so as

to obtain the maximum sensitiveness. A small brass wire passes through the

selenium in each hole, without, however, touching the plate, on to the

rectangular and vertical ebonite plate, B, Fig. 1, from under this plate

at point, C. Thus, every wire passing through plate, A, has its point

of contact above the plate, B, lengthwise. With this view the wires are

clustered together when leaving the camera, and thence stretch to their

corresponding points of contact on plate, B, along line, C C. The surface

of brass, A, is in permanent contact with the positive pole of the battery

(selenium). On each side of plate, B, are let in two brass rails, D and E,

whereon the slide hereinafter described works.

[Illustration: Fig. 1]

Rail, E, communicates with the line wire intended to conduct the various

light and shade vibrations. Rail, D, is connected with the battery wire.

Along F are a number of points of contact corresponding with those along

C C. These contacts help to work the apparatus, and to insure the perfect

isochronism of the transmitter and receiver. These points of contact,

though insulated one from the other on the surface of the plate, are all

connected underneath with a wire coming from the positive pole of a special

battery. This apparatus requires two batteries, as, in fact, do all

autographic telegraphs--one for sending the current through the selenium,

and one for working the receiver, etc. The different features of this

important plate may, therefore, be summed up thus:

FIGURE 1.

D. Brass rail, grooved and connected with the line wire working the

receiver.

F. Contacts connected underneath with a wire permanently connected with

battery.

C. Contacts connected to insulated wires from selenium.

E. Brass rail, grooved, etc., like D.

RECEIVER.

A small slide, Fig. 2, having at one of its angles a very narrow piece of

brass, separated in the middle by an insulating surface, used for setting

the apparatus in rapid motion. This small slide has at the points, D D, a

small groove fitting into the brass rails of plate, B, Fig. 1, whereby it

can keep parallel on the two brass rails, D and E. Its insulator, B, Fig.

2, corresponds to the insulating interval between F and C, Fig. 1.

A, Fig. 3, circular disk, suspended vertically (made of ebonite or other

insulating material). This disk is fixed. All round the inside of its

circumference are contacts, connected underneath with the corresponding

wires of the receiving apparatus. The wires coming from the seleniumized

plate correspond symmetrically, one after the other, with the contacts of

transmitter. They are connected in the like order with those of disk, A,

and with those of receiver, so that the wire bearing the No. 5 from the

selenium will correspond identically with like contact No. 5 of receiver.

D, Fig. 4, gutta percha or vulcanite insulating plate, through which pass

numerous very fine platinum wires, each corresponding at its point of

contact with those on the circular disk, A.

The receptive plate must be smaller than the plate whereon the light

impinges. The design being thus reduced will be the more perfect from the

dots formed by the passing currents being closer together.

B, zinc or iron or brass plate connected to earth. It comes in contact with

chemically prepared paper, C, where the impression is to take place. It

contributes to the impression by its contact with the chemically prepared

paper.

In E, Fig. 3, at the center of the above described fixed plate is a

metallic axis with small handle. On this axis revolves brass wheel, F, Fig.

[Illustration: FIG. 2]

On handle, E, presses continuously the spring, H, Fig. 3, bringing the

current coming from the selenium line. The cogged wheel in Fig. 5 has at a

certain point of its circumference the sliding spring, O, Fig. 5, intended

to slide as the wheel revolves over the different contacts of disk, A, Fig.

This cogged wheel, Fig. 5, is turned, as in the dial telegraphs, by a rod

working in and out under the successive movements of the electro-magnet,

H, and of the counter spring. By means of this rod (which must be of a

non-metallic material, so as not to divert the motive current), and of an

elbow lever, this alternating movement is transmitted to a catch, G, which

works up and down between the cogs, and answers the same purpose as the

ordinary clock anchor.

[Illustration: FIG. 3]

This cogged wheel is worked by clockwork inclosed between two disks, and

would rotate continuously were it not for the catch, G, working in and out

of the cogs. Through this catch, G, the wheel is dependent on the movement

of electro-magnet. This cogged wheel is a double one, consisting of two

wheels coupled together, exactly similar one with the other, and so fixed

that the cogs of the one correspond with the void between the cogs of the

others. As the catch, G, moves down it frees a cog in first wheel, and both

wheels begin to turn, but the second wheel is immediately checked by catch,

G, and the movement ceases. A catch again works the two wheels, turn half a

cog, and so on. Each wheel contains as many cogs as there are contacts on

transmitter disk, consequently as many as on circular disk, A, Fig. 3, and

on brass disk within camera.

[Illustration: FIG. 4]

[Illustration: FIG. 5]

Having now described the several parts of the apparatus, let us see how it

works. All the contacts correspond one with the other, both on the side of

selenium current and that of the motive current. Let us suppose that the

slide of transmitter is on contact No. 10 for instance; the selenium

current starting from No. 10 reaches contact 10 of rectangular transmitter,

half the slide bearing on this point, as also on the parallel rail,

communicates the current to said rail, thence to line, from the line to

axis of cogged wheel, from axis to contact 10 of circular fixed disk,

and thence to contact 10 of receiver. At each selenium contact of the

rectangular disk there is a corresponding contact to the battery and

electro-magnet. Now, on reaching contact 10 the intermission of the current

has turned the wheel 10 cogs, and so brought the small contact, O, Fig. 5,

on No. 10 of the fixed circular disk.

As may be seen, the synchronism of the apparatus could not be obtained in

a more simple and complete mode--the rectangular transmitter being placed

vertically, and the slide being of a certain weight to its fall from the

first point of contact sufficient to carry it rapidly over the whole length

of this transmitter.

The picture is, therefore, reproduced almost instantaneously; indeed, by

using platinum wires on the receiver connected with the negative pole, by

the incandescence of these wires according to the different degrees of

electricity we can obtain a picture, of a fugitive kind, it is true, but

yet so vivid that the impression on the retina does not fade during the

relatively very brief space of time the slide occupies in traveling over

all the contacts. A Ruhmkorff coil may also be employed for obtaining

sparks in proportion to the current emitted. The apparatus is regulated

in precisely the same way as dial telegraphs, starting always from first

contact. The slide should, therefore, never be removed from the rectangular

disk, whereon it is held by the grooves in the brass rails, into which it

fits with but slight friction, without communicating any current to the

line wires when not placed on points of contact.

* * * * *

[Continued from SUPPLEMENT No. 274, page 4368.]

THE VARIOUS MODES OF TRANSMITTING POWER TO A DISTANCE.

[Footnote: A paper lately read before the Institution of Mechanical

Engineers.]

By ARTHUR ACHARD, of Geneva.

But allowing that the figure of 22 H. P., assumed for this power (the

result in calculating the work with compressed air being 19 H. P.) may be

somewhat incorrect, it is unlikely that this error can be so large that its

correction could reduce the efficiency below 80 per cent. Messrs. Sautter

and Lemonnier, who construct a number of compressors, on being consulted

by the author, have written to say that they always confined themselves in

estimating the power stored in the compressed air, and had never measured

the gross power expended. Compressed air in passing along the pipe, assumed

to be horizontal, which conveys it from the place of production to the

place where it is to be used, experiences by friction a diminution of

pressure, which represents a reduction in the mechanical power stored up,

and consequently a loss of efficiency.

The loss of pressure in question can only be calculated conveniently on the

hypothesis that it is very small, and the general formula,

p1 - p 4L

------- = ---- f(u),

[Delta] D

[TEX: \frac{p_1 - p}{\Delta} = \frac{4L}{D}f(u)]

is employed for the purpose, where D is the diameter of the pipe, assumed

to be uniform, L the length of the pipe, p1 the pressure at the entrance, p

the pressure at the farther end, u the velocity at which the compressed air

travels, [Delta] its specific weight, and f(u) the friction per unit of

length. In proportion as the air loses pressure its speed increases, while

its specific weight diminishes; but the variations in pressure are assumed

to be so small that u and [Delta] may be considered constant. As regards

the quantity f(u), or the friction per unit of length, the natural law

which regulates it is not known, audit can only be expressed by some

empirical formula, which, while according sufficiently nearly with the

facts, is suited for calculation. For this purpose the binomial formula, au

+ bu squared, or the simple formula, b1 u squared, is generally adopted; a b and b1 being

coefficients deduced from experiment. The values, however, which are to

be given to these coefficients are not constant, for they vary with the

diameter of the pipe, and in particular, contrary to formerly received

ideas, they vary according to its internal surface. The uncertainty in this

respect is so great that it is not worth while, with a view to accuracy, to

relinquish the great convenience which the simple formula, b1 u squared, offers.

It would be better from this point of view to endeavor, as has been

suggested, to render this formula more exact by the substitution of a

fractional power in the place of the square, rather than to go through

the long calculations necessitated by the use of the binomial au + bu squared.

Accordingly, making use of the formula b1 u squared, the above equation becomes,

p1 - p 4L

------- = ---- b1 u squared;

[Delta] D

[TEX: \frac{p_1 - p}{\Delta} = \frac{4L}{D} b_1 u^2]

or, introducing the discharge per second, Q, which is the usual figure

supplied, and which is connected with the velocity by the relation, Q =

([pi] D squared u)/4, we have

p1 - p 64 b1

------- = --------- L Q squared.

[Delta] [pi] squared D^5

[TEX: \frac{p_1 - p}{\Delta} = \frac{64 b_1}{\pi^2 D^5} L Q^2]

Generally the pressure, p1, at the entrance is known, and the pressure, p,

has to be found; it is then from p1 that the values of Q and [Delta] are

calculated. In experiments where p1 and p are measured directly, in order

to arrive at the value of the coefficient b1, Q and [Delta] would be

calculated for the mean pressure 1/2(p1 + p). The values given to the

coefficient b1 vary considerably, because, as stated above, it varies with

the diameter, and also with the nature of the material of the pipe. It

is generally admitted that it is independent of the pressure, and it is

probable that within certain limits of pressure this hypothesis is in

accordance with the truth.

D'Aubuisson gives for this case, in his _Traite d'Hydraulique_, a rather

complicated formula, containing a constant deduced from experiment, whose

value, according to a calculation made by the author, is approximately b1 =

0.0003. This constant was determined by taking the mean of experiments made

with tin tubes of 0.0235 meter (15/16 in.), 0.05 meter (2 in.), and 0.10

meter (4 in.) diameter; and it was erroneously assumed that it was correct

for all diameters and all substances.

M. Arson, engineer to the Paris Gas Company, published in 1867, in the

_Memoires de la Societe des Ingenieurs Civils de France_, the results of

some experiments on the loss of pressure in gas when passing through pipes.

He employed cast-iron pipes of the ordinary type. He has represented the

results of his experiments by the binomial formula, au + bu squared, and gives

values for the coefficients a and b, which diminish with an increase in

diameter, but would indicate greater losses of pressure than D'Aubuisson's

formula. M. Deviller, in his _Rapport sur les travaux de percement du

tunnel sous les Alpes_, states that the losses of pressure observed in the

air pipe at the Mont Cenis Tunnel confirm the correctness of D'Aubuisson's

formula; but his reasoning applies to too complicated a formula to be

absolutely convincing.

Quite recently M. E. Stockalper, engineer-in-chief at the northern end of

the St. Gothard Tunnel, has made some experiments on the air conduit of

this tunnel, the results of which he has kindly furnished to the author.

These lead to values for the coefficient b1 appreciably less than that

which is contained implicitly in D'Aubuisson's formula. As he experimented

on a rising pipe, it is necessary to introduce into the formula the

difference of level, h, between the two ends; it then becomes

p1 - p 64 b1

------- = --------- L Q squared + h.

[Delta] [pi] squared D^5

[TEX: \frac{p_1 - p}{\Delta} = \frac{64 b_1}{\pi^2 D^5} L Q^2 + h]

The following are the details of the experiments: First series of

experiments: Conduit consisting of cast or wrought iron pipes, joined by

means of flanges, bolts, and gutta percha rings. D = 0.20 m. (8 in.); L =

4,600 m. (15,100 ft,); h= 26.77 m. (87 ft. 10 in.). 1st experiment: Q =

0.1860 cubic meter (6.57 cubic feet), at a pressure of 1/2(p1 + p), and a

temperature of 22 deg. Cent. (72 deg. Fahr.); p1 = 5.60 atm., p =5.24 atm. Hence p1

- p = 0.36 atm.= 0.36 x 10,334 kilogrammes per square meter (2.116 lb. per

square foot), whence we obtain b1=0.0001697. D'Aubuisson's formula would

have given p1 - p = 0.626 atm.; and M. Arson's would have given p1 - p =

0.9316 atm. 2d experiment: Q = 0.1566 cubic meter (5.53 cubic feet), at a

pressure of 1/2(p1 + p), and a temperature of 22 deg. Cent. (72 deg. Fahr.); p1

= 4.35 atm., p = 4.13 atm. Hence p1 - p = 0.22 atm. = 0.22 X 10,334

kilogrammes per square meter (2,116 lb. per square foot); whence we obtain

b1 = 0.0001816. D'Aubuisson's formula would have given p1 - p = 0.347 atm;

and M. Arson's would have given p1 - p = 0.5382 atm. 3d experiment: Q =

0.1495 cubic meter (5.28 cubic feet) at a pressure of 1/2(p1 + p) and a

temperature 22 deg. Cent. (72 Fahr.); p1 = 3.84 atm., p = 3.65 atm. Hence p1 -

p = 0.19 atm. = 0.19 X 10,334 kilogrammes per square meter (2.116 lb. per

square foot); whence we obtain B1 = 0.0001966. D'Aubuisson's formula would

have given p1 - p = 0.284 atm., and M. Arson's would have given p1 - p =

0.4329 atm. Second series of experiments: Conduit composed of wrought-iron

pipes, with joints as in the first experiments. D = 0.15 meter (6 in.), L

- 0.522 meters (1,712 ft.), h = 3.04 meters (10 ft.) 1st experiments: Q =

0.2005 cubic meter (7.08 cubic feet), at a pressure of 1/2(p1 + p), and a

temperature of 26.5 deg. Cent. (80 deg. Fahr.); p1 = 5.24 atm., p = 5.00 atm. Hence

p1 - p = 0.24 atm. =0.24 x 10,334 kilogrammes per square meter (2,116 lb.

per square foot); whence we obtain b1 = 0.3002275. 2nd experiment: Q =

0.1586 cubic meter (5.6 cubic feet), at a pressure of 1/2(p1 + p), and a

temperature of 26.5 deg. Cent. (80 deg. Fahr.); p1 = 3.650 atm., p = 3.545 atm.

Hence p1 - p = 0.105 atm. = 0.105 x 10,334 kilogrammes per square meter

(2,116 lb. per square foot); whence we obtain b1 = 0.0002255. It is clear

that these experiments give very small values for the coefficient. The

divergence from the results which D'Aubuisson's formula would give is due

to the fact that his formula was determined with very small pipes. It is

probable that the coefficients corresponding to diameters of 0.15 meter

(6 in.) and 0.20 meter (8 in.) for a substance as smooth as tin, would be

still smaller respectively than the figures obtained above.

The divergence from the results obtained by M. Arson's formula does not

arise from a difference in size, as this is taken into account. The author

considers that it may be attributed to the fact that the pipes for the St.

Gothard Tunnel were cast with much greater care than ordinary pipes, which

rendered their surface smoother, and also to the fact that flanged joints

produce much less irregularity in the internal surface than the ordinary

spigot and faucet joints.

Lastly, the difference in the methods of observation and the errors which

belong to them, must be taken into account. M. Stockalper, who experimented

on great pressures, used metallic gauges, which are instruments on whose

sensibility and correctness complete reliance cannot be placed; and

moreover the standard manometer with which they were compared was one of

the same kind. The author is not of opinion that the divergence is owing to

the fact that M. Stockalper made his observations on an air conduit, where

the pressure was much higher than in gas pipes. Indeed, it may be assumed

that gases and liquids act in the same manner; and, as will be [1]

explained later on, there is reason to believe that with the latter a rise

of pressure increases the losses of pressure instead of diminishing them.

[Transcribers note 1: corrected from 'as will we explained']

All the pipes for supplying compressed air in tunnels and in headings of

mines are left uncovered, and have flanged joints; which are advantages not

merely as regards prevention of leakage, but also for facility of laying

and of inspection. If a compressed air pipe had to be buried in the ground

the flanged joint would lose a part of its advantages; but, nevertheless,

the author considers that it would still be preferable to the ordinary

joint.

It only remains to refer to the motors fed with the compressed air.

This subject is still in its infancy from a practical point of view. In

proportion as the air becomes hot by compression, so it cools by expansion,

if the vessel containing it is impermeable to heat. Under these conditions

it gives out in expanding a power appreciably less than if it retained its

original temperature; besides which the fall of temperature may impede the

working of the machine by freezing the vapor of water contained in the air.

If it is desired to utilize to the utmost the force stored up in the

compressed air it is necessary to endeavor to supply heat to the air during

expansion so as to keep its temperature constant. It would be possible

to attain this object by the same means which prevent heating from

compression, namely, by the circulation and injection of water. It would

perhaps be necessary to employ a little larger quantity of water for

injection, as the water, instead of acting by virtue both of its heat of

vaporization and of its specific heat, can in this case act only by virtue

of the latter. These methods might be employed without difficulty for air

machines of some size. It would be more difficult to apply them to small

household machines, in which simplicity is an essential element; and we

must rest satisfied with imperfect methods, such as proximity to a stove,

or the immersion of the cylinder in a tank of water. Consequently loss of

power by cooling and by incomplete expansion cannot be avoided. The only

way to diminish the relative amount of this loss is to employ compressed

air at a pressure not exceeding three or four atmospheres.

The only real practical advance made in this matter is M. Mekarski's

compressed air engine for tramways. In this engine the air is made to pass

through a small boiler containing water at a temperature of about 120 deg.

Cent. (248 deg. Fahr.), before entering the cylinder of the engine. It must

be observed that in order to reduce the size of the reservoirs, which

are carried on the locomotive, the air inside them must be very highly

compressed; and that in going from the reservoir into the cylinder it

passes through a reducing valve or expander, which keeps the pressure of

admission at a definite figure, so that the locomotive can continue working

so long as the supply of air contained in the reservoir has not come down

to this limiting pressure. The air does not pass the expander until after

it has gone through the boiler already mentioned. Therefore, if the

temperature which it assumes in the boiler is 100 deg. Cent. (212 deg. Fahr.), and

if the limiting pressure is 5 atm., the gas which enters the engine will be

a mixture of air and water vapor at 100 deg. Cent.; and of its total pressure

the vapor of water will contribute I atm. and the air 4 atm. Thus this

contrivance, by a small expenditure of fuel, enables the air to act

expansively without injurious cooling, and even reduces the consumption of

compressed air to an extent which compensates for part of the loss of power

arising from the preliminary expansion which the air experiences before its

admission into the engine. It is clear that this same contrivance, or what

amounts to the same thing, a direct injection of steam, at a sufficient

pressure, for the purpose of maintaining the expanding air at a constant

temperature, might be tried in a fixed engine worked by compressed air with

some chance of success.

Whatever method is adopted it would be advantageous that the losses of

pressure in the pipes connecting the compressors with the motors should be

reduced as much as possible, for in this case that loss would represent

a loss of efficiency. If, on the other hand, owing to defective means of

reheating, it is necessary to remain satisfied with a small amount of

expansion, the loss of pressure in the pipe is unimportant, and has only

the effect of transferring the limited expansion to a point a little lower

on the scale of pressures. If W is the net disposable force on the shaft

of the engine which works the compressor, v1 the volume of air at the

compressor, p1. given by the compressor, and at the temperature of the

surrounding air, and p0 the atmospheric pressure, the efficiency of the

compressor, assuming the air to expand according to Boyle's law, is given

by the well-known formula--

p1 v1 log (p1 / p0)

-------------------.

[TEX: \frac{p_1 v_1 \log \frac{p_1}{p_0}}{W}]

Let p2 be the value to which the pressure is reduced by the loss of

pressure at the end of the conduit, and v2 the volume which the air

occupies at this pressure and at the same temperature; the force stored

up in the air at the end of its course through the conduit is p2 v2

log(p2/p0); consequently, the efficiency of the conduit is

p2 v2 log(p2/p0)

----------------

p1 v1 log(p1/p0)

[TEX: \frac{p_2 v_2 \log\frac{p_2}{p_0}}{p_2 v_2 \log\frac{p_2}{p_0}}]

a fraction that may be reduced to the simple form

log(p2/p0)

----------,

log(p1/p0)

[TEX: \frac{\log\frac{p_2}{p_0}}{\log\frac{p_2}{p_0}}]

if there is no leakage during the passage of the air, because in that cause

p2 v2 = p1 v1. Lastly, if W1 is the net disposable force on the shaft of

the compressed air motor, the efficiency of this engine will be,

----------------

p2 v2 log(p2/p0)

[TEX: \frac{W_1}{p_2 v_2 \log \frac{p_2}{p_0}}]

and the product of these three partial efficiencies is equal to W1/W, the

general efficiency of the transmission.

III. _Transmission by Pressure Water_.--As transmission of power by

compressed air has been specially applied to the driving of tunnels, so

transmission by pressure water has been specially resorted to for lifting

heavy loads, or for work of a similar nature, such as the operations

connected with the manufacture of Bessemer steel or of cast-iron pipes.

The author does not propose to treat of transmissions established for this

special purpose, and depending on the use of accumulators at high pressure,

as he has no fresh matter to impart on this subject, and as he believes

that the remarkable invention of Sir William Armstrong was described for

the first time, in the "Proceedings of the Institution of Mechanical

Engineers." His object is to refer to transmissions applicable to general

purposes.

The transmission of power by water may occur in another form. The motive

force to be transmitted may be employed for working pumps which raise the

water, not to a fictitious height in an accumulator, but to a real height

in a reservoir, with a channel from this reservoir to distribute the water

so raised among several motors arranged for utilizing the pressure. The

author is not aware that works have been carried out for this purpose.

However, in many towns a part of the water from the public mains serves to

supply small motors--consequently, if the water, instead of being brought

by a natural fall, has been previously lifted artificially, it might be

said that a transmission of power is here grafted on to the ordinary

distribution of water.

Unless a positive or negative force of gravity is introduced into the

problem, independently of the force to be transmitted, the receivers of

the water pressure must be assumed to be at the same level as the forcing

pumps, or more correctly, the water discharged from the receivers to be at

the same level as the surface of the water from which the pumps draw their

supply. In this case the general efficiency of transmission is the product

of three partial efficiencies, which correspond exactly to those mentioned

with regard to compressed air. The height of lift, contained in the

numerator of the fraction which expresses the efficiency of the pumps, is

not to be taken as the difference in level between the surface of the water

in the reservoir and the surface of the water whence the pumps draw their

supply; but as this difference in level, plus the loss of pressure in the

suction pipe, which is usually very short, and plus the loss in the channel

to the reservoir, which may be very long. A similar loss of initial

pressure affects the efficiency of the discharge channel. The reservoir, if

of sufficient capacity, may become an important store of power, while the

compressed air reservoir can only do so to a very limited extent.

Omitting the subject of the pumps, and passing on at once to the discharge

main, the author may first point out that the distinction between the

ascending and descending mains of the system is of no importance, for two

reasons: first, that nothing prevents the motors being supplied direct from

the first alone; and second, that the one is not always distinct from the

other. In fact, the reservoir may be connected by a single branch pipe with

the system which goes from the pumps to the motors; it may even be placed

at the extreme end of this system beyond the motors, provided always that

the supply pipe is taken into it at the bottom. The same formula may be

adopted for the loss of initial pressure in water pipes as for compressed

air pipes, viz.,

p1 - p 64 b1

------- = --------- L Q squared +- h;

[Delta] [pi] squared D^5

[TEX: \frac{p_1 - p}{\Delta} = \frac{64 b_1}{\pi^2 D^5} L Q^2 \pm h]

h being the difference of level between the two ends of the portion of

conduit of length, L, and the sign + or - being used according as the

conduit rises or falls. The specific weight, [delta], is constant, and the

quotients, p1/[delta] and p/[delta], represent the heights, z and z1, to

which the water could rise above the pipes, in vertical tubes branching

from it, at the beginning and end of the transit. The values assigned to

the coefficient b1 in France, are those determined by D'Arcy. For new

cast-iron pipes he gives b1 - 0.0002535 + 1/D 0.000000647; and recommends

that this value should be doubled, to allow for the rust and incrustation

which more or less form inside the pipes during use. The determination of

this coefficient has been made from experiments where the pressure has

not exceeded four atmospheres; within these limits the value of the

coefficient, as is generally admitted, is independent of the pressure. The

experiments made by M. Barret, on the pressure pipes of the accumulator at

the Marseilles docks, seem to indicate that the loss of pressure would be

greater for high pressures, everything else being equal. This pipe, having

a diameter of 0.127 m. (5 in.), was subjected to an initial pressure of 52

atmospheres. The author gives below the results obtained for a straight

length 320 m. (1050 ft) long; and has placed beside them the results which

D'Arcy's formula would give.

Loss of head, in meters or ft. respectively

per 100 meters or ft. run of pipes.

+-----------------^-------------------+

| |

Calculated loss.

+-----------^-----------+

| |

Velocity of flow Actual loss

per second. observed. Old pipes. New pipes.

Meters. Feet. Met. or Ft. Met. or Ft. Met. or Ft.

0.25 0.82 1.5 0.12 0.06

0.50 1.64 2.5 0.48 0.24

0.75 2.46 3.7 1.08 0.54

1.00 3.28 5.5 1.92 0.96

1.25 4.10 6.1 3.00 1.50

1.50 4.92 7.3 4.32 2.16

1.75 5.74 8.0 5.88 2.94

2.00 6.56 10.2 7.68 3.84

2.25 7.38 11.7 9.72 4.86

2.50 8.20 14.0 12.00 6.00

Moreover, these results would appear to indicate a different law from that

which is expressed by the formula b1 u squared, as is easy to see by representing

them graphically. It would be very desirable that fresh experiments should

be made on water pipes at high pressure, and of various diameters. Of

machines worked by water pressure the author proposes to refer only to two

which appear to him in every respect the most practical and advantageous.

One is the piston machine of M. Albert Schmid, engineer at Zurich. The

cylinder is oscillating, and the distribution is effected, without an

eccentric, by the relative motion of two spherical surfaces fitted one

against the other, and having the axis of oscillation for a common axis.

The convex surface, which is movable and forms part of the cylinder, serves

as a port face, and has two ports in it communicating with the two ends of

the cylinder. The concave surface, which is fixed and plays the part of a

slide valve, contains three openings, the two outer ones serving to admit

the pressure water, and the middle one to discharge the water after it has

exerted its pressure. The piston has no packing. Its surface of contact has

two circumferential grooves, which produce a sort of water packing acting

by adhesion. A small air chamber is connected with the inlet pipe, and

serves to deaden the shocks. This engine is often made with two cylinders,

having their cranks at right angles.

The other engine, which is much less used, is a turbine on Girard's system,

with a horizontal axis and partial admission, exactly resembling in

miniature those which work in the hydraulic factory of St. Maur, near

Paris. The water is introduced by means of a distributer, which is fitted

in the interior of the turbine chamber, and occupies a certain portion

of its circumference. This turbine has a lower efficiency than Schmid's

machine, and is less suitable for high pressures; but it possesses this

advantage over it, that by regulating the amount of opening of the

distributer, and consequently the quantity of water admitted, the force can

be altered without altering the velocity of rotation. As it admits of great

speeds, it could be usefully employed direct, without the interposition of

spur wheels or belts for driving magneto-electric machines employed for the

production of light, for electrotyping, etc.

In compressed air machines the losses of pressure due to incomplete

expansion, cooling, and waste spaces, play an important part. In water

pressure machines loss does not occur from these causes, on account of the

incompressibility of the liquid, but the frictions of the parts are the

principal causes of loss of power. It would be advisable to ascertain

whether, as regards this point, high or low pressures are the most

advantageous. Theoretical considerations would lead the author to imagine

that for a piston machine low pressures are preferable. In conclusion, the

following table gives the efficiencies of a Girard turbine, constructed by

Messrs. Escher Wyss & Co., of Zurich, and of a Schmid machine, as measured

by Professor Fliegnor, in 1871:

ESCHER WYSS & CO'S TURBINE.

Effective Head of Water. Revolutions Efficiency.

per minute.

Meters. Feet. Revs. Per cent.

20.7 67.9 628 68.5

20.7 67.9 847 47.4

24.1 79.0 645 68.5

27.6 90.5 612 65.7

27.6 90.5 756 68.0

31.0 101.7 935 56.9

31.0 101.7 1,130 35.1

SCHMID MOTOR.

8.3 27.2 226 37.4

11.4 37.4 182 67.4

14.5 47.6 254 53.4

17.9 58.7 157 86.2

20.7 67.9 166 89.6

20.7 67.9 225 74.6

24.1 79.0 238 76.7

24.1 79.0 389 64.0

27.6 90.5 207 83.9

It will be observed that these experiments relate to low pressures; it

would be desirable to extend them to higher pressures.

IV. _Transmission by Electricity._--However high the efficiency of an

electric motor may be, in relation to the chemical work of the electric

battery which feeds it, force generated by an electric battery is too

expensive, on account of the nature of the materials consumed, for a

machine of this kind ever to be employed for industrial purposes. If,

however, the electric current, instead of being developed by chemical

work in a battery, is produced by ordinary mechanical power in a

magneto-electric or dynamo-electric machine, the case is different; and

the double transformation, first of the mechanical force into an electric

current, and then of that current into mechanical force, furnishes a means

for effecting the conveyance of the power to a distance.

It is this last method of transmission which remains to be discussed. The

author, however, feels himself obliged to restrict himself in this matter

to a mere summary; and, indeed, it is English physicists and engineers who

have taken the technology of electricity out of the region of empiricism

and have placed it on a scientific and rational basis. Moreover, they are

also taking the lead in the progress which is being accomplished in this

branch of knowledge, and are best qualified to determine its true bearings.

When an electric current, with an intensity, i, is produced, either by

chemical or mechanical work, in a circuit having a total resistance, R, a

quantity of heat is developed in the circuit, and this heat is the exact

equivalent of the force expended, so long as the current is not made use of

for doing any external work. The expression for this quantity of heat, per

unit of time, is Ai squaredR; A being the thermal equivalent of the unit of power

corresponding to the units of current and resistance, in which i and R are

respectively expressed. The product, i squaredR, is a certain quantity of power,

which the author proposes to call _power transformed into electricity_.

When mechanical power is employed for producing a current by means of

a magneto-electric or dynamo-electric machine--or, to use a better

expression, by means of a _mechanical generator of electricity_--it is

necessary in reality to expend a greater quantity of power than i squaredR in

order to make up for losses which result either from ordinary friction

or from certain electro magnetic reactions which occur. The ratio of the

quantity, i squaredR, to the power, W, actually expended per unit of time is

called the efficiency of the generator. Designating it by K, we obtain, W

= i squaredR/K. It is very important to ascertain the value of this efficiency,

considering that it necessarily enters as a factor into the evaluation of

all the effects to be produced by help of the generator in question. The

following table gives the results of certain experiments made early in

1879, with a Gramme machine, by an able physicist, M Hagenbach, Professor

at the University at Basle, and kindly furnished by him to the author:

Revolutions per minute 935 919.5 900.5 893

Total resistance in Siemens' units 2.55 3.82 4.94 6.06

Total resistance in absolute units 2.435 3.648 4.718 5.787

x10^9 x10^9 x10^9 x10^9

Intensity in chemical units 17.67 10.99 8.09 6.28

Intensity in absolute units 2.828 1.759 1.295 1.005

Work done i squaredR in absolute units 1948.6 1129.2 791.3 584.9

x10^7 x10^7 x10^7 x10^7

Work done i squaredR in kilogrammes 198.6 115.1 80.66 59.62

Power expended in kilogrammes 301.5 141.0 86.25 83.25

Efficiency, per cent. 65.9 81.6 93.5 71.6

M. Hagenbach's dynamometric measurements were made by the aid of a brake.

After each experiment on the electric machine, he applied the brake to the

engine which he employed, taking care to make it run at precisely the same

speed, with the same pressure of steam, and with the same expansion as

during experiment. It would certainly be better to measure the force

expended during and not after the experiment, by means of a registering

dynamometer. Moreover, M. Hagenbach writes that his measurements by means

of the brake were very much prejudiced by external circumstances; doubtless

this is the reason of the divergences between the results obtained.

About the same time Dr. Hopkinson communicated to this institution the

results of some very careful experiments made on a Siemens machine. He

measured the force expended by means of a registering dynamometer, and

obtained very high coefficients of efficiency, amounting to nearly 90 per

cent. M. Hagenbach also obtained from one machine a result only a little

less than unity. Mechanical generators of electricity are certainly

capable of being improved in several respects, especially as regards their

adaptation to certain definite classes of work. But there appears to

remain hardly any margin for further progress as regards efficiency. Force

transformed into electricity in a generator may be expressed by i [omega] M

C; [omega] being the angular velocity of rotation; M the magnetism of one

of the poles, inducing or induced, which intervenes; and C a constant

specially belonging to each apparatus, and which is independent of

the units adopted. This constant could not be determined except by

an integration practically impossible; and the product, M C, must be

considered indivisible. Even in a magneto-electric machine (with permanent

inducing magnets), and much more in a dynamo-electric machine (inducing by

means of electro-magnets excited by the very current produced) the product,

M C, is a function of the intensity. From the identity of the expressions,

i squaredR and i [omega] M C we obtain the relation M C = IR/[omega] which

indicates the course to be pursued to determine experimentally the law

which connects the variations of M C with those of i. Some experiments made

in 1876, by M. Hagenbach, on a Gramme dynamo-electric machine, appear to

indicate that the magnetism, M C, does not increase indefinitely with the

intensity, but that there is some maximum value for this quantity. If,

instead of working a generator by an external motive force, a current is

passed through its circuit in a certain given direction, the movable part

of the machine will begin to turn in an opposite direction to that in which

it would have been necessary to turn it in order to obtain a current in the

aforesaid direction. In virtue of this motion the electro-magnetic forces

which are generated may be used to overcome a resisting force. The machine

will then work as a motor or receiver. Let i be the intensity of the

external current which works the motor, when the motor is kept at rest. If

it is now allowed to move, its motion produces, in virtue of the laws of

induction, a current in the circuit of intensity, i1, in the opposite

direction to the external current; the effective intensity of the current

traversing the circuit is thus reduced to i - i1. The intensity of the

counter current is given, like that of the generating current, by the

equation, i1 squaredR = i1 [omega]1 M1 C1, or i1R = [omega]1 M1 C1, the index, 1,

denoting the quantities relating to the motor. Here M1 C1 is a function of

i - i1, not of i. As in a generator the force transformed into electricity

has a value, i [omega] M C, so in a motor the force developed by

electricity is (i - i1) [omega]1 M1 C1. On account, however, of the losses

which occur, the effective power, that is the disposable power on the shaft

of the motor, will have a smaller value, and in order to arrive at it a

coefficient of efficiency, K1, must be added. We shall then have W1 = K1

(i-i1) [omega]1 M1 C1. The author has no knowledge of any experiments

having been made for obtaining this efficiency, K1. Next let us suppose

that the current feeding the motor is furnished by a generator, so that

actual transmission by electricity is taking place. The circuit, whose

resistance is R, comprises the coils, both fixed and movable, of the

generator and motor, and of the conductors which connect them. The

intensity of the current which traverses the circuit had the value, i, when

the motor was at rest; by the working of the motor it is reduced to i - i1.

The power applied to the generator is itself reduced to W-[(i-i1)[omega]

M C]/K. The prime mover is relieved by the action of the counter current,

precisely as the consumption of zinc in the battery would be reduced by the

same cause, if the battery was the source of the current. The efficiency

of the transmission is W1/W. Calculation shows that it is expressed by the

following equations:W1/W = K K1 [([omega]11 M1 C1)/([omega]1 M C)], or = K

K1 [([omega]11 M1 C)/([omega]11 M1 C1 + (i-i1) R)]; expressions in which

it must be remembered M C and M1 C1 are really functions of (i-i1). This

efficiency is, then, the product of three distinct factors, each evidently

less than unity, namely, the efficiency belonging to the generator, the

efficiency belonging to the motor, and a third factor depending on the rate

of rotation of the motor and the resistance of the circuit. The influence

which these elements exert on the value of the third factor cannot be

estimated, unless the law is first known according to which the magnetisms,

M C, M1 C C1, vary with the intensity of the current.

GENERAL RESULTS.

Casting a retrospective glance at the four methods of transmission of power

which have been examined, it would appear that transmission by ropes forms

a class by itself, while the three other methods combine into a natural

group, because they possess a character in common of the greatest

importance. It may be said that all three involve a temporary

transformation of the mechanical power to be utilized into potential

energy. Also in each of these methods the efficiency of transmission is

the product of three factors or partial efficiencies, which correspond

exactly--namely, first, the efficiency of the instrument which converts

the actual energy of the prime mover into potential energy; second, the

efficiency of the instrument which reconverts this potential energy into

actual energy, that is, into motion, and delivers it up in this shape

for the actual operations which accomplish industrial work; third, the

efficiency of the intermediate agency which serves for the conveyance of

potential energy from the first instrument to the second.

This last factor has just been given for transmission by electricity. It

is the exact correlative of the efficiency of the pipe in the case of

compressed air or of pressure water. It is as useful in the case of

electric transmission, as of any other method, to be able, in studying the

system, to estimate beforehand what results it is able to furnish, and for

this purpose it is necessary to calculate exactly the factors which compose

the efficiency.

In order to obtain this desirable knowledge, the author considers that the

three following points should form the aim of experimentalists: First,

the determination of the efficiency, K, of the principal kinds of

magneto-electric, or dynamo-electric machines working as generators;

second, the determination of the efficiency, K1, of the same machines

working as motors; third, the determination of the law according to which

the magnetism of the cores of these machines varies with the intensity of

the current. The author is of opinion that experiments made with these

objects in view would be more useful than those conducted for determining

the general efficiency of transmission, for the latter give results only

available under precisely similar conditions. However, it is clear that

they have their value and must not be neglected.

There are, moreover, many other questions requiring to be elucidated by

experiment, especially as regards the arrangement of the conducting wires:

but it is needless to dwell further upon this subject, which has been ably

treated by many English men of science--for instance, Dr. Siemens and

Professor Ayrton. Nevertheless, for further information the author would

refer to the able articles published at Paris, by M. Mascart, in the

_Journal de Physique_, in 1877 and 1878. The author would gladly have

concluded this paper with a comparison of the efficiencies of the four

systems which have been examined, or what amounts to the same thing--with a

comparison of the losses of power which they occasion. Unfortunately, such

a comparison has never been made experimentally, because hitherto the

opportunity of doing it in a demonstrative manner has been wanting, for the

transmission of power to a distance belongs rather to the future than to

the present time. Transmission by electricity is still in its infancy; it

has only been applied on a small scale and experimentally.

Of the three other systems, transmission by means of ropes is the only one

that has been employed for general industrial purposes, while compressed

air and water under pressure have been applied only to special purposes,

and their use has been due much more to their special suitableness for

these purposes than from any considerations relative to loss of power.

Thus the effective work of the compressed air used in driving the

tunnels through the Alps, assuming its determination to be possible, was

undoubtedly very low; nevertheless, in the present state of our appliances

it is the only process by which such operations can be accomplished. The

author believes that transmission by ropes furnishes the highest proportion

of useful work, but that as regards a wide distribution of the transmitted

power the other two methods, by air and water, might merit a preference.

* * * * *

THE HOTCHKISS REVOLVING GUN.

The Hotchkiss revolving gun, already adopted in the French navy and by

other leading European nations, has been ordered for use in the German navy

by the following decree of the German Emperor, dated January 11 last: "On

the report made to me, I approve the adoption of the Hotchkiss revolving

cannon as a part of the artillery of my navy; and each of my ships,

according to their classification, shall in general be armed with this

weapon in such a manner that every point surrounding the vessel may be

protected by the fire of at least two guns at a minimum range of 200

meters."

* * * * *

THALLIUM PAPERS AS OZONOMETERS.

Schoene has given the results of an extended series of experiments on the

use of thallium paper for estimating approximately the oxidizing material

in the atmosphere, whether it be hydrogen peroxide alone, or mixed with

ozone, or perhaps also with other constituents hitherto unknown. The

objection to Schoenbein's ozonometer (potassium iodide on starch paper) and

to Houzeau's ozonometer (potassium iodide on red litmus paper) lies in

the fact that their materials are hygroscopic, and their indications vary

widely with the moisture of the air. Since dry ozone does not act on these

papers, they must be moistened; and then the amount of moisture varies the

result quite as much as the amount of ozone. Indeed, attention has been

called to the larger amount of ozone near salt works and waterfalls, and

the erroneous opinion advanced that ozone is formed when water is finely

divided. And Boettger has stated that ozone is formed when ether is

atomized; the fact being that the reaction he observed was due to the

H_2O_2 always present in ether. Direct experiments with the Schoenbein

ozonometer and the psychrometer gave parallel curves; whence the author

regards the former as only a crude hygrometer. These objections do not lie

against the thallium paper, the oxidation to brown oxide by either ozone or

hydrogen peroxide not requiring the presence of moisture, and the color,

therefore, being independent of the hygrometric state of the air. Moreover,

when well cared for, the papers undergo no farther change of color and may

be preserved indefinitely. The author prepares the thallium paper a few

days before use, by dipping strips of Swedish filtering paper in a solution

of thallous hydrate, and drying. The solution is prepared by pouring a

solution of thallous sulphate into a boiling solution of barium hydrate,

equivalent quantities being taken, the resulting solution of thallous

hydrate being concentrated in vacuo until 100 c.c. contains 10 grammes

Tl(OH). For use the strips are hung in the free air in a close vessel,

preferably over caustic lime, for twelve hours. Other papers are used, made

with a two per cent. solution. These are exposed for thirty-six hours. The

coloration is determined by comparison with a scale having eleven degrees

of intensity upon it. Compared with Schoenbein's ozonometer, the results are

in general directly opposite. The thallium papers show that the greatest

effect is in the daytime, the iodide papers that it is at night. Yearly

curves show that the former generally indicate a rise when the latter give

a fall. The iodide curve follows closely that of relative humidity, clouds,

and rain; the thallium curve stands in no relation to it. A table of

results for the year 1879 is given in monthly means, of the two thallium

papers, the ozonometer, the relative humidity, cloudiness, rain, and

velocity of wind.--_G. F. B., in Ber. Berl. Chem. Ces._

* * * * *

THE AUDIPHONE IN ENGLAND.

The audiphone has been recently tried in the Board School for Deaf and

Dumb at Turin street, Bethnal Green, with very satisfactory results--so

satisfactory that the report will recommend its adoption in the four

schools which the London Board have erected for the education of the deaf

and dumb. Some 20 per cent. of the pupils in deaf and dumb schools have

sufficient power of hearing when assisted by the audiphone to enable them

to take their places in the classes of the ordinary schools.

* * * * *

CONDUCTIVITY OF MOIST AIR.

Many physical treatises still assert that moist air conducts electricity,

though Silberman and others have proved the contrary. An interesting

experiment bearing on this has been described lately by Prof. Marangoni.

Over a flame is heated some water in a glass jar, through the stopper of

which passes a bent tube to bell-jar (held obliquely), which thus gets

filled with aqueous vapor. The upper half of a thin Leyden jar charged is

brought into the bell-jar, and held there four or five seconds; it is

then found entirely discharged. That the real cause of this, however, is

condensation of the vapor on the part of the glass that is not coated with

tin foil (the liquid layer acting by conduction) can be proved; for if that

part of the jar be passed several times rapidly through the flame, so as

to heat it to near 100 deg. C., before inserting in the bell-jar, a different

effect will be had; the Leyden jar will give out long sparks after

withdrawal. This is because the glass being heated no longer condenses the

vapor on its surface, and there is no superficial conduction, as in the

previous case.

* * * * *

FLOATING PONTOON DOCK.

Considerable attention has been given for some years past to the subject of

floating pontoon docks by Mr. Robert Turnbull, naval architect, of South

Shields, Eng., who has devised the ingenious arrangement which forms the

subject of the annexed illustration. The end aimed at and now achieved by

Mr. Turnbull was so to construct floating docks or pontoons that they may

rise and fall in a berth, and be swung round at one end upon a center post

or cylinder--nautically known as a dolphin--projecting from the ground at

a slight distance from the berth. The cylinder is in deep water, and,

when the pontoon is swung and sunk to the desired depth by letting in the

necessary amount of water, a vessel can be floated in and then secured. The

pontoon, with the vessel on it, is then raised by pumping out the contained

water until she is a little above the level of the berth. The whole is then

swung round over the berth, the vessel then being high and dry to enable

repairs or other operations to be conducted. For this purpose, one end of

the pontoon is so formed as to enable it to fit around the cylinder, and

to be held to it as to a center or fulcrum, about which the pontoon can be

swung. The pontoon is of special construction, and has air-chambers at the

sides placed near the center, so as to balance it. It also has chambers at

the ends, which are divided horizontally in order that the operation of

submerging within a berth or in shallow water may be conducted without

risk, the upper chambers being afterwards supplied with water to sink the

pontoon to the full depth before a vessel is hauled in. When the ship is in

place, the pontoon with her is then lifted above the level of the berth in

which it has to be placed, and then swung round into the berth. In some

cases, the pontoon is provided with a cradle, so that, when in berth, the

vessel on the cradle can be hauled up a slip with rails arranged as

a continuation of the cradle-rails of the pontoon, which can be then

furnished with another cradle, and another vessel lifted.

It is this latter arrangement which forms the subject of our illustration,

the vessel represented being of the following dimensions: Length between

perpendiculars, 350 feet; breadth, moulded, 40 feet; depth, moulded, 32

feet; tons, B. M., 2,600; tons net, 2,000. At A, in fig. 1, is shown in

dotted lines a portion of the vessel and pontoon, the ship having just been

hauled in and centered over the keel blocks. At B, is shown the pontoon

with the ship raised and swung round on to a low level quay. Going a step

further in the operation, we see at C, the vessel hauled on to the slipways

on the high-level quay. In this case the cylinder is arranged so that

the vessel may be delivered on to the rails or slips, which are arranged

radially, taking the cylinder as the center. There may be any number of

slips so arranged, and one pontoon may be made available for several

cylinders at the deep water parts of neighboring repairing or building

yards, in which case the recessed portion of the pontoon, when arranged

around the cylinder, has stays or retaining bars fitted to prevent it

leaving the cylinder when the swinging is taking place, such as might

happen in a tideway.

[Illustration: Fig. 1. IMPROVED FLOATING PONTOON DRY DOCK.]

The arrangements for delivering vessels on radial slips is seen in plan at

fig. 2, where A represents the river or deep water; B is the pontoon with

the vessel; C being the cylinder or turning center; D is the low-level

quay on to which the pontoon carrying the ship is first swung; E is the

high-level quay with the slip-ways; F is an engine running on rails around

the radial slips for drawing the vessels with the cradle off the pontoon,

and hauling them up on to the high-level quay; and G shows the repairing

shops, stores, and sheds. A pontoon attached to a cylinder may be fitted

with an ordinary wet dock; and then the pontoon, before or after the vessel

is upon it, can be slewed round to suit the slips up which the vessel has

to be moved, supposing the slips are arranged radially. In this case, the

pivot end of the pontoon would be a fixture, so to speak, to the cylinder.

The pontoon may also be made available for lifting heavy weights, by

fitting a pair of compound levers or other apparatus at one end, the

lifting power being in the pontoon itself. In some cases, in order to

lengthen the pontoon, twenty-five or fifty foot lengths are added at

the after end. When not thus engaged, those lengths form short pontoons

suitable for small vessels.--_Iron_.

* * * * *

WEIRLEIGH, BRENCHLEY, KENT.

Some few years since, Mr. Harrison Weir (whose drawings of natural history

are known probably to a wider circle of the general public than the works

of most artists), wishing to pursue his favorite study of animals and

horticulture, erected on the steep hillside of the road leading from

Paddock Wood to Brenchley, a small "cottage ornee" with detached studio.

Afterward desiring more accommodation, he carried out the buildings shown

in our illustrations. Advantage has been taken of the slope of the hill on

one side, and the rising ground in the rear on the other, to increase the

effect of the buildings and meet the difficulty of the levels. The two

portions--old, etched, and new, shown as black--are connected together by a

handsome staircase, which is carried up in the tower, and affords access to

the various levels. The materials are red brick, with Bathstone dressings,

and weather-tiling on the upper floors. Black walnut, pitch pine, and

sequoias have been used in the staircase, and joiner's work to the

principal rooms. The principal stoves are of Godstone stone only, no iron

or metal work being used. The architects are Messrs. Wadmore & Baker, of 35

Great St. Helens, E.C.; the builders, Messrs. Penn Brothers, of Pembury,

Kent.--_Building News_.

[Illustration: ARTISTS HOMES NO 11 "WEIRLEIGH" BRENCHLEY, KENT. THE

RESIDENCE OF HARRISON WEIR ESQ'RE WADMORE & BAKER ARCHITECTS]

* * * * *

RAPID BREATHING AS A PAIN OBTUNDER IN MINOR SURGERY, OBSTETRICS, THE

GENERAL PRACTICE OF MEDICINE AND OF DENTISTRY.

[Footnote: Read before the Philadelphia County Medical Society, May 12,

1880, by W. G. A. Bonwill, M.D., D.D.S., Philadelphia.]

Through the kind invitation of your directors, I am present to give you

the history of "rapid breathing" as an analgesic agent, as well as my

experience therein since I first discovered it. It is with no little

feeling of modesty that I appear before such a learned and honorable

body of physicians and surgeons, and I accept the privilege as a high

compliment. I trust the same liberal spirit which prompted you to call this

subject to the light of investigation will not forsake you when you have

heard all I have to say and you sit in judgment thereon. Sufficient time

has now elapsed since the first promulgation of the subject for the shafts

of ridicule to be well nigh spent (which is the common logic used to crush

out all new ideas), and it is to be expected that gentlemen will look upon

it with all the charity of a learned body, and not be too hasty to condemn

what they have had but little chance to investigate; and, of course, have

not practiced with that success which can only come from an intelligent

understanding of its application and _modus operandi_.

Knowing the history of past discoveries, I was well prepared for the

crucible. I could not hope to be an exception. But, so far, the medical

profession have extended me more favor than I have received at the hands of

the dental profession.

My first conception of the analgesic property of a pain obtunder in

contradistinction to its anaesthetic effect, which finally led to the

discovery of the inhalation of common air by "rapid breathing," was in 1855

or 1856, while performing upon my own teeth certain operations which gave

me intense pain (and I could not afford to hurt myself) without a resort to

ether and chloroform. These agents had been known so short a time that no

one was specially familiar with their action. Without knowing whether I

could take chloroform administered by myself, and at the same time perform

with skill the excavation of extremely sensitive dentine or tooth-bone, as

if no anaesthetic had been taken, and not be conscious of pain, was more

than the experience of medical men at that time could assure me. But,

having a love for investigation of the unknown, I prepared myself for the

ordeal. By degrees I took the chloroform until I began to feel very plainly

its primary effects, and knowing that I must soon be unconscious, I applied

the excavator to the carious tooth, and, to my surprise, found no pain

whatever, but the sense of touch and hearing were marvelously intensified.

The small cavity seemed as large as a half bushel; the excavator more the

size of an ax; and the sound was equally magnified. That I might not be

mistaken, I repeated the operation until I was confident that anaesthetics

possessed a power not hitherto known--that of analgesia. To be doubly

certain, I gave it in my practice, in many cases with the same happy

results, which saved me from the risks incident to the secondary effects of

anaesthetics, and which answered for all the purposes of extracting from

one to four teeth. Not satisfied with any advance longer than I could find

a better plan, I experimented with the galvanic current (to and fro) by so

applying the poles that I substituted a stronger impression by electricity

from the nerve centers or ganglia to the peripheries than was made from the

periphery to the brain. This was so much of a success that I threw

aside chloroform and ether in removing the living nerve of a tooth with

instruments instead of using arsenic; and for excavating sensitive caries

in teeth, preparatory to filling, as well as many teeth extracted by it.

But this was short-lived, for it led to another step. Sometimes I would

inflict severe pain in cases of congested pulps or from its hasty

application, or pushing it to do too much, when my patient invariably would

draw or inhale the breath _very forcibly and rapidly_. I was struck with

the repeated coincidence, and was led to exclaim: "Nature's anaesthetic."

This then reminded me of boyhood's bruises. The involuntary action of every

one who has a finger hurt is to place it to the mouth and draw violently in

the air and hold it for an instant, and again repeat it until the pain is

subdued. The same action of the lungs occurs, except more powerfully,

in young children who take to crying when hurt. It will be noticed they

breathe very rapidly while furiously crying, which soon allays the

irritation, and sleep comes as the sequel. Witness also when one is

suddenly startled, how violently the breath is taken, which gives relief.

The same thing occurs in the lower animals when pain is being inflicted at

the hand of man.

This was advance No. 3, and so sure was I of this new discovery, that I at

once made an application while removing decay from an extremely sensitive

tooth. To be successful, I found I must make the patient take the start,

and I would follow with a thrust from the excavator, which move would be

accomplished before the lungs could be inflated. This was repeated for

at least a minute, until the operation was completed, I always following

immediately or synchronously with the inhalation.

This led to step No. 4, which resulted in its application to the extracting

of teeth and other operations in minor surgery.

Up to this time I had believed the sole effect of the rapid inhalation was

due to mere diversion of the will, and this was the only way nature could

so violently exert herself--that of controlling the involuntary action of

the lungs to her uses by the _safety valve_, or the voluntary movement.

The constant breathing of the patient for thirty seconds to a minute left

him in a condition of body and mind resembling the effects of ether and

chloroform in their primary stages. I could but argue that the prolonged

breathing each time had done it; and, if so, then there must be some

specific effect over and above the mere diversion by the will. To what

could it be due? To the air alone, which went in excess into the lungs in

the course of a minute! Why did I not then immediately grasp the idea of

its broader application as now claimed for it? It was too much, gentlemen,

for that hour. Enough had been done in this fourth step of conception to

rest in the womb of time, until by evolution a higher step could be made at

the maturity of the child. Being self-satisfied with my own baby, I watched

and caressed it until it could take care of itself, and my mind was again

free for another conception.

The births at first seemed to come at very short intervals; but see how

long it was between the fourth and the fifth birth. It was soon after that

my mind became involved in inventions--a hereditary outgrowth--and the

electric mallet and then the dental engine, the parent of your surgical

engine, to be found in the principal hospitals of this city, took such

possession of my whole soul, that my air analgesic was left slumbering. It

was not until August, 1875--nineteen years after--that it again came up in

full force, without any previous warning.

This time it was no law of association that revived it; but it seemed

the whispering of some one in the air--some ethereal spirit, if you

please--which instituted it, and advanced the following problem: "Nitrous

oxide gas is composed of the same elements as ordinary air, with a larger

equivalent of oxygen, except it is a chemical compound, not a mechanical

mixture, and its anaesthetic effects are said to be due to the excess of

oxygen. If this be a fact, then why can you not produce a similar effect by

rapid breathing for a minute, more or less, by which a larger quantity of

oxygen is presented in the lungs for absorption by the blood?"

This query was soon answered by asking myself another: "If the rapid

inhalation of air into the lungs does not increase the heart's action and

cause it to drive the blood in exact ratio to the inhalations, then _I can_

produce partial anaesthesia from this excess of oxygen brought about by the

voluntary movements over their ordinary involuntary action of the lungs."

The next question was: Will my heart be affected by this excess of air in

the lungs to such an extent that there will be a full reciprocity between

them? Without making any trial of it, I argued that, while there is no

other muscular movement than that of the chest as under the control of the

will, and as nature has given to the will the perfect control over the

lungs to supply more or less air, as is demanded by the pneumogastric nerve

for the immediate wants of the economy, when the _involuntary action_ is

not sufficient; and the heart not being under the control of the will, and

its action never accelerated or diminished except by a specific poison, or

from the general activity of the person in violent running or working, the

blood is forced into the heart faster and must get rid of it, when a larger

supply of oxygen is demanded and rapid breathing must occur, or asphyxia

result. I was not long in deciding that the heart _would not be

accelerated_ but a trifle--say a tenth--and, under the circumstances, I

said: "The air _is_ an anaesthetic."

From this rapid course of argument, I was so profoundly convinced of its

truth, that without having first tried it upon my own person, I would have

sat where I was, upon the curbstone, and had a tooth removed with the

perfect expectation of absence of pain and of still being conscious of

touch. While yet walking with my children, I commenced to breathe as

rapidly as possible, and, as anticipated, found my steps growing shorter

and shorter, until I came to a stand, showing to my mind clearly that my

argument in advance was right, so far as locomotion was concerned; and,

upon referring to my pulse, I found but little acceleration.

To what other conclusion could I arrive from this argument, with the

foundation laid nineteen years before, when I established on my own person

by experiment the fact of analgesia as induced from chloroform, with the

many experiments in rapid respiration on tooth bone?

From this moment until its first application to the extraction of a tooth

you can well imagine my suspense. That I might not fail in the very first

attempt, I compelled myself and others in my household to breathe rapidly

to investigate the phenomenon. This gave me some idea as to the proper

method of proceeding in its administering.

The first case soon appeared, and was a perfect success, going far beyond

my anticipations, for the effect was such as to produce a partial paralysis

of the hands and arms to the elbow. Again and again I tried it in every

case of extraction and many other experiments, doubting my own senses for

a long time at a result so anomalous and paradoxical. I was reminded just

here of a phenomenon which gave me additional proof--that of blowing a

dull fire to revive it. For a minute or so one blows and blows in rapid

succession until, rising from the effort, a sense of giddiness for a

few moments so overcomes that the upright position is with difficulty

maintained. In this condition you are fitted for having a tooth extracted

or an abscess lanced.

Believing that I had something new to offer which might be of use to

suffering humanity, I read the first article upon it Nov. 17, 1875, before

the Franklin Institute. Shortly after I was invited before the Northern

Medical Society of this city to address them thereon. A number of medical

gentlemen have been using it in their practice, while the bulk of them have

spurned it as "negative" and preposterous, without an effort at trying it,

which I can _now_ very well understand.

Unless one is aware of the fact that in the use of any agent which has the

power to suspend the volition, it can be taken to that point where he is

still conscious of _touch and hearing_, and at the same time not cognizant

of pain inflicted, the action of rapid breathing could not be understood.

And I regret to say that of three-fourths of the medical men I have talked

with on the subject they had not been aware of such a possibility from

ether and chloroform. Until this analgesic state could be established in

their minds it was impossible to convince them that the excess of oxygen,

as obtained by rapid breathing, could be made to produce a similar effect.

_I_ should have been as reluctant as any one to believe it, had I not

personally experienced the effect while performing an operation which would

otherwise have been very painful. Such a result could not well be reached

by any course of reasoning.

Has it proven in my practice what has been claimed for it--a substitute

for the powerful anaesthetics in minor operations in surgery? Most

emphatically, yes! So completely has it fulfilled its humble mission in

my office, that I can safely assert there has not been more than five per

cent. of failures. I have given it under all circumstances of diseased

organs, and have seen no other than the happiest results in its after

effects. It may well be asked just here: Why has it not been more generally

and widely used by the dental profession as well as the medical, if it is

really what is claimed for it? The most satisfactory and charitable answer

to be given is, the failure upon their part to comprehend the _fact_ as

existing in chloroform and ether that there is such a state as analgesia;

or, in other words, that the animal economy is so organized, while the

sense of touch is not destroyed, but rather increased, the mind of the

subject fails to perceive a sense of pain when anaesthetics are given, and

the effects are manifested in the primary stage. As I before intimated,

such is the knowledge possessed by most of those who administer ether and

chloroform. This was enough to cause nearly every one to look upon it as a

bubble or air castle. Many gentlemen told me they tried it upon themselves,

and, while it affected them very seriously by giddiness, they still

_retained consciousness_; and, such being the case, no effect could be

produced for obtunding pain. Others told me they were afraid to continue

the breathing alarmed at the vertigo induced. And the practitioner who has

adopted it more effectively than any other laughed at me when I first told

him of the discovery; but his intimate association with me changed his

views after much explanation and argument between us.

It was hardly to be expected that without this knowledge of analgesia,

and without any explanation from me as to the _modus operandi_ of rapid

breathing, other than a few suggestions or directions as to how the effect

was induced, even the most liberal of medical men should be able to make

it effective, or have the least disposition to give it a preliminary trial

upon themselves, and, of course, would not attempt it upon a patient.

Notwithstanding, it found a few adherents, but only among my personal

_medical_ friends, with whom I had an opportunity to explain what I

believed its physiological action, and the cases of success in my own

practice. To this I have submitted as among the inevitable in the calendar

of discoveries of all grades.

My own profession have attempted to _ridicule_ it out of its birthright

and possible existence, which style of argument is not resorted to by true

logicians.

To all this I can truly say I have not for one moment faltered. I could

afford to wait. The liberality of this society alone fully compensates for

the seeming indisposition of the past, believing that it is proper that

every advance should be confronted, and, if in time found worthy, give it

God speed.

From its first conception I have diligently labored to solve its _modus

operandi_, and the doubt in my own mind as to whether I could be mistaken

in my observations. I asked the opinion of our best chemical teachers if

air could have such effect. One attributed it to oxygen stimulation, and

the other to nitrogen. Another gentleman told me the medical profession had

come to the conclusion that it was possible for me to thus extract teeth,

but it was due solely to my strong _personal magnetism_ (which power I was

not before aware I possessed).

Now, from what I have related of the successive and natural steps which

finally culminated in this process or plan of analgesia induced by an

excess of ordinary air taken forcibly into the lungs above what is

necessary for life, and from what I shall state as to the apparently

anomalous or paradoxical effects, with its physiological action, and the

simple tests made upon each of my patients, I shall trust to so convince

you of its plausibility and possibility that it will be made use of in

hundreds of minor operations where ether and chloroform are now used.

Aside from my assertion and that of its friends, that the effects can be

produced by air alone, you must have some light shed upon the causes of its

physiological action, which will appeal to your _medical_ reason.

To assign an action to any drug is difficult, and in the cases of ether and

the other anaesthetics a quarter of a century still finds many conflicting

opinions. This being true, you will deal leniently with me for the opinion

I hold as to their analgesic action. Of course it will be objected to,

for the unseen is, to a great extent, unknowable. Enough for my argument,

however; it seems to suit the case very well without looking for another;

and while it was based on the phenomenon resulting from many trials, and

not the trials upon it as a previous theory, I shall be content with it

until a better one can be found.

What is it I claim as a new discovery, and the facts and its philosophy?

I have asserted that I can produce, from rapidly breathing common air at

the rate of a hundred respirations a minute, a similar effect to that from

ether, chloroform, and nitrous oxide gas, in their primary stages; and I

can in this way render patients sufficiently insensible to acute pain from

any operation where the time consumed is not over twenty to thirty seconds.

While the special senses are in partial action, the sense of pain is

obtunded, and in many cases completely annulled, consciousness and general

sensibility being preserved.

To accomplish this, each patient must be instructed how to act and what to

expect. As simple as it may seem, there is a proper and consistent plan to

enable you to reach full success. Before the patient commences to inhale he

is informed of the fact that, while he will be unconscious of pain, he

will know full, or partially well, every touch upon the person; that the

inhalation must be vigorously kept up during the whole operation without

for an instant stopping; that the more energetically and steadily he

breathes, the more perfect the effect, and that if he cease breathing

during the operation, pain will be felt. Fully impress them with this

idea, for the very good reason that they may stop when in the midst of an

operation, and the fullest effects be lost. It is obligatory to do so on

account of its evanescent effects, which demand that the patient be pushed

by the operator's own energetic appeals to "go on." It is very difficult

for any person to respire more than one hundred times to the minute, as he

will become by that time so exhausted as not to be able to breathe at all,

as is evidenced by all who have thus followed my directions. For the next

minute following the completion of the operation the subject will not

breathe more than once or twice. Very few have force enough left to raise

hand or foot. The voluntary muscles have nearly all been subjugated and

overcome by the undue effort at forced inhalation of one hundred over

seventeen, the normal standard. It will be more fully understood further on

in my argument why I force patients, and am constantly speaking to them to

go on.

I further claim that for the past four years, so satisfactory has been the

result of this system in the extracting of teeth and deadening extremely

sensitive dentine, there was no longer any necessity for chloroform,

ether, or nitrous oxide in the dental office. That such teeth as cannot be

extracted by its aid can well be preserved and made useful, except in a

very few cases, who will not be forced to breathe.

The anaesthetics, when used in major operations, where time is needed for

the operation, can be made more effective by a lesser quantity when given

in conjunction with "rapid breathing." Drs. Garrettson and Hews, who have

thus tried it, tell me it takes one-half to three-fourths less, and the

after effects are far less nauseating and unpleasant.

As an agent in labor where an anaesthetic is indicated, it is claimed by

one who has employed it (Dr. Hews) in nearly every case for three years, he

has used "rapid breathing" solely, and to the exclusion of chloroform and

ether. For this I have his assertion, and have no doubt of it whatever, for

if any agent could break down the action of the voluntary muscles of the

parts involved, which prevent the involuntary muscles of the uterus from

having their fullest effect, it is this. The very act of rapid breathing so

affects the muscles of the abdomen as to force the contents of the uterus

downward or outward, while the specific effect of the air at the end of a

minute's breathing leaves the subject in a semi-prostrate condition, giving

the uterus full chance to act in the interim, because free of the will to

make any attempt at withholding the involuntary muscles of the uterus from

doing their natural work. It is self evident; and in this agent we claim

here a boon of inestimable value. And not least in such cases is, there is

no danger of hemorrhage, since the cause of the effect is soon removed.

In attestation of many cases where it has been tried, I have asked the

mother, and, in some cases, the attendants, whether anything else had been

given, and whether the time was very materially lessened, there has been

but one response, and that in its favor.

Gentlemen, if we are not mistaken in this, you will agree with me in saying

that it is no mean thing, and should be investigated by intelligent men and

reported upon. From my own knowledge of its effects in my practice, I am

bound to believe this gentleman's record.

I further claim for it a special application in dislocations. It has

certainly peculiar merits here, as the will is so nearly subjugated by

it as to render the patient quite powerless to resist your effort at

replacing, and at the same time the pain is subdued.

It is not necessary I should further continue special applications; when

its _modus operandi_ is understood, its adaptation to many contingencies

will of a sequence follow.

It is well just here, before passing to the next point of consideration, to

answer a query which may arise at this juncture:

What are the successive stages of effects upon the economy from its

commencement until the full effect is observed, and what proof have I that

it was due to the amount of air inhaled?

The heart's action is not increased more than from seventy (the average) to

eighty and sometimes ninety, but is much enfeebled, or throwing a lesser

quantity of blood. The face becomes suffused, as in blowing a fire or in

stooping, which continues until the breathing is suspended, when the

face becomes paler. (Have not noticed any purple as from asphyxia by a

deprivation of oxygen.) The vision becomes darkened, and a giddiness soon

appears. The voluntary muscles furthest from the heart seem first to be

affected, and the feet and hands, particularly the latter, have a numbness

at their ends, which increases, until in many cases there is partial

paralysis as far as the elbow, while the limbs become fixed. The hands are

so thoroughly affected that, when open, the patient is powerless to close

them and _vice versa_. There is a vacant gaze from the eyes and looking

into space without blinking of the eyelids for a half minute or more. The

head seems incapable of being held erect, and there is no movement of the

arms or legs as is usual when in great pain. There is no disposition on the

part of the patient to take hold of the operator's hand or interfere with

the operation.

Many go on breathing mechanically after the tooth is removed, as if nothing

had occurred. Some are aware that the tooth has been extracted, and say

they felt it; others could not tell what had been accomplished. The

majority of cases have an idea of what is being done, but are powerless to

resist.

With the very intelligent, or those who stop to reason, I have to teach

them the peculiarities of being sensible of touch and not of pain.

One very interesting case I will state. In extracting seven teeth for a

lady who was very _unwilling_ to believe my statement as to touch and no

pain, I first removed three teeth after having inhaled for one minute, and

when fully herself, she stated that she could not understand why there was

no pain while she was conscious of each one extracted; it was preposterous

to believe such an effect could be possible, as her reason told her that

there is connected with tooth extracting pain in the part, and of severe

character, admitting, though, she felt no pain. She allowed one to be

removed without anything, and she could easily distinguish the change, and

exclaimed, "It is all the difference imaginable!" When the other three were

extracted, there was perfect success again as with the first three.

One of the most marked proofs of the effects of rapid breathing was that of

a boy of eleven years of age for whom I had to extract the upper and lower

first permanent molars on each side. He breathed for nearly a minute, when

I removed in about twenty seconds all four of the teeth, without a moment's

intermission or the stopping the vigorous breathing; and not a murmur,

sigh, or tear afterward.

He declared there was no pain, and we needed no such assertion, for there

was not the first manifestation from him that he was undergoing such a

severe operation.

Another case, the same day, when I had to extract the superior wisdom teeth

on both sides for an intelligent young lady of eighteen years, where I had

to use two pairs of forceps on each tooth (equivalent to extraction of four

teeth), and she was so profoundly affected afterward that she could; not

tell me what had been done other than that I had touched her four times.

She was overcome from its effects for at least a minute afterward. She was

delighted.

With such severe tests I fear very little the result in any case I can have

them do as I bid.

There can be no mistake that there is a _specific action_ from something.

It cannot be personal magnetism or mesmeric influence exerted by me, for

such cases are rare, averaging about 10 per cent, only of all classes.

Besides, in mesmeric influence the time has nothing to do with it; whereas,

in my cases, it cannot last over a half minute or minute at most. It cannot

be fear, as such cases are generally more apt to get hurt the worse. It is

not diversion of mind alone, as we have an effect above it.

There is no better way of testing whether pain has been felt than by taking

the lacerated or contused gums of the patient between the index finger

and thumb and making a gentle pressure to collapse the alveolar borders;

invariably, they will cry out lustily, _that is pain_! This gives undoubted

proof of a specific agent. There is no attempt upon my _own_ part to exert

any influence over my patients in any way other than that they shall

believe what I say in regard to _giving_ them _no pain_ and in the

following of my orders. Any one who knows how persons become mesmerized can

attest that it was not the _operator who forces them under it against

their will_, but it is a peculiar state into which any one who has within

themselves this temperament can _place_ themselves where any one who knows

how can have control. It is not the will of the operator. I therefore

dismiss this as unworthy of consideration in connection with rapid

breathing.

Then you may now ask, To what do I attribute this very singular phenomenon?

Any one who followed, in the earlier part of this paper, the course of

the argument in my soliloquy, after twenty years had elapsed from my

observation upon myself of the analgesic effects of chloroform, can almost

give something of an answer.

That you may the more easily grasp what I shall say, I will ask you, If it

be possible for any human being to make one hundred inhalations in a minute

and the heart's action is not increased more than ten or twenty pulsations

over the normal, what should be the effect upon the brain and nerve

centers?

If the function of oxygen in common air is to set free in the blood,

either in the capillaries alone, or throughout the whole of the arterial

circulation, carbonic acid gas; and that it cannot escape from the system

unless it do so in the lungs as it passes in the general current--except

a trace that is removed by the skin and kidneys--and that the quantity of

carbonic acid gas set free is in exact relation to the amount of oxygen

taken into the blood, what effect _must be_ manifested where one hundred

respirations in one minute are made--five or six times the normal

number--while the heart is only propelling the blood a very little faster

through the lungs, and _more feebly_--say 90 pulsations at most, when to

be in proportion it should be 400 to 100 respirations to sustain life any

length of time?

You cannot deny the fact that a definite amount of oxygen can be absorbed

and is absorbed as fast as it is carried into the lungs, even if there be

one hundred respirations to the minute, while the pulsations of the heart

are only ninety! Nature has _made it_ possible to breathe so rapidly to

meet any emergency; and we can well see its beautiful application in the

normal action of both the heart and lungs while one is violently running.

What would result, and that very speedily, were the act of respiration to

remain at the standard--say 18 or 20--when the heart is in violent action

from this running? Asphyxia would surely end the matter! And why? The

excessive exercise of the whole body is setting free from the tissues such

an amount of excretive matter, and carbon more largely than all the others,

that, without a relative action of the lungs to admit the air that oxygen

may be absorbed, carbonic acid gas cannot be liberated through the lungs

as fast as the waste carbon of the overworked tissues is being made by

disassimilation from this excess of respiration.

You are already aware how small a quantity of carbonic acid in excess in

the air will seriously affect life. Even 2 to 3 per cent, in a short time

will prove fatal. In ordinary respiration of 20 to the minute the average

of carbonic acid exhaled is 4.35.

From experiments long ago made by Vierordt--see Carpenter, p. 524--you will

see the relative per cent, of carbonic acid exhaled from a given number of

respirations. When he was breathing six times per minute, 5.5 per cent of

the exhaled air was carbonic acid; twelve times, 4.2; twenty-four times,

3.3; forty-eight times, 3; ninety-six times, 2.6.

Remember this is based upon the whole number of respirations in the minute

and not each exhalation--which latter could not be measured by the most

minute method.

Let us deduct the minimum amount, 2.6 per cent, of carbonic acid when

breathing ninety-six times per minute, from the average, at twenty per

minute, or the normal standard, which is recorded in Carpenter, p. 524, as

4.35 per minute, and we have retained in the circulation nearly 2 per cent.

of carbonic acid; that, at the average, would have passed off through the

lungs without any obstruction, and life equalized; but it not having been

thrown off as fast as it should have been, must, of necessity, be left to

prey upon the brain and nerve centers; and as 2 to 3 per cent., we are

told, will so poison the blood, life is imperiled and that speedily.

It is not necessary we should argue the point as to whether oxygen

displaces carbonic acid in the tissues proper or the capillaries. The

theory of Lavoisier on this point has been accepted.

We know furthermore, as more positive, that tissues placed in an atmosphere

of oxygen will set free carbonic acid, and that carbonic acid has a

paralyzing effect upon the human hand held in it for a short time. The

direct and speedy effects of this acid upon the delicate nervous element of

the brain is so well known that it must be accepted as law. One of the most

marked effects is the suspension of locomotion of the legs and arms,

and the direct loss of will power which must supervene before voluntary

muscular inactivity, which amounts to partial paralysis in the hands or

feet, or peripheral extremities of the same.

Now that we have sufficient evidence from the authorities that carbonic

acid can be retained in the blood by excessive breathing, and enough to

seriously affect the brain, and what its effects are when taken directly

into the lungs in excess, we can enter upon what I have held as the most

reasonable theory of the phenomenon produced by rapid breathing for

analgesic purposes; which _theory_ was not _first_ conceived and the

process made to yield to it, but the phenomenon was long observed, and

from the repetition of the effects and their close relationship to that

of carbonic acid on the economy, with the many experiments performed

upon myself, I am convinced that what I shall now state will be found to

substantiate my discovery. Should it not be found to coincide with what

some may say is physiological truth, it will not invalidate the discovery

itself; for of that I am far more positive than Harvey was of the discovery

of the circulation of the blood; or of Galileo of the spherical shape of

the earth. And I ask that it shall not be judged by my theory, but from the

practice.

It should have as much chance for investigation as the theory of

Julius Robert Mayer, upon which he founded, or which gave rise to the

establishment of one of the most important scientific truths--"the

conservation of energy," and finally the "correlation of forces," which

theory I am not quite sure was correct, although it was accepted, and as

yet, I have not seen it questioned.

In all due respect to him I quote it from the sketch of that remarkable

man, as given in the _Popular Science Monthly_, as specially bearing on my

discovery:

"Mayer observed while living in Java, that the _venous blood_ of some of

his patients had a singularly bright red color. The observation riveted

his attention; he reasoned upon it, and came to the conclusion that the

brightness of the color was due to the fact that a less amount of oxidation

was sufficient to keep up the temperature of the body in a hot climate than

a cold one. The darkness of the venous blood he regarded as the visible

sign of the energy of the oxidation."

My observation leads me to the contrary, that the higher the temperature

the more rapid the breathing to get clear of the excess of carbon, and

hence more oxygenation of the blood which will arterialize the venous

blood, unless there is a large amount of carbonized matter from the tissues

to be taken up.

Nor must it be denied because of the reasoning as presented to my mind by

some outside influence in my soliloquy when I first exclaimed, "Nature's

anaesthetic," where the argument as to the effects of nitrous oxide gas

being due to an excess of oxygen was urged, and that common air breathed in

excess would do the same thing.

I am not sure that _it_ was correct, for the effects of nitrous oxide is,

perhaps, due to a deprivation of mechanically mixed air.

Knowing what I do of theory and practice, I can say with assurance that

there is not a medical practitioner who would long ponder in any urgent

case as to the thousand and one theories of the action of remedies; but

would resort to the _practical_ experience of others and his own finally.

(What surgeon ever stops to ask how narcotics effect their influence?)

After nearly thirty years of association with ether and chloroform, who can

positively answer as to their _modus operandi?_ It is thus with nearly the

whole domain of medicine. It is not yet, by far, among the sciences, with

immutable laws, such as we have in chemistry. Experimentation is giving us

more specific knowledge, and "practice alone has tended to make perfect."

(Then, gentlemen will not set at naught my assertion and practical results.

When I have stated my case in full it is for _you_ to disprove both the

theory and practice annunciated. So far as I am concerned I am responsible

for both.)

You will please bear with me for a few minutes in my attempt at theory.

The annulling of pain, and, in some cases, its complete annihilation,

can be accomplished in many ways. Narcotics, anaesthetics--local and

internal--direct action of cold, and mesmeric or physiological influence,

have all their advocates, and each _will surely_ do its work. There is one

thing about which, I think, we can all agree, as to these agencies; unless

the _will_ is partially and in some cases completely subjugated there can

be no primary or secondary effect. The voluntary muscles must become wholly

or partially paralyzed for the time. Telegraphic communication must be cut

off from the brain, that there be no reflex action. It is not necessary

there should be separate nerves to convey pleasure and pain any more than

there should be two telegraphic wires to convey two messages.

If, then, we are certain of this, it matters little as to whether it was

done by corpuscular poisoning and anaemia as from chloroform or hyperaemia

from ether.

I think we are now prepared to show clearly the causes which effect the

phenomena in "rapid breathing."

The first thing enlisted is the _diversion of the will force_ in the act of

forced respiration at a moment when the heart and lungs have been in normal

reciprocal action (20 respirations to 80 pulsations), which act could

not be made and carried up to 100 respirations per minute without such

concentrated effort that ordinary pain could make no impression upon the

brain while this abstraction is kept up.

Second. There is a specific effect resulting from enforced respiration of

100 to the minute, due to the _excess of carbonic acid gas set free from

the tissues_, generated by this enforced normal act of throwing into the

lungs _five times_ the normal amount of oxygen in one minute demanded, when

the heart has not been aroused to exalted action, which comes from violent

exercise in running or where one is suddenly startled, which excess of

carbonic acid cannot escape in the same ratio from the lungs, since the

heart does not respond to the proportionate overaction of the lungs.

Third.--Hyperaemia is the last in this chain of effects, which is due to

the excessive amount of air passing into the lungs preventing but little

more than the normal quantity of blood from passing from the heart into

the arterial circulation, but draws it up in the brain with its excess of

carbonic acid gas to act also directly upon the brain as well as throughout

the capillary and venous system, and as well upon the heart, the same as if

it were suspended in that gas outside the body.

These are evident to the senses of any liberal observer who can witness a

subject rapidly breathing.

Some ask why is not this same thing produced when one has been running

rapidly for a few minutes? For a very good reason: in this case the rapid

inhalations are preceded by the violent throes of the heart to propel the

carbonized blood from the overworked tissues and have them set free at the

lungs where the air is rushing in at the normal ratio of four to one. This

is not an abnormal action, but is of necessity, or asphyxia would instantly

result and the runner would drop. Such sometimes occurs where the runner

exerts himself too violently at the very outset; and to do so he is

compelled to hold his breath for this undue effort, and the heart cannot

carry the blood fast enough. In this instance there is an approach to

analgesia as from rapid breathing.

Let me take up the first factor--_diversion of will_--and show that nature

invariably resorts to a sudden inhalation to prevent severe infliction of

pain being felt. It is the panacea to childhood's frequent bruises and

cuts, and every one will remember how when a finger has been hurt it is

thrust into the mouth and a violent number of efforts at rapid inhalation

is effected until ease comes. By others it is subdued by a fit of crying,

which if you will but imitate the sobs, will find how frequently the

respirations are made.

One is startled, and the heart would seem to jump out of the chest; in

quick obedience to nature the person is found making a number of quick

inhalations, which subdue the heart and pacify the will by diversion from

the cause.

The same thing is observed in the lower animals. I will relate a case:

An elephant had been operated upon for a diseased eye which gave him great

pain, for which he was unprepared, and he was wrathy at the keeper and

surgeon. It soon passed off, and the result of the application was so

beneficial to the animal that when brought out in a few days after, to have

another touch of caustic to the part, he was prepared for them; and, just

before the touch, he inflated the lungs to their fullest extent, which

occupied more time than the effect of the caustic, when he made no effort

at resistance and showed no manifestation of having been pained.

In many cases of extraction of the temporary teeth of children, I make them

at the instant I grasp the tooth take _one_ very violent inhalation, which

is sufficient. Mesmeric anaesthesia can well be classified under diversion

or subjugation of the will, but can be effected in but a small percentage

of the cases. To rely upon this first or primary effect, except in

instantaneous cases, would be failure.

The second factor is the one upon which I can rely in such of the cases as

come into my care, save when I cannot induce them to make such a number of

respirations as is absolutely necessary. The _whole secret of success lies_

in the greatest number of respirations that can be effected in from 60 to

90 seconds, and that without any intermission. If the heart, by the _alow

method of respiration_, is pulsating in ratio of four to one respiration,

_no effect can be induced_.

When the respirations are, say, 100 to the minute, and made with all the

energy the patient can muster, and are kept up while the operation is going

on, there can hardly be a failure in the minor operations.

It is upon this point many of you may question the facts. Before I tried

it for the first time upon my own person, I arrived at the same conclusion

from a course of argument, that rapid breathing would control the heart's

action and pacify it, and even reduce it below the normal standard under my

urgent respirations.

In view of the many applications made I feel quite sure in my belief that,

inasmuch as the heart's action is but slightly accelerated, though with

less force from rapid breathing at the rate of 100 to the minute, there is

such an excess of carbonic acid gas set free and crowding upon the heart

and capillaries of the brain, without a chance to escape by the lungs, that

it is the same to all intents as were carbonic acid breathed through the

lungs in common air. Look at the result after this has been kept up for a

minute or more? During the next minute the respirations are not more than

one or two, and the heart has fallen really below, in some cases, the

standard beat, showing most conclusively that once oxygenation has taken

place and that the free carbonic acid gas has been so completely consumed,

that there is no involuntary call through the pneumogastric nerve for a

supply of oxygen.

If any physiological facts can be proven at all, then I feel quite sure of

your verdict upon my side.

There is no one thing that goes so far to prove the theory of Lavoisier

regarding the action of oxygen in the tissues and capillaries for

converting carbon into carbonic acid gas instead of the lungs, as held

prior to that time, and still held by many who are not posted in late

experiments. At the time I commenced this practice I must confess I knew

nothing of it. The study of my cases soon led me to the same theory of

Lavoisier, as I could not make the phenomena agree with the old theory of

carbonic acid generated only in the lungs.

When Vierordt was performing his experiments upon himself in rapid

breathing from six times per minute to ninety-six, I cannot understand

why he failed to observe and record what did certainly result--an extreme

giddiness with muscular prostration and numbness in the peripheries of the

hands and feet, with suffusion of the face, and such a loss of locomotion

as to prevent standing erect without desiring support. Besides, the very

great difference he found in the amount of carbonic acid retained in the

circulation, the very cause of the phenomena just spoken of.

One thing comes in just here to account for the lack of respiration the

minute after the violent effort. The residual air, which in a normal state

is largely charged with carbonic acid, has been so completely exhausted

that some moments are consumed before there is sufficient again to call

upon the will for its discharge.

As to hyperaemia you will also assent, now that my second factor is

explained; but it is so nearly allied to the direct effect of excessive

respiration that we can well permit it to pass without argument. If

hyperaemia _is present_, we have a more certain and rather more lasting

effect.

In conclusion, I will attempt to prognosticate the application of this

principle to the cure of many diseases of chronic nature, and especially

tuberculosis; where from a diminished amount of air going into the lungs

for want of capacity, and particularly for want of energy and inclination

to breathe in full or excess, the tissues cannot get clear of their

excrementitious material, and particularly the carbon, which must go to the

lungs, this voluntary effort can be made frequently during the day to

free the tissues and enable them to take nutritious material for their

restoration to their standard of health.

Air will be found of far more value than ever before as one of the greatest

of factors in nutrition, and which is as necessary as proper food, and

without which every organization must become diseased, and no true

assimilation can take place without a due amount of oxygen is hourly

and daily supplied by this extra aid of volition which has been so long

overlooked.

The pure oxygen treatment has certainly performed many cures; yet, when

compared to the mechanical mixture and under the direct control of

the will, at all times and seasons, there is no danger from excessive

oxygenation as while oxygen is given. When every patient can be taught to

rely upon this great safety valve of nature, there will be less need for

medication, and the longevity of our race be increased with but little

dread by mankind for that terrible monster consumption, which seems to have

now unbounded control.

When this theory I have here given you to-night is fully comprehended by

the medical world and taught the public, together with the kind of foods

necessary for every one in their respective occupation, location, and

climate, we may expect a vast change in their physical condition and a hope

for the future which will brighten as time advances.

I herewith attach the sphygmographic tracings made upon myself by another,

showing the state of the pulse as compared with the progress of the

respiration.

ADDENDA.

Sphygmographic tracings of the pulse of the essayist. Normal pulse 60

to the minute. Ten seconds necessary for the slip to pass under the

instrument.

[Illustration]

A, A, normal pulse.

B, pulse taken after breathing rapidly for 15 seconds when

20 respirations had been taken.

C, rapid breathing for 30 seconds, 43 respirations.

D, " " 45 " 76 "

E, " " 60 " 96 "

F, pulse taken after rapid breathing for one minute, as in E, where no

respiration had as yet been taken after the essayist had kept it up for

that one minute. This was after 10 seconds had intervened.

G, the same taken 50 seconds after, and still no respiration had been

taken, the subject having no disposition to inhale, the blood having been

over oxygenated.

The pulse in E shows after 96 respirations but 14, or 84 per minute, and

the force nearly as in the normal at A, A1.

The record in B shows the force more markedly, but still normal in number.

F and G show very marked diminution in the force, but the number of

pulsations not over 72 per minute; G particularly so, the heart needing the

stimulus of the oxygen for full power.

The following incident which has but very recently been made known, gives

most conclusive evidence of the truth of the theory and practice of rapid

breathing.

A Mexican went into the office of a dentist in one of the Mexican cities to

have a tooth extracted by nitrous oxide gas.

The dentist was not in, and the assistant was about to permit the patient

to leave without removing the tooth, when the wife of the proprietor

exclaimed that she had often assisted her husband in giving the gas, and

that she would do so in this instance if the assistant would agree to

extract the tooth. It was agreed. All being in readiness, the lady turned

on as she supposed the gas, and the Mexican patient was ordered to breathe

as fast as possible to make sure of the full effect and no doubt of the

final success. The assistant was about to extract, but the wife insisted on

his breathing more rapidly, whereupon the patient was observed to become

very dark or purple in the face, which satisfied the lady that the

full effect was manifested, and the tooth was extracted, to the great

satisfaction of all concerned. While the gas was being taken by the Mexican

the gasometer was noticed to rise higher and higher as the patient breathed

faster, and not to sink as was usual when the gas had been previously

administered. This led to an investigation of the reason of such an

anomalous result, when to their utter surprise they found the valve was so

turned by the wife that the Mexican had been breathing nothing but common

air, and instead of exhaling into the surrounding air he violently forced

it into the gasometer with the nitrous oxide gas, causing it to rise and

not sink, which it should have done had the valve been properly turned by

the passage of gas into the lungs of the patient.

No more beautiful and positive trial could happen, and might not again by

accident or inadvertence happen again in a lifetime.

* * * * *

TAP FOR EFFERVESCING LIQUIDS.

When a bottle of any liquor charged with carbonic acid under strong

pressure, such as champagne, sparkling cider, seltzer water, etc., is

uncorked, the contents often escape with considerable force, flow out, and

are nearly all lost. Besides this, the noise made by the popping of the

cork is not agreeable to most persons. To remedy these inconveniences

there has been devised the simple apparatus which we represent in the

accompanying cut, taken from _La Nature_. The device consists of a hollow,

sharp-pointed tube, having one or two apertures in its upper extremity

which are kept closed by a hollow piston fitting in the interior of the

tube. This tube, or "tap," as it may be called, is supported on a firm base

to which is attached a draught tube, and a small lever for actuating the

piston. After the tap has been thrust through the cork of the bottle of

liquor the contents may be drawn in any quantity and as often as wanted by

simply pressing down the lever with the finger; this operation raises the

piston so that its apertures correspond with those in the sides of the top,

and the liquid thus finds access to the draught tube through the interior

of the piston. By removing the pressure the piston descends and thus closes

the vents. By means of this apparatus, then, the contents of any bottle of

effervescing liquids may be as easily drawn off as are those contained in

the ordinary siphon bottles in use.

[Illustration: TAP FOR EFFERVESCING LIQUIDS.]

* * * * *

CHEMICAL SOCIETY, LONDON, JAN. 20, 1881.

PROF. H.E. ROSCOE, President, in the Chair.

Mr. Vivian Lewes read a paper on "_Pentathionic Acid_." In March last the

author, at the suggestion of Dr. Debus, undertook an investigation of

pentathionic acid, the existence of which has been denied. The analyses

of the liquid obtained by Wackenroder and others, by passing sulphureted

hydrogen and sulphur dioxide through water, are based on the assumption

that only one acid is present in the solution, and consequently do not

establish the existence of pentathionic acid; as, for example, a mixture of

one molecule of H_2S_4O_6 and one molecule of H_2S_6O_6 would give the same

analytical results as H_2S_5O_6. Moreover, no salt of pentathionic acid has

been prepared in a pure state. The author has succeeded in preparing barium

pentathionate thus: A Wackenroder solution was about half neutralized with

barium hydrate, filtered, and the clear solution evaporated _in vacuo_ over

sulphuric acid. After eighteen days crystals, which proved to be barium

pentathionate + 3 molecules of water, formed. These crystals were

separated, and the liquid further evaporated, when a second crop was

obtained intermediate in composition between the tetra and pentathionate.

These were separated, and the mother-liquor on standing deposited some

oblong rectangular crystals. These on analysis proved to consist of baric

pentathionate with three molecules of water. This salt dissolves readily in

cold water; the solution is decomposed by strong potassic hydrate, baric

sulphite, hyposulphites, and sulphur being formed. By a similar method of

procedure the author obtained potassium pentathionate, anhydrous, and with

one or two molecules of water. The author promises some further results

with some other salts of the higher thionates.

The president said that the society had to thank the author for a very

complete research on the subject of pentathionic acid. He, however, begged

to differ from him as to his statements concerning the researches of

Messrs. Takamatsu and Smith; in his opinion these authors had proved the

existence of pentathionic acid. He hoped that the crystals (which were very

fine) would be measured.

Dr. Debus said that no one had previously been able to make the salts of

pentathionic acid, and expressed his sense of the great merit due to the

author for his perseverance and success. The paper opened up some highly

interesting theoretical speculations as to the existence of hexathionic

acid. If potassium tetrathionate was dissolved in water it could be

re-crystallized, but potassium pentathionate under similar circumstances

splits into sulphur and tetrathionate; but a mixture of tetrathionate and

pentathionate can be re-crystallized. It seemed as if the sulphur when

eliminated from the pentathionate combined with the tetrathionate.

Dr. Dupre asked Dr. Debus how it was that a molecule of pentathionate could

be re-crystallized, whereas two molecules of pentathionate, which should,

when half decomposed, furnish a molecule of tetra and a molecule of

pentathionate, could not.

Dr. Armstrong then read a _"Preliminary Note on some Hydrocarbons from

Rosin Spirit."_ After giving an account of our knowledge of rosin spirit,

the author described the result of the examination of the mixture of

hydrocarbons remaining after heating it with sulphuric acid and diluting

with half its volume of water and steam distilling. Thus treated rosin

spirit furnishes about one-fourth of its volume of a colorless mobile

liquid, which after long-continued fractional distillation is resolved into

a variety of fractions boiling at temperatures from 95 deg. to over 180 deg.. Each

of the fractions was treated with concentrated sulphuric acid, and the

undissolved portions were then re-fractionated. The hydrocarbons dissolved

by the acid were recovered by heating under pressure with hydrochloric

acid. Besides a cymene and a toluene, which have already been shown to

exist in rosin spirit, metaxylene was found to be present. The hydrocarbons

insoluble in sulphuric acid are, apparently, all members of the C_nH_{2n}

series; they are not, however, true homologues of ethylene, but hexhydrides

of hydrocarbons of the benzene series. Hexhydro-toluene and probably

hex-hydrometaxylene are present besides the hydrocarbon, C_10H_20, but it

is doubtful if an intermediate term is also present. It is by no means

improbable, however, that these hydrocarbons are, at least in part,

products of the action of the sulphuric acid. Cahours and Kraemer's and

Godzki's observations on the higher fractions of crude wood spirit, in

fact, furnish a precedent for this view. Referring to the results obtained

by Anderson, Tilden, and Renard, the author suggests that rosin spirit

perhaps contains hydrides intermediate in composition between those of

the C_nH_{2n-6} and C_nH_{2n} series, also derived like the latter from

hydrocarbons of the benzene series. Finally, Dr Armstrong mentioned that

the volatile portion of the distillate from the non-volatile product of the

oxidation of oil of turpentine in moist air furnishes ordinary cymene when

treated in the manner above described. The fact that rosin spirit yields a

different cymene is, he considers, an argument against the view which

has more than once been put forward, that rosin is directly derived from

terpene. Probably resin and turpentine, though genetically related, are

products of distinct processes.

The next paper was _"On the Determination of the Relative Weight of Single

Molecules,"_ by E. Vogel, of San Francisco. This paper, which was taken as

read, consists of a lengthy theoretical disquisition, in which the author

maintains the following propositions: That the combining weights of all

elements are one third of their present values; the assumption that equal

volumes of gases contain equal numbers of molecules does not hold good;

that the present theory of valency is not supported by chemical facts, and

that its elimination would be no small gain for chemistry in freeing it

of an element full of mystery, uncertainty, and complication; that the

distinction between atoms and molecules will no longer be necessary;

that the facts of specific heat do not lend any support to the theory of

valency. The paper concludes as follows: "The cause of chemical action is

undoubtedly atmospheric pressure, which under ordinary conditions is equal

to the weight of 76 cubic centimeters of mercury, one of which equals 6.145

mercury molecules, so that the whole pressure equals 467 mercury molecules.

This force--which with regard to its chemical effect on molecules can be

multiplied by means of heat--is amply sufficient to bring about the highest

degree of molecular specific gravity by the reduction of the molecular

volumes. To it all molecules are exposed and subjected unalterably, and

if not accepted as the cause of chemical action, its influence has to be

eliminated to allow the introduction and display of other forces."

The next communication was _"On the Synthetical Production of Ammonia,

by the Combination of Hydrogen and Nitrogen in Presence of Heated Spongy

Platinum (Preliminary Notice),"_ by G. S. Johnson. Some experiments, in

which pure nitrogen was passed over heated copper containing occluded

hydrogen, suggested to the author the possibility of the formation of

ammonia; only minute traces were formed. On passing, however, a mixture of

pure nitrogen (from ammonium nitrite) and hydrogen over spongy platinum at

a low red heat, abundant evidence was obtained of the synthesis of ammonia.

The gases were passed, before entering the tube containing the platinum,

through a potash bulb containing Nessler reagent, which remained colorless.

On the contrary, the gas issuing from the platinum rapidly turned Nessler

reagent brown, and in a few minutes turned faintly acid litmus solution

blue; the odor of NH_3 was also perceptible. In one experiment 0.0144

gramme of ammonia was formed in two hours and a half. The author promises

further experiment as to the effect of temperature, rate of the gaseous

current, and substitution of palladium for platinum. The author synthesized

some ammonia before the Society with complete success.

The President referred to the synthesis of ammonia from its elements

recently effected by Donkin, and remarked that apparently the ammonia was

formed in much larger quantities by the process proposed by the author of

the present paper.

Mr. Warington suggested that some HCl gas should be simultaneously passed

with the nitrogen and hydrogen, and that the temperature of the spongy

platinum should be kept just below the temperature at which NH_3

dissociates, in order to improve the yield of NH_3.

_"On the Oxidation of Organic Matter in Water"_ by A. Downes. The author

considers that the mere presence of oxygen in contact with the organic

matter has but little oxidizing action unless lowly organisms, as bacteria,

etc. be simultaneously present. Sunlight has apparently considerable

effect in promoting the oxidation of organic matter. The author quotes the

following experiment: A sample of river water was filtered through paper.

It required per 10,000 parts 0.236 oxygen as permanganate. A second portion

was placed in a flask plugged with cotton wool, and exposed to sunlight for

a week; it then required 0.200. A third portion after a week, but excluded

from light, required 0.231. A fourth was boiled for five minutes, plugged,

and then exposed to sunlight for a week; required 0.198. In a second

experiment with well water a similar result was obtained; more organic

matter was oxidized when the organisms had been killed by the addition of

sulphuric acid than when the original water was allowed to stand for an

equal length of time. The author also discusses the statement made by Dr.

Frankland that there is less ground for assuming that the organized and

living matter of sewage is oxidized in a flow of twelve miles of a river

than for assuming that dead organic matter is oxidized in a similar

flow.--_Chem. News._

* * * * *

ROSE OIL, OR OTTO OF ROSES.

By CHARLES G. WARNFORD LOCK.

This celebrated perfume is the volatile essential oil distilled from the

flowers of some varieties of rose. The botany of roses appears to be in a

transition and somewhat unsatisfactory state. Thus the otto-yielding rose

is variously styled _Rosa damascena, R. sempervirens, R. moschata, R.

gallica, R. centifolia, R. provincialis_. It is pretty generally agreed

that the kind grown for its otto in Bulgaria in the damask rose (_R.

damascena_), a variety induced by long cultivation, as it is not to be

found wild. It forms a bush, usually three to four feet, but sometimes six

feet high; its flowers are of moderate size, semi-double, and arranged

several on a branch, though not in clusters or bunches. In color, they are

mostly light-red; some few are white, and said to be less productive of

otto.

The utilization of the delicious perfume of the rose was attempted, with

more or less success, long prior to the comparatively modern process of

distilling its essential oil. The early methods chiefly in vogue were the

distillation of rose-water, and the infusion of roses in olive oil, the

latter flourishing in Europe generally down to the last century, and

surviving at the present day in the South of France. The butyraceous oil

produced by the distillation of roses for making rose-water in this country

is valueless as a perfume; and the real otto was scarcely known in British

commerce before the present century.

The profitable cultivation of roses for the preparation of otto is limited

chiefly by climatic conditions. The odoriferous constitutent of the otto

is a liquid containing oxygen, the solid hydrocarbon or stearoptene, with

which it is combined, being absolutely devoid of perfume. The proportion

which this inodorous solid constituents bears to the liquid perfume

increases with the unsuitability of the climate, varying from about 18 per

cent. in Bulgarian oil, to 35 and even 68 per cent. in rose oils distilled

in France and England. This increase in the proportion of stearoptene is

also shown by the progressively heightened fusing-point of rose oils from

different sources: thus, while Bulgarian oil fuses at about 61 deg. to 64 deg.

Fahr., an Indian sample required 68 deg. Fahr.; one from the South of France,

70 deg. to 73 deg. Fahr.; one from Paris, 84 deg. Fahr.; and one obtained in making

rose-water in London, 86 deg. to 891/2 deg. Fahr. Even in the Bulgarian oil, a

notable difference is observed between that produced on the hills and that

from the lowlands.

It is, therefore, not surprising that the culture of roses, and extraction

of their perfume, should have originated in the East. Persia produced

rose-water at an early date, and the town of Nisibin, north-west of Mosul,

was famous for it in the 14th century. Shiraz, in the 17th century,

prepared both rose water and otto, for export to other parts of Persia, as

well as all over India. The Perso-Indian trade in rose oil, which continued

to possess considerable importance in the third quarter of the 18th

century, is declining, and has nearly disappeared; but the shipments of

rose-water still maintain a respectable figure. The value, in rupees, of

the exports of rose-water from Bushire in 1879, were--4,000 to India, 1,500

to Java, 200 to Aden and the Red Sea, 1,000 to Muscat and dependencies, 200

to Arab coast of Persian Gulf and Bahrein, 200 to Persian coast and Mekran,

and 1,000 to Zanzibar. Similar statistics relating to Lingah, in the same

year, show--Otto: 400 to Arab coast of Persian Gulf, and Bahrein; and 250

to Persian coast and Mekran. And Bahrein--Persian Otto: 2,200 to Koweit,

Busrah, and Bagdad. Rose-water: 200 to Arab coast of Persian Gulf, and

1,000 to Koweit, Busrah, and Bagdad.

India itself has a considerable area devoted to rose-gardens, as at

Ghazipur, Lahore, Amritzur, and other places, the kind of rose being _R.

damascena_, according to Brandis. Both rose-water and otto are produced.

The flowers are distilled with double their weight of water in clay stills;

the rose-water (_goolabi pani_) thus obtained is placed in shallow vessels,

covered with moist muslin to keep out dust and flies, and exposed all night

to the cool air, or fanned. In the morning, the film of oil, which has

collected on the top, is skimmed off by a feather, and transferred to a

small phial. This is repeated for several nights, till almost the whole of

the oil has separated. The quantity of the product varies much, and three

different authorities give the following figures: (_a_) 20,000 roses to

make 1 rupee's weight (176 gr.) of otto; (_b_) 200,000 to make the same

weight; (_c_) 1,000 roses afford less than 2 gr. of otto. The color ranges

from green to bright-amber, and reddish. The oil (otto) is the most

carefully bottled; the receptacles are hermetically sealed with wax, and

exposed to the full glare of the sun for several days. Rose water deprived

of otto is esteemed much inferior to that which has not been so treated.

When bottled, it is also exposed to the sun for a fortnight at least.

The Mediterranean countries of Africa enter but feebly into this industry,

and it is a little remarkable that the French have not cultivated it in

Algeria. Egypt's demand for rose-water and rose-vinegar is supplied from

Medinet Fayum, south-west of Cairo. Tunis has also some local reputation

for similar products. Von Maltzan says that the rose there grown for otto

is the dog-rose (_R. canina_), and that it is extremely fragrant, 20 lb.

of the flower yielding about 1 dr. of otto. Genoa occasionally imports a

little of this product, which is of excellent quality. In the south of

France rose gardens occupy a large share of attention, about Grasse,

Cannes, and Nice; they chiefly produce rose-water, much of which is

exported to England. The essence (otto) obtained by the distillation of the

Provence rose (_R. provincialis_) has a characteristic perfume, arising, it

is believed, from the bees transporting the pollen of the orange flowers

into the petals of the roses. The French otto is richer in stearoptene than

the Turkish, nine grammes crystallizing in a liter (13/4 pint) of alcohol at

the same temperature as 18 grammes of the Turkish. The best preparations

are made at Cannes and Grasse. The flowers are not there treated for the

otto, but are submitted to a process of maceration in fat or oil, ten

kilos. of roses being required to impregnate one kilo. of fat. The price of

the roses varies from 50c. to 1 fr. 25c. per kilo.

But the one commercially important source of otto of roses is a

circumscribed patch of ancient Thrace or modern Bulgaria, stretching along

the southern slopes of the central Balkans, and approximately included

between the 25th and 26th degrees of east longitude, and the 42d and 43d of

north latitude. The chief rose-growing districts are Philippopoli, Chirpan,

Giopcu, Karadshah-Dagh, Kojun-Tepe, Eski-Sara, Jeni-Sara, Bazardshik, and

the center and headquarters of the industry, Kazanlik (Kisanlik),

situated in a beautiful undulating plain, in the valley of the Tunja. The

productiveness of the last-mentioned district may be judged from the fact

that, of the 123 Thracian localities carrying on the preparation of otto in

1877--they numbered 140 in 1859--42 belong to it. The only place affording

otto on the northern side of the Balkans is Travina. The geological

formation throughout is syenite, the decomposition of which has provided a

soil so fertile as to need but little manuring. The vegetation, according

to Baur, indicates a climate differing but slightly from that of the Black

Forest, the average summer temperatures being stated at 82 deg. Fahr. at noon,

and 68 deg. Fahr. in the evening. The rose-bushes nourish best and live longest

on sandy, sun-exposed (south and south-east aspect) slopes. The flowers

produced by those growing on inclined ground are dearer and more esteemed

than any raised on level land, being 50 per cent. richer in oil, and that

of a stronger quality. This proves the advantage of thorough drainage. On

the other hand, plantations at high altitudes yield less oil, which is of a

character that readily congeals, from an insufficiency of summer heat. The

districts lying adjacent to and in the mountains are sometimes visited

by hard frosts, which destroy or greatly reduce the crop. Floods also

occasionally do considerable damage. The bushes are attacked at intervals

and in patches by a blight similar to that which injures the vines of the

country.

The bushes are planted in hedge-like rows in gardens and fields, at

convenient distances apart, for the gathering of the crop. They are seldom

manured. The planting takes place in spring and autumn; the flowers attain

perfection in April and May, and the harvest lasts from May till the

beginning of June. The expanded flowers are gathered before sunrise,

often with the calyx attached; such as are not required for immediate

distillation are spread out in cellars, but all are treated within the day

on which they are plucked. Baur states that, if the buds develop slowly,

by reason of cool damp weather, and are not much exposed to sun-heat, when

about to be collected, a rich yield of otto, having a low solidifying

point, is the result, whereas, should the sky be clear and the temperature

high at or shortly before the time of gathering, the product is diminished

and is more easily congealable. Hanbury, on the contrary, when distilling

roses in London, noticed that when they had been collected on fine dry

days the rose-water had most volatile oil floating upon it, and that, when

gathered in cool rainy weather, little or no volatile oil separated.

The flowers are not salted, nor subjected to any other treatment, before

being conveyed in baskets, on the heads of men and women and backs of

animals, to the distilling apparatus. This consists of a tinned-copper

still, erected on a semicircle of bricks, and heated by a wood fire; from

the top passes a straight tin pipe, which obliquely traverses a tub kept

constantly filled with cold water, by a spout, from some convenient

rivulet, and constitutes the condenser. Several such stills are usually

placed together, often beneath the shade of a large tree. The still is

charged with 25 to 50 lb. of roses, not previously deprived of their

calyces, and double the volume of spring water. The distillation is carried

on for about l1/2 hours, the result being simply a very oily rose-water

(_ghyul suyu_). The exhausted flowers are removed from the still, and the

decoction is used for the next distillation, instead of fresh water.

The first distillates from each apparatus are mixed and distilled by

themselves, one-sixth being drawn off; the residue replaces spring water

for subsequent operations. The distillate is received in long-necked

bottles, holding about 11/4 gallon. It is kept in them for a day or two, at a

temperature exceeding 59 deg. Fahr., by which time most of the oil, fluid

and bright, will have reached the surface. It is skimmed off by a small,

long-handled, fine-orificed tin funnel, and is then ready for sale. The

last-run rose-water is extremely fragrant, and is much prized locally for

culinary and medicinal purposes. The quantity and quality of the otto are

much influenced by the character of the water used in distilling. When

hard spring water is employed, the otto is rich in stearoptene, but less

transparent and fragrant. The average quantity of the product is estimated

by Baur at 0.037 to 0.040 per cent.; another authority says that 3,200

kilos. of roses give 1 kilo. of oil.

Pure otto, carefully distilled, is at first colorless, but speedily becomes

yellowish; its specific gravity is 0.87 at 72.5 deg. Fahr.; its boiling-point

is 444 deg. Fahr.; it solidifies at 51.8 deg. to 60.8 deg. Fahr., or still higher; it

is soluble in absolute alcohol, and in acetic acid. The most usual and

reliable tests of the quality of an otto are (1) its odor, (2) its

congealing point, (3) its crystallization. The odor can be judged only

after long experience. A good oil should congeal well in five minutes at

a temperature of 54.5 deg. Fahr.; fraudulent additions lower the congealing

point. The crystals of rose-stearoptene are light, feathery, shining

plates, filling the whole liquid. Almost the only material used for

artificially heightening the apparent proportion of stearoptene is said to

be spermaceti, which is easily recognizable from its liability to settle

down in a solid cake, and from its melting at 122 deg. Fahr., whereas

stearoptene fuses at 91.4 deg. Fahr. Possibly paraffin wax would more easily

escape detection.

The adulterations by means of other essential oils are much more difficult

of discovery, and much more general; in fact, it is said that none of the

Bulgarian otto is completely free from this kind of sophistication. The

oils employed for the purpose are certain of the grass oils (_Andropogon_

and _Cymbopogon spp._) notably that afforded by _Andropogon, Schoenanthus_

called _idris-yaghi_ by the Turks, and commonly known to Europeans as

"geranium oil," though quite distinct from true geranium oil. The addition

is generally made by sprinkling it upon the rose-leaves before distilling.

It is largely produced in the neighborhood of Delhi, and exported to

Turkey by way of Arabia. It is sold by Arabs in Constantinople in large

bladder-shaped tinned-copper vessels, holding about 120 lb. As it is

usually itself adulterated with some fatty oil, it needs to undergo

purification before use. This is effected in the following manner: The

crude oil is repeatedly shaken up with water acidulated with lemon-juice,

from which it is poured off after standing for a day. The washed oil

is placed in shallow saucers, well exposed to sun and air, by which it

gradually loses its objectionable odor. Spring and early summer are the

best seasons for the operation, which occupies two to four weeks, according

to the state of the weather and the quality of the oil. The general

characters of this oil are so similar to those of otto of roses--even the

odor bearing a distant resemblance--that their discrimination when mixed is

a matter of practical impossibility. The ratio of the adulteration varies

from a small figure up to 80 or 90 per cent. The only safeguard against

deception is to pay a fair price, and to deal with firms of good repute,

such as Messrs. Papasoglu, Manoglu & Son, Ihmsen & Co., and Holstein & Co.

in Constantinople.

The otto is put up in squat-shaped flasks of tinned copper, called

_kunkumas_, holding from 1 to 10 lb., and sewn up in white woolen cloths.

Usually their contents are transferred at Constantinople into small gilded

bottles of German manufacture for export. The Bulgarian otto harvest,

during the five years 1867-71, was reckoned to average somewhat below

400,000 _meticals, miskals_, or _midkals_ (of about 3 dwt. troy), or 4,226

lb. av.; that of 1873, which was good, was estimated at 500,000, value

about L700,000. The harvest of 1880 realized more than L1,000,000, though

the roses themselves were not so valuable as in 1876. About 300,000

_meticals_ of otto, valued at L932,077, were exported in 1876 from

Philippopolis, chiefly to France, Australia, America, and Germany.

--_Jour. Soc. of Arts._

* * * * *

A NEW METHOD OF PREPARING METATOLUIDINE.

By OSKAR WIDMAN.

The author adds in small portions five parts metanitro-benzaldehyd to nine

parts of phosphorus pentachloride, avoiding a great rise of temperature.

When the reaction is over, the whole is poured into excess of cold water,

quickly washed a few times with cold water, and dissolved in alcohol. After

the first crystallization the compound melts at 65 deg., and is perfectly pure.

* * * * *

A catalogue, containing brief notices of many important scientific papers

heretofore published in the SUPPLEMENT, may be had gratis at this office.

* * * * *

THE SCIENTIFIC AMERICAN SUPPLEMENT.

PUBLISHED WEEKLY.

TERMS OF SUBSCRIPTION, $5 A YEAR.

Sent by mail, postage prepaid, to subscribers in any part of the United

States or Canada. Six dollars a year, sent, prepaid, to any foreign

country.

All the back numbers of THE SUPPLEMENT, from the commencement, January 1,

1876, can be had. Price, 10 cents each.

All the back volumes of THE SUPPLEMENT can likewise be supplied. Two

volumes are issued yearly. Price of each volume, $2.50, stitched in paper,

or $3.50, bound in stiff covers.

COMBINED RATES--One copy of SCIENTIFIC AMERICAN and one copy of SCIENTIFIC

AMERICAN SUPPLEMENT, one year, postpaid, $7.00.

A liberal discount to booksellers, news agents, and canvassers.

MUNN & CO., PUBLISHERS,

37 PARK ROW, NEW YORK, N. Y.

* * * * *

PATENTS.

In connection with the SCIENTIFIC AMERICAN, Messrs. MUNN & Co. are

Solicitors of American and Foreign Patents, have had 35 years' experience,

and now have the largest establishment in the world. Patents are obtained

on the best terms.

A special notice is made in the SCIENTIFIC AMERICAN of all Inventions

patented through this Agency, with the name and residence of the Patentee.

By the immense circulation thus given, public attention is directed to the

merits of the new patent, and sales or introduction often easily effected.

Any person who has made a new discovery or invention can ascertain, free of

charge, whether a patent can probably be obtained, by writing to MUNN & Co.

We also send free our Hand Book about the Patent Laws, Patents, Caveats.

Trade Marks, their costs, and how procured, with hints for procuring

advances on inventions. Address

MUNN & CO., 37 PARK ROW, NEW YORK.

Branch Office, cor. F and 7th Sts., Washington, D. C.

End of the Project Gutenberg EBook of Scientific American Supplement 275

by Various

*** END OF THE PROJECT GUTENBERG EBOOK SCIENTIFIC AMERICAN, SUP. 275 ***

This file should be named 7027510.txt or 7027510.zip

Corrected EDITIONS of our eBooks get a new NUMBER, 7027511.txt

VERSIONS based on separate sources get new LETTER, 7027510a.txt

Produced by Olaf Voss, Don Kretz, Juliet Sutherland,

Charles Franks and the Online Distributed Proofreading Team.

Project Gutenberg eBooks are often created from several printed

editions, all of which are confirmed as Public Domain in the US

unless a copyright notice is included. Thus, we usually do not

keep eBooks in compliance with any particular paper edition.

We are now trying to release all our eBooks one year in advance

of the official release dates, leaving time for better editing.

Please be encouraged to tell us about any error or corrections,

even years after the official publication date.

Please note neither this listing nor its contents are final til

midnight of the last day of the month of any such announcement.

The official release date of all Project Gutenberg eBooks is at

Midnight, Central Time, of the last day of the stated month. A

preliminary version may often be posted for suggestion, comment

and editing by those who wish to do so.

Most people start at our Web sites at:

http://gutenberg.net or

http://promo.net/pg

These Web sites include award-winning information about Project

Gutenberg, including how to donate, how to help produce our new

eBooks, and how to subscribe to our email newsletter (free!).

Those of you who want to download any eBook before announcement

can get to them as follows, and just download by date. This is

also a good way to get them instantly upon announcement, as the

indexes our cataloguers produce obviously take a while after an

announcement goes out in the Project Gutenberg Newsletter.

http://www.ibiblio.org/gutenberg/etext03 or

ftp://ftp.ibiblio.org/pub/docs/books/gutenberg/etext03

Or /etext02, 01, 00, 99, 98, 97, 96, 95, 94, 93, 92, 92, 91 or 90

Just search by the first five letters of the filename you want,

as it appears in our Newsletters.

Information about Project Gutenberg (one page)

We produce about two million dollars for each hour we work. The

time it takes us, a rather conservative estimate, is fifty hours

to get any eBook selected, entered, proofread, edited, copyright

searched and analyzed, the copyright letters written, etc. Our

projected audience is one hundred million readers. If the value

per text is nominally estimated at one dollar then we produce $2

million dollars per hour in 2002 as we release over 100 new text

files per month: 1240 more eBooks in 2001 for a total of 4000+

We are already on our way to trying for 2000 more eBooks in 2002

If they reach just 1-2% of the world's population then the total

will reach over half a trillion eBooks given away by year's end.

The Goal of Project Gutenberg is to Give Away 1 Trillion eBooks!

This is ten thousand titles each to one hundred million readers,

which is only about 4% of the present number of computer users.

Here is the briefest record of our progress (* means estimated):

eBooks Year Month

1 1971 July

10 1991 January

100 1994 January

1000 1997 August

1500 1998 October

2000 1999 December

2500 2000 December

3000 2001 November

4000 2001 October/November

6000 2002 December*

9000 2003 November*

10000 2004 January*

The Project Gutenberg Literary Archive Foundation has been created

to secure a future for Project Gutenberg into the next millennium.

We need your donations more than ever!

As of February, 2002, contributions are being solicited from people

and organizations in: Alabama, Alaska, Arkansas, Connecticut,

Delaware, District of Columbia, Florida, Georgia, Hawaii, Illinois,

Indiana, Iowa, Kansas, Kentucky, Louisiana, Maine, Massachusetts,

Michigan, Mississippi, Missouri, Montana, Nebraska, Nevada, New

Hampshire, New Jersey, New Mexico, New York, North Carolina, Ohio,

Oklahoma, Oregon, Pennsylvania, Rhode Island, South Carolina, South

Dakota, Tennessee, Texas, Utah, Vermont, Virginia, Washington, West

Virginia, Wisconsin, and Wyoming.

We have filed in all 50 states now, but these are the only ones

that have responded.

As the requirements for other states are met, additions to this list

will be made and fund raising will begin in the additional states.

Please feel free to ask to check the status of your state.

In answer to various questions we have received on this:

We are constantly working on finishing the paperwork to legally

request donations in all 50 states. If your state is not listed and

you would like to know if we have added it since the list you have,

just ask.

While we cannot solicit donations from people in states where we are

not yet registered, we know of no prohibition against accepting

donations from donors in these states who approach us with an offer to

donate.

International donations are accepted, but we don't know ANYTHING about

how to make them tax-deductible, or even if they CAN be made

deductible, and don't have the staff to handle it even if there are

ways.

Donations by check or money order may be sent to:

Project Gutenberg Literary Archive Foundation

PMB 113

1739 University Ave.

Oxford, MS 38655-4109

method other than by check or money order.

The Project Gutenberg Literary Archive Foundation has been approved by

the US Internal Revenue Service as a 501(c)(3) organization with EIN

[Employee Identification Number] 64-622154. Donations are

tax-deductible to the maximum extent permitted by law. As fund-raising

requirements for other states are met, additions to this list will be

made and fund-raising will begin in the additional states.

We need your donations more than ever!

You can get up to date donation information online at:

http://www.gutenberg.net/donation.html

***

If you can't reach Project Gutenberg,

you can always email directly to:

Michael S. Hart <[email protected]>

Prof. Hart will answer or forward your message.

We would prefer to send you information by email.

**The Legal Small Print**

(Three Pages)

***START**THE SMALL PRINT!**FOR PUBLIC DOMAIN EBOOKS**START***

Why is this "Small Print!" statement here? You know: lawyers.

They tell us you might sue us if there is something wrong with

your copy of this eBook, even if you got it for free from

someone other than us, and even if what's wrong is not our

fault. So, among other things, this "Small Print!" statement

disclaims most of our liability to you. It also tells you how

you may distribute copies of this eBook if you want to.

*BEFORE!* YOU USE OR READ THIS EBOOK

By using or reading any part of this PROJECT GUTENBERG-tm

eBook, you indicate that you understand, agree to and accept

this "Small Print!" statement. If you do not, you can receive

a refund of the money (if any) you paid for this eBook by

sending a request within 30 days of receiving it to the person

you got it from. If you received this eBook on a physical

medium (such as a disk), you must return it with your request.

ABOUT PROJECT GUTENBERG-TM EBOOKS

This PROJECT GUTENBERG-tm eBook, like most PROJECT GUTENBERG-tm eBooks,

is a "public domain" work distributed by Professor Michael S. Hart

through the Project Gutenberg Association (the "Project").

Among other things, this means that no one owns a United States copyright

on or for this work, so the Project (and you!) can copy and

distribute it in the United States without permission and

without paying copyright royalties. Special rules, set forth

below, apply if you wish to copy and distribute this eBook

under the "PROJECT GUTENBERG" trademark.

Please do not use the "PROJECT GUTENBERG" trademark to market

any commercial products without permission.

To create these eBooks, the Project expends considerable

efforts to identify, transcribe and proofread public domain

works. Despite these efforts, the Project's eBooks and any

medium they may be on may contain "Defects". Among other

things, Defects may take the form of incomplete, inaccurate or

corrupt data, transcription errors, a copyright or other

intellectual property infringement, a defective or damaged

disk or other eBook medium, a computer virus, or computer

codes that damage or cannot be read by your equipment.

LIMITED WARRANTY; DISCLAIMER OF DAMAGES

But for the "Right of Replacement or Refund" described below,

[1] Michael Hart and the Foundation (and any other party you may

receive this eBook from as a PROJECT GUTENBERG-tm eBook) disclaims

all liability to you for damages, costs and expenses, including

legal fees, and [2] YOU HAVE NO REMEDIES FOR NEGLIGENCE OR

UNDER STRICT LIABILITY, OR FOR BREACH OF WARRANTY OR CONTRACT,

INCLUDING BUT NOT LIMITED TO INDIRECT, CONSEQUENTIAL, PUNITIVE

OR INCIDENTAL DAMAGES, EVEN IF YOU GIVE NOTICE OF THE

POSSIBILITY OF SUCH DAMAGES.

If you discover a Defect in this eBook within 90 days of

receiving it, you can receive a refund of the money (if any)

you paid for it by sending an explanatory note within that

time to the person you received it from. If you received it

on a physical medium, you must return it with your note, and

such person may choose to alternatively give you a replacement

copy. If you received it electronically, such person may

choose to alternatively give you a second opportunity to

receive it electronically.

THIS EBOOK IS OTHERWISE PROVIDED TO YOU "AS-IS". NO OTHER

WARRANTIES OF ANY KIND, EXPRESS OR IMPLIED, ARE MADE TO YOU AS

TO THE EBOOK OR ANY MEDIUM IT MAY BE ON, INCLUDING BUT NOT

LIMITED TO WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE.

Some states do not allow disclaimers of implied warranties or

the exclusion or limitation of consequential damages, so the

above disclaimers and exclusions may not apply to you, and you

may have other legal rights.

INDEMNITY

You will indemnify and hold Michael Hart, the Foundation,

and its trustees and agents, and any volunteers associated

with the production and distribution of Project Gutenberg-tm

texts harmless, from all liability, cost and expense, including

legal fees, that arise directly or indirectly from any of the

following that you do or cause: [1] distribution of this eBook,

[2] alteration, modification, or addition to the eBook,

or [3] any Defect.

DISTRIBUTION UNDER "PROJECT GUTENBERG-tm"

You may distribute copies of this eBook electronically, or by

disk, book or any other medium if you either delete this

"Small Print!" and all other references to Project Gutenberg,

or:

[1] Only give exact copies of it. Among other things, this

requires that you do not remove, alter or modify the

eBook or this "small print!" statement. You may however,

if you wish, distribute this eBook in machine readable

binary, compressed, mark-up, or proprietary form,

including any form resulting from conversion by word

processing or hypertext software, but only so long as

*EITHER*:

[*] The eBook, when displayed, is clearly readable, and

does *not* contain characters other than those

intended by the author of the work, although tilde

(~), asterisk (*) and underline (_) characters may

be used to convey punctuation intended by the

author, and additional characters may be used to

indicate hypertext links; OR

[*] The eBook may be readily converted by the reader at

no expense into plain ASCII, EBCDIC or equivalent

form by the program that displays the eBook (as is

the case, for instance, with most word processors);

[*] You provide, or agree to also provide on request at

no additional cost, fee or expense, a copy of the

eBook in its original plain ASCII form (or in EBCDIC

or other equivalent proprietary form).

[2] Honor the eBook refund and replacement provisions of this

"Small Print!" statement.

[3] Pay a trademark license fee to the Foundation of 20% of the

gross profits you derive calculated using the method you

already use to calculate your applicable taxes. If you

don't derive profits, no royalty is due. Royalties are

payable to "Project Gutenberg Literary Archive Foundation"

the 60 days following each date you prepare (or were

legally required to prepare) your annual (or equivalent

periodic) tax return. Please contact us beforehand to

let us know your plans and to work out the details.

WHAT IF YOU *WANT* TO SEND MONEY EVEN IF YOU DON'T HAVE TO?

Project Gutenberg is dedicated to increasing the number of

public domain and licensed works that can be freely distributed

in machine readable form.

The Project gratefully accepts contributions of money, time,

public domain materials, or royalty free copyright licenses.

Money should be paid to the:

"Project Gutenberg Literary Archive Foundation."

If you are interested in contributing scanning equipment or

software or other items, please contact Michael Hart at:

[email protected]

[Portions of this eBook's header and trailer may be reprinted only

Michael S. Hart. Project Gutenberg is a TradeMark and may not be

used in any sales of Project Gutenberg eBooks or other materials be

they hardware or software or any other related product without

express permission.]

*END THE SMALL PRINT! FOR PUBLIC DOMAIN EBOOKS*Ver.02/11/02*END*

Livros Grátis
( http://www.livrosgratis.com.br )

Milhares de Livros para Download:

Baixar livros de Administração
Baixar livros de Agronomia
Baixar livros de Arquitetura
Baixar livros de Artes
Baixar livros de Astronomia
Baixar livros de Biologia Geral
Baixar livros de Ciência da Computação
Baixar livros de Ciência da Informação
Baixar livros de Ciência Política
Baixar livros de Ciências da Saúde
Baixar livros de Comunicação
Baixar livros do Conselho Nacional de Educação - CNE
Baixar livros de Defesa civil
Baixar livros de Direito
Baixar livros de Direitos humanos
Baixar livros de Economia
Baixar livros de Economia Doméstica
Baixar livros de Educação
Baixar livros de Educação - Trânsito
Baixar livros de Educação Física
Baixar livros de Engenharia Aeroespacial
Baixar livros de Farmácia
Baixar livros de Filosofia
Baixar livros de Física
Baixar livros de Geociências
Baixar livros de Geografia
Baixar livros de História
Baixar livros de Línguas

Baixar livros de Literatura
Baixar livros de Literatura de Cordel
Baixar livros de Literatura Infantil
Baixar livros de Matemática
Baixar livros de Medicina
Baixar livros de Medicina Veterinária
Baixar livros de Meio Ambiente
Baixar livros de Meteorologia
Baixar Monografias e TCC
Baixar livros Multidisciplinar
Baixar livros de Música
Baixar livros de Psicologia
Baixar livros de Química
Baixar livros de Saúde Coletiva
Baixar livros de Serviço Social
Baixar livros de Sociologia
Baixar livros de Teologia
Baixar livros de Trabalho
Baixar livros de Turismo
